Inspection and Verification
- Verify the customer concern.
- Visually inspect for obvious signs of mechanical or electrical damage. VISUAL INSPECTION CHART Electrical Smart junction box (SJB) fuse(s): 9 (15A) 10 (15A) 25 (10A) Wiring, terminals or connectors Courtesy lamps Map lamps Puddle lamps Luggage compartment lamp Vanity lamps Overhead console Instrument panel dimmer switch (part of the headlamp switch) SJB
- If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
- If the cause is not visually evident, connect the scan tool to the data link connector (DLC).
- If the scan tool does not communicate with the VCM: Check the VCM connection to the vehicle. Check the scan tool connection to the VCM. Refer to «MODULE COMMUNICATIONS NETWORK»(ref-293472) article, No Power To The Scan Tool, to diagnose no communication with the scan tool.
- If the scan tool does not communicate with the vehicle: Verify the ignition key is in the ON position. Verify the scan tool operation with a known good vehicle. Refer to «MODULE COMMUNICATIONS NETWORK»(ref-293472) article to diagnose no response from the PCM.
- Carry out the network test. If the scan tool responds with no communication with the SJB or liftgate/trunk module (LTM) (if equipped), refer to «MODULE COMMUNICATIONS NETWORK»(ref-293472) article. If the network test passes, retrieve and record the continuous memory DTCs.
- Clear the continuous DTCs and carry out the self-test diagnostics for the SJB and the LTM (if equipped).
- If the DTCs retrieved are related to the concern, refer to DTC Tables. For all other DTCs, refer to «MULTIFUNCTION ELECTRONIC MODULES»(ref-293473) article.
- If no DTCs related to the concern are retrieved, go to «Symptom Chart»(ref-293474-S00680275162008080700000) .
DTC Tables
| DTC | Description | Action |
|---|---|---|
| B1320 | Driver Door Ajar Circuit Open | Go to Pinpoint Test B . |
| B1328 | Passenger Door Ajar Circuit Open | Go to Pinpoint Test B . |
| B1331 | Decklid Ajar Rear Door Circuit Failure | Go to Pinpoint Test K . |
| B1336 | Door Ajar RR Circuit Open | Go to Pinpoint Test B . |
| B1572 | Door Ajar LR Circuit Open | Go to Pinpoint Test B . |
| B1688 | Lamp Dome Input Circuit Short to Ground | Go to Pinpoint Test B . |
| B2077 | Liftgate Ajar Sw Circuit Failure | Go to Pinpoint Test B . |
| B2A35 | Interior Lighting Output Circuit Open | If the courtesy lamps are inoperative, go to Pinpoint Test A . If the courtesy lamps stay on continuously, go to Pinpoint Test B . |
| B2A36 | Interior Lighting Output Circuit Short to Ground | Go to Pinpoint Test A . |
| B2A3A | Puddle Lamp Output Circuit Short to Ground | Go to Pinpoint Test G . |
| B2A39 | Puddle Lamp Output Circuit Open | If the puddle lamps are inoperative, go to Pinpoint Test G . If the puddle lamps are always on, go to Pinpoint Test H . |
| All other DTCs | REFER to MULTIFUNCTION ELECTRONIC MODULES article. |
SMART JUNCTION BOX (SJB) DTC TABLE
| DTC | Description | Action |
|---|---|---|
| B2718 | Liftgate/Decklid Ajar Output Short to Battery | Go to Pinpoint Test B . |
| B2721 | Liftgate/Decklid Ajar Output Short to Ground or Open | If interior lamps are inoperative, go to Pinpoint Test E . If interior lamps are always on, go to Pinpoint Test B . |
| All other DTCs | REFER to MULTIFUNCTION ELECTRONIC MODULES article. |
LIFTGATE/TRUNK MODULE (LTM) DTC TABLE
Symptom Chart
| Condition | Possible Sources | Action |
|---|---|---|
| No communication with the smart junction box (SJB) | Wiring, terminals or connectors SJB | REFER to MODULE COMMUNICATIONS NETWORK article. |
| No communication with the liftgate/trunk module (LTM) | Wiring, terminals or connectors LTM | REFER to MODULE COMMUNICATIONS NETWORK article. |
