GENERAL SPECIFICATIONS
| ITEMS | SPECIFICATIONS |
|---|
| Model | F4A42 | F4A51 |
| Type | Electronically controlled 4-speed full-automatic |
| Torque converter | Type | 3-element with torque converter clutch |
| Engine stall speed | 2100 - 2600 r/min | 2100 - 2600 r/min |
| Stall torque ratio | 2.0 | 2.0 |
Identifying General Specifications (1 Of 2)
| ITEMS | SPECIFICATIONS |
|---|
| Gear ratio | 1st | 2.842 | 2.842 |
| 2nd | 1.529 | 1.495 |
| 3rd | 1.000 | 1.000 |
| 4th | 0.712 | 0.731 |
| Reverse | 2.480 | 2.720 |
| Final gear ratio | 4.041 | 3.728 |
Identifying General Specifications (2 Of 2)
Scheme 63
Scheme 63: SERVICE SPECIFICATIONS
Scheme 64
Scheme 64: VALVE BODY SPRING IDENTIFICATION TABLE
Scheme 65
Scheme 65: Thrust washer (For adjustment of input shaft end play)
Scheme 66
Scheme 66: Snap ring < F4A42 > (For adjustment of underdrive clutch and overdrive clutch end play)
Scheme 67
Scheme 67: Snap ring < F4A51 > (For adjustment of underdrive clutch and overdrive clutch end play)
Scheme 68
Scheme 68: Snap ring < F4A42 > (For adjustment of low-reverse brake and second brake reaction plates end play)
Scheme 69
Scheme 69: Snap ring < F4A51 > (For adjustment of low-reverse brake and second brake reaction plates end play)
Scheme 70
Scheme 70: Pressure plate < F4A42 > (For adjustment of low-reverse brake and second brake end play)
Scheme 71
Scheme 71: Pressure plate < F4A51 > (For adjustment of low-reverse brake and second brake end plays).
Scheme 72
Scheme 72: Snap ring < F4A42 > (For adjustment of reverse clutch end play)
Scheme 73
Scheme 73: Snap ring < F4A51 > (For adjustment of reverse clutch end play)
Scheme 74
Scheme 74: Snap ring (For adjustment of reverse clutch and overdrive clutch spring retainer end plays)
Scheme 75
Scheme 75: Thrust race (For adjustment of underdrive sun gear end play)
Scheme 76
Scheme 76: Spacer (For adjustment of output shaft preload)
Scheme 77
Scheme 77: Spacer (For adjustment of differential case preload)
Scheme 78
Scheme 78: Spacer (For adjustment of backlash between differential side gear and pinion)
