>>E<< SEALANT APPLICATION TO ENGINE COOLANT TEMPERATURE GAUGE UNIT

Apply 3M TM AAD Part number 8672 or equivalent to the engine coolant temperature gauge unit.

Scheme 384: >>E<< SEALANT APPLICATION TO ENGINE COOLANT TEMPERATURE GAUGE UNIT

Apply 3M TM AAD Part number 8731 or equivalent to the engine coolant temperature sensor.

Scheme 385: >>F<< SEALANT APPLICATION TO ENGINE COOLANT TEMPERATURE SENSOR

Scheme 386: REMOVAL AND INSTALLATION

Scheme 387: >>A<< WATER OUTLET FITTING INSTALLATION

Apply a 3 mm (0.1 inch) diameter bead of sealant. (MITSUBISHI Genuine Part number MD970389) to the groove as shown in the illustration.
Install the housing quickly (within 15 minutes) while the sealant is wet and tighten the bolts to the specified torque. Tightening torque: 13 +/- 2 N.m (113 +/- 17 in-lb) NOTE: After installation, keep the sealed area away from the coolant for approximately one hour.

Scheme 388: REMOVAL AND INSTALLATION

Required Special Tools

CAUTION

Be careful not to block the oil passage with sealant.

Apply 3M TM AAD Part number 8672 or equivalent to the threads of the oil pressure switch.
Tighten the switch to the specified torque. Tightening torque: 19 +/- 3 N.m (14 +/- 2 ft-lb)