| The courtesy lamps flash on and off | The SJB is not configured correctly. | CONFIGURE the SJB. REFER to MODULE CONFIGURATION article. TEST the system for normal operation. |
| The courtesy lamps are inoperative | Fuse Wiring, terminals or connectors SJB | Go to Pinpoint Test A . |
| The courtesy lamps stay on continuously | Wiring, terminals or connectors Door ajar switch Liftgate ajar switch Instrument panel dimmer switch (part of the headlamp switch) LTM SJB | Go to Pinpoint Test B . |
| An individual courtesy lamp is inoperative | Wiring, terminals or connectors Interior lamp | Go to Pinpoint Test C . |
| The courtesy lamps do not turn on with one door open | Wiring, terminals or connectors Door ajar switch SJB | Go to Pinpoint Test D . |
| The courtesy lamps do not turn on with the liftgate open | Wiring, terminals or connectors Liftgate ajar switch Rear wiper motor LTM SJB | Go to Pinpoint Test E . |
| The courtesy lamps are inoperative - from the dimmer switch | Wiring, terminals or connectors Instrument panel dimmer switch (part of the headlamp switch) SJB | Go to Pinpoint Test F . |
| The puddle lamp(s) are inoperative | Fuse Wiring, terminals or connectors Exterior mirror Puddle lamp SJB | Go to Pinpoint Test G . |
| The puddle lamps stay on continuously | Wiring, terminals or connectors SJB | Go to Pinpoint Test H . |
| The demand lamps are inoperative | Fuse Wiring, terminals or connectors SJB | Go to Pinpoint Test I . |
| An individual demand lamp is inoperative | Wiring, terminals or connectors Interior lamp | Go to Pinpoint Test J . |
| The luggage compartment lamp is inoperative/does not operate correctly | Wiring, terminals or connectors Luggage compartment lamp Luggage compartment lid latch | Go to Pinpoint Test K . |
| The battery saver does not deactivate after time-out | Wiring, terminals or connectors SJB | Go to Pinpoint Test L . |
| The illuminated entry is inoperative when using the integrated keyhead transmitter (IKT) | IKT system SJB | Operate the door locks from the IKT. If the door locks operate correctly, INSTALL a new SJB. REFER to MULTIFUNCTION ELECTRONIC MODULES article. TEST the system for normal operation. If the door locks do not operate correctly, REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS article. |
Symptom Chart
Pinpoint Test A: The Courtesy Lamps Are Inoperative
Refer to appropriate SYSTEM WIRING DIAGRAMS article, Interior Lamps for schematic and connector information.
| CAUTION | Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector. |
Scheme 3
- A1 CHECK CIRCUIT VLN33 (GY/VT) FOR AN OPEN Key in OFF position. Disconnect: SJB C2280a NOTE: If the jumper wire fails, repair circuit VLN33 for a short to ground. Connect a fused (5A) jumper wire between the SJB C2280a-9, circuit VLN33 (GY/VT), harness side and battery positive. Do the courtesy lamps illuminate? YES : VERIFY the SJB fuse 9 (15A) is OK. If OK, go to A2 . NO : REPAIR the circuit. RUN the on-demand self-test (required to clear certain DTCs). CORRECT any unresolved DTCs. CLEAR all DTCs. TEST the system for normal operation.
- A2 CHECK FOR CORRECT SJB OPERATION Disconnect all the SJB connectors. Check for: corrosion damaged pins pushed-out pins Connect all the SJB connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new SJB. REFER to «MULTIFUNCTION ELECTRONIC MODULES»(ref-293473) article. TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.
Pinpoint Test B: The Courtesy Lamps Stay On Continuously
Refer to appropriate SYSTEM WIRING DIAGRAMS article, Interior Lamps for schematic and connector information.
