Traction Control System (Tcl): Wiring Mitsubishi Eclipse IV рестайлинг

RESISTANCE AND CONTINUITY BETWEEN HARNESS-SIDE CONNECTOR TERMINALS

Required Special Tool

MB991997: ASC Check Harness

Scheme 335

1. Turn the ignition switch to the "LOCK" (OFF) position and disconnect the ABS/TCL-ECU connectors before checking resistance and continuity.
2. Check the resistance and continuity between the terminals indicated in the table below.
3. The terminal layout is shown in the illustration. CONNECTOR TERMINAL REFERENCE CONNECTOR TERMINAL NO. SIGNAL NORMAL CONDITION 45 - 46 Front-left wheel speed sensor 1.24 - 1.64 kohms 33 - 34 Front-right wheel speed sensor 1.24 - 1.64 kohms 36 - 37 Rear-left wheel speed sensor 1.24 - 1.64 kohms 42 - 43 Rear-right wheel speed sensor 1.24 - 1.64 kohms 16 - body ground Ground Continuity exists (2 ohms or less) 47 - body ground Ground Continuity exists (2 ohms or less)

<< A: HARNESS CONNECTOR DISCONNECTION

Move the lock lever of the ABS/TCL-ECU as shown in the illustration, and then disconnect the harness connector.

Scheme 336
