WHEEL BEARING ROTATION STARTING TORQUE AND AXIAL PLAY CHECK
Required Special Tools
- MB990998: Front Hub Remover and Installer
- MB991000: Spacer
- MB990326: Preload Socket
- MB990685: Torque Wrench
Scheme 1
Scheme 2
Scheme 3
- Install special tools MB991000, MB990998 and tighten them to the specified torque. Tightening torque: 226 +/- 29 N.m (167 +/- 21 ft-lb)
- Hold front wheel hub assembly in a vice, using wooden blocks.
- Rotate the hub in order to seat the bearing.
- Measure the wheel bearing rotation starting torque by using the special tools MB990326 and MB990685. Limit: 1.4 N.m (12 in-lb)
- If the rotation starting torque is not within the limit when the nut is tightened to 226 +/- 29 N.m (167 +/- 21 ft-lb), replace the front wheel bearing assembly. If there is any signs of binding or tight spots when the wheel bearing turns, replace it.
- Measure to determine whether the wheel bearing axial play is within the specified limit or not. Limit: 0.05 mm (0.002 inch)
- If the play exceeds the limit when the nut is tightened to 226 +/- 29 N.m (167 +/- 21 ft-lb), replace the front wheel hub assembly.
Scheme 4
Required Special Tools
- MB990242: Puller Shaft Puller
- MB990244: Puller Bar
- MB990767: Front Hub and Flange Yoke Holder
- MB990998: Front Hub Remover and Installer
- MB991000: Spacer
- MB991354: Puller Body
- MB991897: Ball Joint Remover
FASTENER TIGHTENING SPECIFICATIONS
| ITEM | SPECIFICATION |
|---|---|
| Caliper assembly bolt | 100 +/- 10 N.m (74 +/- 7 ft-lb) |
| Center bearing bracket bolt < 3.8L-RH > | 41+/- 4 N. m (30 +/- 3 ft-lb) |
| Drive shaft nut | 226 +/- 29 N. m (167 +/- 21 ft-lb) |
| Dust cover bolt | 9.0 +/- 2.0 N. m (80 +/- 17 in-lb) |
| Front strut nut | 305 +/- 25 N. m (225 +/- 18 ft-lb) |
| Front wheel hub bolt | 90 +/- 10 N. m (67 +/- 7 ft-lb) |
| Self-locking nut (lower arm ball joint connection) | 65 +/- 6 N. m (48 +/- 4 ft-lb) |
| Self-locking nut (tie rod end connection) | 29 +/- 4 N. m (21 +/- 3 ft-lb) |
FASTENER TIGHTENING SPECIFICATIONS
GENERAL SPECIFICATIONS
| ITEM | SPECIFICATION | ||
|---|---|---|---|
| Wheel bearing | Type | Unit ball bearing (Double-row angular contact ball bearing) | |
| Drive shaft | Joint type | Outer | BJ (Birfield Joint) < 2.4L engine >, EBJ (Eight Ball Fixed Joint) < 3.8L engine > |
| Inner | TJ (Tripod Joint) < 2.4L engine >, PTJ (Pillow Tripod Joint) < 3.8L engine > | ||
GENERAL SPECIFICATIONS
SERVICE SPECIFICATIONS
| ITEM | STANDARD VALUE | LIMIT | |
|---|---|---|---|
| Wheel bearing end play mm (in) | 0.05 (0.002) | ||
| Wheel bearing rotation starting torque N. m (in-lb) | 1.4 (12) | ||
| Setting of TJ/PTJ boot length mm (in) | 85 +/- 3 (3.35 +/- 0.12) | ||
| Opening dimension of the special tool (MB991561) mm (in) | When the BJ/EBJ boot band (small) is crimped | 2.9 (0.11) | |
| When the BJ/EBJ boot band (large) is crimped | 2.9 (0.11) | ||
| Crimped width of the BJ/EBJ boot band mm (in) | 2.4 - 2.8 (0.09 - 0.11) | ||
SERVICE SPECIFICATIONS