Refer to appropriate SYSTEM WIRING DIAGRAMS article, Remote Keyless Entry and Alarm for schematic and connector information.
| CAUTION | Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector. |
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
- B1 CHECK THE SJB DTCs FROM BOTH THE CONTINUOUS AND THE ON-DEMAND SELF-TESTS Use the recorded results from the SJB continuous and the on-demand self-test. Are any SJB DTCs recorded? YES : For DTCs B1320, B1328, B1336, or B1572, go to B2 . For DTC B1688, go to B5 . For DTC B2A35, go to B7 . For DTC B2077 (manual liftgate), go to B8 . For DTC B2077 (power liftgate), go to B12 . NO : If equipped with a power liftgate, go to B11 . If equipped with a manual liftgate, go to B14 .
- B2 CHECK THE DOOR AJAR GROUND CIRCUITS FOR AN OPEN Key in OFF position. Disconnect: Suspect Door Ajar Switch Measure the resistance between the suspect door ajar switch connector, harness side and ground as follows: Location Connector-Pin Circuit LF C526-1 GD133 (BK) RF C602-1 GD148 (BK/YE) LR C715-1 GD147 (BK/VT) RR C820-1 GD148 (BK/YE) Is the resistance less than 5 ohms? YES : Go to B3 . NO : REPAIR the circuit in question. CLEAR the DTCs. REPEAT the self-test.
- B3 CHECK THE DOOR AJAR INPUT CIRCUITS FOR VOLTAGE Measure the voltage between the suspect door ajar switch, harness side and ground as follows: Location Connector-Pin Circuit LF C526-2 CPL26 (GN/VT) RF C602-2 CPL31 (WH) LR C715-2 CPL36 (GN) RR C820-2 CPL39 (YE) Is the voltage greater than 10 volts? YES : INSTALL a new door ajar switch in question. REFER to «HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS»(ref-293464) article. CLEAR the DTCs. REPEAT the self-test. NO : Go to B4 .
- B4 CHECK THE DOOR AJAR SWITCH CIRCUIT FOR AN OPEN Disconnect: SJB C2280c Measure the resistance between the suspect door ajar switch, harness side and the SJB, harness side as follows: Location SJB Connector- Pin Suspect Door Ajar Switch Connector- Pin Circuit LF C2280c-14 C526-2 CPL26 (GN/VT) RF C2280c-2 C602-2 CPL31 (WH) LR C2280c-3 C715-2 CPL36 (GN) RR C2280c-15 C820-2 CPL39 (YE) Is the resistance less than 5 ohms? YES : Go to B14 . NO : REPAIR the circuit in question. CLEAR the DTCs. REPEAT the self-test.
- B5 CHECK THE INSTRUMENT PANEL DIMMER SWITCH Key in OFF position. Disconnect: Instrument Panel Dimmer Switch C2065 Are the courtesy lamps still illuminated? YES : Go to B6 . NO : INSTALL a new headlamp switch. REFER to «EXTERIOR LIGHTING»(ref-293485) article. CLEAR the DTCs. REPEAT the self-test.
- B6 CHECK CIRCUIT CLN28 (GN/BU) FOR A SHORT TO GROUND Disconnect: SJB C2280b Measure the resistance between the instrument panel dimmer switch C2065-5, circuit CLN28 (GN/BU), harness side and ground. Is the resistance greater than 10,000 ohms? YES : Go to B14 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the self-test.
- B7 CHECK CIRCUIT VLN33 (GY/VT) FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: SJB C2280a Key in ON position. Observe the courtesy lamps. Are the courtesy lamps still illuminated? YES : REPAIR the circuit. CLEAR the DTCs. REPEAT the self-test. NO : Go to B14 .
- B8 CHECK CIRCUIT GD147 (BK/VT) FOR AN OPEN (MANUAL LIFTGATE) Key in OFF position. Disconnect: Liftgate Latch C4185 Measure the resistance between the liftgate latch C4185-3, circuit GD147 (BK/VT), harness side and ground. Is the resistance less than 5 ohms? YES : Go to B9 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the self-test.
