0496107 118730 Adapter Minimum set: Mechanical tools MW

Note. For compression testing.

Storage Location

C23

SI number

01 04 07 (352)

Consisting of

1 = 0496305 Adapter

2 = 0496306 Ring

Note. (Sealing ring) For secure connection of test probe 11 0 222 and adapter 11 8 730/731.

Scheme 271

0495927 119560 Adapter Minimum set: Mechanical tools MW

Note. For oil pressure testing.

A86

01 26 06 (321)

Scheme 272

0496016 119630 Angle Minimum set: Mechanical tools MW

Note. (Support angle) For supporting the engine when dismantling the cylinder head.

01 14 07 (389)

Scheme 273

0495948 119620 Assembly tool MW

Note. For installing piston with connecting rod in crankcase.

A85

01 26 06 (321)

Scheme 274

0495958 119670 Bush MW

Note. (assembly bush) For installing piston in crankcase.

01 26 06 (321)

Scheme 275

0493249 116380 Bush Minimum set: Mechanical tools MW

Note. For fitting valve stem seal

B15

01 06 98 (306)

Scheme 276

0490613 110220 Compression tester Minimum set: Mechanical tools MW

Note. (Compression pressure testing set) For all petrol and diesel engines.

01 09 92 (558)

Consisting of

4 = 0490620 Probe

Note. (Test probe) For recording compression testers 11 0 224 and 11 0 160/engine: S14, S38, S50 - Replaced by 11 0 235 (0 493 129)

Scheme 277

4 = 0490616 Card

Note. (Cards) 100 pieces For recording compression tester 11 0 221

4 = 0490622 Card

Note. (Cards) 100 pieces For recording compression tester 11 0 224

2 = 0494517 Adapter

Note. Measuring "absolute compression" at all cylinders. Engine: W17

2 = 0493634 Case

Note. With foam material insert for recording compression tester

16 = 0495279 Adapter

Note. M67, M67TU engine

4 = 0490614 Compression tester

Note. (Compression tester) For diesel engines.

4 = 0490615 Probe

Note. (Test probe) For recording compression testers 11 0 221 and 11 0 160/engine: M21, M41, M47, M51, M57, M57T2

4 = 0490617 Compression tester

Note. (Compression tester) For petrol engines.

4 = 0490618 Hose

Note. (Extension hose) For rubber tapered section with fitting 11 0 228

4 = 0490619 Probe

Note. (Test probe) For recording compression testers 11 0 224 and 11 0 160/engine: M10, M20, M30, M40, M42, M43, M44, M50, M52, M60, M62, M70, M73, N62, S50US, S52US, S62

4 = 0490621 Tapered section

Note. (Rubber tapered section) For recording compression testers 11 0 224 and 11 0 160.

4 = 0490625 Valve

Note. (Non-return valve)

4 = 0490626 Filter

Note. (Filter) 3 x 3 mm

9 = 0493129 Probe

Note. (Test probe, screw-in) For measuring "absolute compression" at all cylinders, engine: S14, S38, S50B30, S50B32, S50US, S52US, S54, S85

2 = 0493387 Probe

Note. (Test probe) For recording compression tester 11 0 221 or DIS pressure sensor/engine: M47, M57, M57TU, M57T2

0495940 119600 Device Minimum set: Mechanical tools MW

Note. (Pulling device) For installing front crankshaft seal.

C85

01 26 06 (321)

Consisting of

1 = 0495941 Basic body

2 = 0495942 Sleeve

Note. (Pressure sleeve)

Scheme 278

3 = 0495943 Nut

Note. (Nut with bearing)

0495944 119610 Device Minimum set: Mechanical tools MW

Note. (pulling device) For fitting the rear shaft seal of the crankshaft.

C85

C86

01 26 06 (321)

Consisting of

1 = 0495945 Basic body

2 = 0495946 Sleeve

Note. (Pressure sleeve)

Scheme 279

3 = 0495947 Nut

Note. (Nut with bearing)

0495955 119660 Device MW

Note. (Press down device) For pressing down the camshaft when removing or fitting.

01 26 06 (321)

Consisting of

1 = 0495956 Basic body

2 = 0495957 Bolt

Note. (Set of screws)

Scheme 280

0495919 119520 Device MW

Note. (Pressure testing fixture) For leakage test of cylinder head.

01 26 06 (321)

Consisting of

1 = 0495920 Plate

Note. (base plate with seal)

2 = 0495921 Plate

Note. (Adapter plate with seal)

Scheme 281

3 = 0495922 Screw

Note. (set of screws)

4 = 0495923 Seal

Note. (Spare seal for base plate)

5 = 0495924 Seal

Note. (Spare seal for adapter plate)

0494362 119000 Device Minimum set: Mechanical tools MW

Note. (Cylinder head expander tool)

Individual

01 03 02 (833)

Consisting of

17 = 0495028 Cage

Note. (Valve spring cage) Engine N52

1 = 0494366 Device

Scheme 282

5 = 0494370 Quick fastener

7 = 0494372 Shaped part

Note. (Shaped part)

8 = 0494373 Shaped part

Note. (Shaped part) Shaped part made of plastic

9 = 0494374 Lever

2 = 0494367 Rod

3 = 0494368 Adapter

Note. (Sliding block)

4 = 0494369 Tab

6 = 0494371 Insert

Note. (Aluminium strip)

