SPECIAL TOOLS
SPECIAL TOOLS CHART TOOL TOOL NUMBER AND NAME SUPERSESSION APPLICATION MB990767 Front hub and flange yoke holder MB990767-01 Fixing of the hub MB991618 Hub bolt remover General service tool Removal of the hub bolt MB991897 Ball joint remover MB991113-01, MB990635-01 or General service tool Knuckle and tie rod end ball joint disconnection NOTE: Steering linkage puller (MB990635 or MB991113) is also used to disconnect knuckle and tie rod end ball joint. MB990241 Axle shaft puller A: MB990242 Puller shaft B: MB990244 Puller bar MB990241-01 or General service tool Removal of the drive shaft MB991354 Puller body General service tool MB990590 Rear axle shaft oil seal remover A: MB990212 Adapter B: MB990211 Slide hammer MB990211-01 Removal of the front wheel hub A: MB991017 B: MB990998 C: MB991000 A, B: Front hub remover and installer C: Spacer MB990998-01 Removal of the hub Provisional holding of the wheel bearing Measurement of hub starting torque Measurement of wheel bearing end play NOTE: MB991000, which belongs to MB990998, should be used as a spacer. MB990685 Torque wrench General service tool Measurement of hub starting torque MB990326 Preload socket General service tool MB990810 Side bearing puller General service tool Removal of the center bearing bracket Removal of the wheel bearing inner race (outside) MB991172 Inner shaft installer base - Press-fitting of the inner shaft MB991248 Inner shaft remover MD998348-01 or General service tool Removal of the inner shaft MD998369 Bearing installer - Installation of the seal plate MB991561 Boot band crimping tool MB991561 BJ boot (resin boot) band installation MB990925 Bearing and oil seal installer set MB990925-01 or General service tool Removal and installation of the center bearing Press-fitting of the dust seal outer, inner MB990890 Rear suspension bushing base MB990890-01 Press-fitting of the dust seal outer, inner
Scheme 58
Scheme 59
Scheme 60
Scheme 61
Scheme 62
Scheme 63
Scheme 64
Scheme 65
Scheme 66
Scheme 67
Scheme 68
Scheme 69
Scheme 70
Scheme 71
Scheme 72
Scheme 73
TOOL DIMENSION CHART TOOL TYPE TOOL NUMBER O D mm (in) A MB990926 39.0 (1.54) MB990927 45.0 (1.77) MB990928 49.5 (1.95) MB990929 51.0 (2.00) MB990930 54.0 (2.13) MB990931 57.0 (2.24) MB990932 61.0 (2.40) MB990933 63.5 (2.50) MB990934 67.5 (2.66) MB990935 71.5 (2.81) MB990936 75.5 (2.97) MB990937 79.0 (3.11) B MB990938 - C MB990939
Scheme 74
Scheme 75
- Remove the caliper assembly and suspend it with a wire.
- Remove the brake disc from the front hub.
- Attach a dial gauge as shown in the illustration, and then measure the end play while moving the hub in the axial direction. Limit: 0.05 mm (0.002 inch)
- If end play exceeds the limit, disassemble the front hub assembly and check the parts.
- Install the brake disc, caliper assembly and tighten the caliper assembly mounting bolts to the specified torque. Tightening torque: 100 +/- 10 N.m (74 +/- 7 ft-lb)
