| Auto-Tensioner Attaching Bolt | 17 (23) |
| Bell Housing Cover Attaching Bolt (Bolt/Flange) | 19 (26) |
| Camshaft Position Sensor Sensing Cylinder Attaching Bolt | 16 (22) |
| Camshaft Position Sensor Support Attaching Bolt | 10 (14) |
| Camshaft Sprocket Attaching Bolt | 65 (88) |
| Connecting Rod Cap Nut |
| Step 1 | 15 (20) |
| Step 2 | Plus Torque Angle 90 Degrees |
| Coolant Temperature Sensor | 21 (29) |
| Counterbalance Shaft Sprocket Bolt | 33 (45) |
| Counterbalance Shaft Tensioner Center Bolt | 14 (19) |
| Crankshaft Damper Bolt | 123 (167) |
| Crankshaft Main Bearing Cap Bolts (1) |
| Step 1 | 18 (25) |
| Step 2 | Plus Torque Angle 90 Degrees |
| Crankshaft Pulley Attaching Bolt | 18 (25) |
| Crankshaft Sprocket Attaching Bolt | 87 (118) |
| Cylinder Head Bolts (2) |
| Step 1 | 58 (78) |
| Step 2 | Loosen Completely |
| Step 3 | 15 (20) |
| Step 4 | Plus Torque Angle 90 Degrees |
| Step 5 | Plus Additional 90 Degrees |
| Drive Belt Adjusting Nut Lock Bolt | 17 (23) |
| Drive Plate/Flywheel Bolt | 97 (132) |
| EGR Valve Bolt | 14 (19) |
| Engine Hanger Bolt | 14 (19) |
| Engine Hanger Nut | 21 (29) |
| Engine Mount Bracket Attaching Bolt |
| M12 x 74 | 63 (86) |
| M12 x 108 | 60 (81) |
| Engine Mount Bracket Attaching Nut | 63 (86) |
| Engine Support Bracket Bolt/Nut | 36 (49) |
| Exhaust Manifold Bracket Attaching Bolt | 26 (35) |
| Exhaust Manifold Cover Bolt | 10 (14) |
| Exhaust Manifold Nut |
| M8 | 21 (29) |
| M10 | 36 (49) |
| Front Case Bolt | 18 (25) |
| Generator Brace Bolt | 18 (25) |
| Generator Pivot Bolt | 32 (44) |
| Heated Oxygen Sensor | 32 (44) |
| Idler Pulley Bolt | 26 (35) |
| Intake Manifold Plenum Bolt/Nut | 15 (20) |
| Intake Manifold Plenum Stay Bolt |
| M8 | 15 (20) |
| M10 | 22 (30) |
| Intake Manifold Stay Attaching Bolt | 22 (30) |
| Knock Sensor | 17 (23) |
| Oil Dipstick Guide Attaching Bolt | 10 (14) |
| Oil Filter | 13 (17) |
| Oil Filter Bracket Bolt | 14 (19) |
| Oil Pan Drain Plug | 29 (39) |
| Oil Pump Sprocket Nut | 40 (54) |
| Oil Screen Bolt | 14 (19) |
| Power Steering Oil Pump Attaching Bolt | 21 (29) |
| Power Steering Oil Pump Bolt | 36 (49) |
| Rocker Arm Shaft Assembly Attaching Bolt | 23 (31) |
| Spark Plugs | 18 (25) |
| Thermostat Housing Bolt | 18 (25) |
| Throttle Body Bolt/Stay Bolt | 14 (19) |
| Timing Belt Tensioner Arm Bolt | 16 (22) |
| Timing Belt Tensioner Pulley Attaching Bolt | 35 (48) |
| Timing Belt Upper Cover Attaching Bolt |
| M6 | (3) |
| M8 | 10 (14) |
| Water Pump Bolt | 10 (14) |
| INCH Lbs. (N.m) |
| Bell Housing Cover Attaching Bolt (Bolt/Washer Assembled) | 80 (9) |
| Camshaft Position Sensor Bolt | 80 (9) |
| Coolant Temperature Gauge Unit | 97 (11) |
| Crankshaft Position Sensor Bolt | 80 (9) |
| Drive Belt Adjusting Bolt | 44 (5) |
| Fuel Pressure Regulator Bolt | 80 (9) |
| Ignition Coil Attaching Bolt | 89 (10) |
| Injectors & Fuel Rail Bolt | 106 (12) |
| Intake Manifold Deferential Pressure Sensor Bolt | 44 (5) |
| Oil Pan Bolts | 80 (9) |
| Oil Pressure Switch | 97 (11) |
| Oil Pump Cover Screw | 89 (10) |
| Oil Seal Case Bolt | 97 (11) |
| PCV Valve | 89 (10) |
| Pressure Hose/Tube Attaching Bolt | 106 (12) |
| Rear Plate Bolt | 97 (11) |
| Rocker Cover Attaching Bolt | 27 (3) |
| Timing Belt Lower Cover Attaching Bolt (Bolt Through Flange) | 97 (11) |
| Timing Belt Lower Cover Attaching Bolt (Bolt & Nut/Washer Assembly) | 80 (9) |
| Water Inlet Fitting Bolt | 115 (13) |
| Water Inlet Pipe Bolt | 115 (13) |
| Water Outlet Fitting Bolt | 115 (13) |
| Water Pump Pulley Attaching Bolt | 80 (9) |
| (1) Tighten according to sequence. (Scheme 218) (2) Tighten according to sequence. see scheme 243 (3) Tighten bolts to 97 INCH lbs. (11 N.m). |