10 = 0494375 Hook

11 = 0494376 Cage

Note. (Valve spring cage) Engine M41, M51, S50

12 = 0494377 Cage

Note. (Valve spring cage) Engine M43, M73

13 = 0494378 Cage

Note. (Valve spring cage) Engine M44, M52, M54, M56, M62, S52, S54, S62

14 = 0494379 Cage

Note. (Valve spring cage) Engine M47, M47TU, M57, M57TU, N40, N42, N62, N73

15 = 0494380 Cage

Note. (Valve spring cage) Engine M21, M40

0493971 119340 Device Minimum set: Mechanical tools MW

Note. (Device) For tensioning timing chain when adjusting timing

B43

01 01 01 (662)

Consisting of

1 = 0494032 Bolt

2 = 0494033 Spindle

Scheme 283

0493751 119150 Extension Minimum set: Mechanical tools MW

Note. (Socket wrench extension) For loosening and tightening the oxygen sensor

A42

01 15 00 (609)

Scheme 284

0496200 119680 Fitting aid Minimum set: Mechanical tools MW

Note. (Mounting tool) For installing the ribbed belt (elastic belt) of the alternator. For vehicles without heating and air conditioning systems only.

01 17 07 (393)

Scheme 285

0490646 110340 Fitting aid MW

Replaced by: 0494362

Note. (fitting accessories) For removing and fitting the valve springs. Replaced by 11 9 000 (0 494 362)

01 12 93 (701)

Consisting of

3 = 0490649 Hook

Note. (hook) Length 220 mm - Engine: all, except M10 Replaced by 11 9 000 (0 494 362)

Scheme 286

5 = 0490651 Cage

Note. (Valve spring cage) Engine: M44, M52, M62, S62, S54 Replaced by 11 9 000 (0 494 362)

1 = 0490647 Cage

Note. (Valve spring cage) Engine: M43, M73

2 = 0490648 Lever

Note. (compression lever) Engine: all, except M10

6 = 0493285 Cage

Note. (Valve spring cage) Engine: M47, M47TU, M57, N40, N42, M67, M67TU

4 = 0490650 Cage

Note. (valve spring cage) Replaced by 11 0345, engine: M52

0495926 119550 Gauge Minimum set: Mechanical tools MW

Note. For locating camshaft in TDC position.

A86

01 26 06 (321)

Consisting of

1 = 0495936 Gauge

2 = 0495937 Holder

Note. (counter support)

3 = 0495938 Screw

Note. (set of screws)

Scheme 287

0493940 119280 Holder Minimum set: Mechanical tools MW

Note. (Counter support) For the crankshaft when releasing/tightening the central bolt

B43

C43

A43

01 01 01 (662)

Scheme 288

Scheme 289

Scheme 290

Scheme 291

Scheme 292

0496775 116210 Lever Minimum set: Mechanical tools MW

Note. Clamping lever for (dis)assembly of the drive belt.

01 33 09 (612)

Consisting of

1 = 0496818 Lever

Note. Engine: N12&N14 -> WAF 21 with 12 edges

2 = 0496819 Lever

Note. Engine: N16&N18 -> WAF 30 with 6 edges

Scheme 293

0490561 110000 Lifting gear Minimum set: Mechanical tools MW

Note. (Hoist) For removing and installing engines.

01 13 94 (888)

Consisting of

1 = 0490562 Lifting gear

Note. (Cross-member)

2 = 0490563 Chain

Note. (Chain) Version: long

Scheme 294

3 = 0490564 Chain

Note. (Chain) Version: short

4 = 0490565 Shackle

Note. (Shackle) 2 x

0490567 110020 Lifting gear Minimum set: Mechanical tools MW

Note. For removing and installing engines.

01 13 94 (888)

Consisting of

1 = 0490568 Lifting gear

Note. (Cross-member)

2 = 0490569 Chain

Note. (Chain)

Scheme 295

3 = 0490570 Chain

Note. (Chain) Version: long

4 = 0490571 Chain

Note. (Chain) Version: short

5 = 0490572 Shackle

Note. (Shackle) 2 pieces

0495939 119590 Mandrel Minimum set: Mechanical tools MW

Note. (Alignment pin) For locating crankshaft in TDC setting.

C85

01 26 06 (321)

Scheme 296

0495105 114480 Oddments tray Minimum set: Mechanical tools MW

Note. (Boards (2 pieces)) For setting down the individual components of the cylinder head.

01 17 04 (130)

Consisting of

1 = 0495106 Oddments tray

Note. (Board for intake side)

2 = 0495107 Oddments tray

Note. (Board for exhaust side)

Scheme 297

0492027 322100 Open-end spanner MW

Note. (open-end spanner WAF 27) For adjusting left track rod on rack

Y4

Scheme 298

0495916 119530 Plate MW

Note. (Engine fixture) For supporting the engine on the assembly stand.

01 26 06 (321)

Consisting of

1 = 0495917 Plate

Note. (Engine fixture)

2 = 0495918 Bolt

Note. (Set of screws)

Scheme 299

0490796 111480 Pliers Minimum set: Mechanical tools MW

Note. For removing valve stem seal

B10

01 01 93 (621)

Scheme 300

Scheme 301

Scheme 302

0495932 119580 Socket ring spanner Minimum set: Mechanical tools MW

Note. For removing and fitting friction gear and auxiliary water pump.

A85

01 26 06 (321)

Consisting of

3 = 0495935 Socket

Note. (socket, width across flats 10)

Scheme 303

1 = 0495933 Ring spanner

2 = 0495934 Socket

Note. (socket, width across flats 8)

0491074 117020 Wrench socket Minimum set: Mechanical tools MW

Note. (Wrench socket 22 mm) For loosening and tightening the oxygen sensor
