LOWER ARM BALL JOINT BREAKAWAY TORQUE CHECK
Required Special Tool
- MB990326: Preload Socket
Scheme 1
- Move the ball joint stud several times and install the lower arm nut on the stud. Using special tool MB990326, measure the ball joint breakaway torque. Standard value: 3.5-6.9 N. m (31-61 in-lb)
- If the measured value is not within the standard value, or if the ball joint is difficult to turn or does not turn smoothly, replace the lower arm assembly.
STABILIZER LINK BALL JOINT BREAKAWAY TORQUE CHECK
Required Special Tool
- MB990326: Preload Socket
Scheme 2
- After shaking the ball joint stud several times, install the nut to the stud and use special tool MB990326 to measure the breakaway torque of the ball joint. Standard value: 3.4-9.0 N. m (30-80 in-lb)
- When the measured value exceeds the standard value, replace the stabilizer link.
- When the measured value is lower than the standard value, check that the ball joint turns smoothly without excessive play. If so, it is possible to re-use that ball joint.
FASTENER TIGHTENING SPECIFICATIONS
| ITEM | SPECIFICATION |
|---|---|
| Lower arm assembly | |
| Lower arm to crossmember connection bolt | 165 +/- 15 N. m (122 +/- 11 ft-lb) |
| Lower arm to crossmember connection nut (self-locking nut) | 165 +/- 15 N. m (122 +/- 11 ft-lb) |
| Lower arm to knuckle connection nut (self-locking nut) | 65 +/- 6 N. m (48 +/- 4 ft-lb) |
| Stabilizer bar | |
| Crossmember to body connection bolt and nut | 180 +/- 20 N. m (133 +/- 14 ft-lb) |
| Front axle crossmember stay bolt and nut | 83 +/- 12 N. m (61 +/- 9 ft-lb) |
| Pressure tube clamp bolt | 12 +/- 2 N. m (102 +/- 22 in-lb) |
| Rear roll stopper connection nut | 58 +/- 7 N. m (43 +/- 5 ft-lb) |
| Return tube clamp bolt and nut | 12 +/- 2 N. m (102 +/- 22 in-lb) |
| Stabilizer bracket bolt | 58 +/- 7 N. m (43 +/- 5 ft-lb) |
| Stabilizer link nut | 48 +/- 7 N. m (36 +/- 5 ft-lb) |
| Steering gear and joint connecting bolt | 18 +/- 2 N. m (13 +/- 2 ft-lb) |
| Steering gear and pressure tube flare nut | 15 +/- 3 N. m (11 +/- 2 ft-lb) |
| Steering gear and return tube flare nut | 15 +/- 3 N. m (11 +/- 2 ft-lb) |
| Tie rod to knuckle connection nut | 29 +/- 4 N. m (21 +/- 3 ft-lb) |
| Steering gear and linkage protector bolt | 12 +/- 2 N. m (102 +/- 22 in-lb) |
| Strut assembly | |
| Stabilizer link nut | 48 +/- 7 N. m (36 +/- 5 ft-lb) |
| Strut assembly to body connection nut | 48 +/- 7 N. m (36 +/- 5 ft-lb) |
| Strut assembly to knuckle connection nut | 305 +/- 25 N. m (225 +/- 18 ft-lb) |
| Strut nut (self-locking nut) | 65 +/- 5 N. m (48 +/- 4 ft-lb) |
FASTENER TIGHTENING SPECIFICATIONS
SERVICE SPECIFICATIONS
| ITEM | STANDARD VALUE | |
|---|---|---|
| Toe-in mm (in) | 0 +/- 3 (0 +/- 0.12) | |
| Steering angle | Inner wheel | 31°48' +/- 2°00' |
| Outer wheel (reference) | 27°06' | |
| Camber | 0°00' +/- 30' (Left/right deviation within 30') | |
| Caster | 3°00' +/- 30' (Left/right deviation within 30') | |
| Kingpin inclination | 12°54' +/- 1°30' | |
| Lower arm ball joint breakaway torque N. m (in-lb) | 3.5-6.9 (31-61) | |
| Lower arm bushing press-in pressure kN (lb) | 10 (2,248) or more | |
| Stabilizer link ball joint breakaway torque N. m (in-lb) | 3.4-9.0 (30-80) | |
SERVICE SPECIFICATIONS