- B9 CHECK THE LIFTGATE AJAR SWITCH (MANUAL LIFTGATE) Connect a (5A) jumper wire between the liftgate latch C4185-4, circuit CPL58 (GY/OG), harness side and the liftgate latch C4185-3, circuit GD147 (BK/VT), harness side. Do the courtesy lamps turn off? YES : INSTALL a new liftgate latch. REFER to «HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS»(ref-293464) article. CLEAR the DTCs. REPEAT the self-test. NO : LEAVE the jumper wire connected. Go to B10 .
- B10 CHECK CIRCUIT CPL58 (GY/OG) FOR AN OPEN (MANUAL LIFTGATE) Disconnect: SJB C2280c Measure the resistance between the SJB C2280c-16, circuit CPL58 (GY/OG) harness side, and ground. Is the resistance less than 5 ohms? YES : REMOVE the jumper wire. Go to B14 . NO : REMOVE the jumper wire. REPAIR the circuit. CLEAR the DTCs. REPEAT the self-test.
- B11 CHECK THE LTM DTCs FROM BOTH THE CONTINUOUS AND THE ON-DEMAND SELF-TESTS Use the recorded results from the LTM continuous and the on-demand self-test. Are any LTM DTCs recorded? YES : For DTCs B2718 or B2721, go to B12 . For all other DTCs, REFER to «MULTIFUNCTION ELECTRONIC MODULES»(ref-293473) article. NO : Go to B14 .
- B12 CHECK THE LTM Key in OFF position. Disconnect: LTM C4174a NOTE: If the fuse fails, repair the circuit for a short to voltage. Connect a fused (5A) jumper wire between the LTM C4174a-2, circuit CPL58 (GY/OG), harness side and ground. Do the courtesy lamps turn off? YES : REMOVE the jumper wire. Go to B15 . NO : LEAVE the jumper wire connected. Go to B13 .
- B13 CHECK CIRCUIT CPL58 (GY/OG) FOR AN OPEN (POWER LIFTGATE) Disconnect: SJB C2280c Measure the resistance between the SJB C2280c-16, circuit CPL58 (GY/OG), harness side and ground. Is the resistance less than 5 ohms? YES : REMOVE the jumper wire. Go to B14 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the self-test.
- B14 CHECK FOR CORRECT SJB OPERATION Disconnect all the SJB connectors. Check for: corrosion damaged pins pushed-out pins Connect all the SJB connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new SJB. REFER to «MULTIFUNCTION ELECTRONIC MODULES»(ref-293473) article. TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.
- B15 CHECK FOR CORRECT LTM OPERATION Disconnect all the LTM connectors. Check for: corrosion damaged pins pushed-out pins Connect all the LTM connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new LTM. REFER to «BODY CLOSURES»(ref-293463) article. TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.
Pinpoint Test C: An Individual Courtesy Lamp Is Inoperative
Refer to appropriate SYSTEM WIRING DIAGRAMS article, Interior Lamps for schematic and connector information.
| CAUTION | Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector. |
- C1 CHECK THE INTERIOR LAMP Key in OFF position. Disconnect: Suspect Interior Lamp Open the driver door. Measure the voltage between the suspect interior lamp connector, harness side as follows: Location Connector-Pin/ Circuit Connector-Pin/ Circuit Overhead console C9013-2 VLN33 (GY/VT) C9013-1 GD133 (BK) 2nd row interior lamp C961-1 VLN33 (GY/VT) C961-2 GD147 (BK/VT) 3rd row interior lamp C963-1 VLN33 (GY/VT) C963-2 GD147 (BK/VT) Is the voltage greater than 10 volts? YES : INSTALL a new interior lamp for the lamp in question. REFER to «Interior Lamp»(ref-293474-S17652100562008080700000) . TEST the system for normal operation. NO : Go to C2 .
- C2 CHECK CIRCUIT VLN33 (GY/VT) FOR AN OPEN Measure the voltage between the suspect interior lamp, harness side and ground as follows: Location Connector-Pin Circuit Overhead console C9013-2 VLN33 (GY/VT) 2nd row interior lamp C961-1 VLN33 (GY/VT) 3rd row interior lamp C963-1 VLN33 (GY/VT) Is the voltage greater than 10 volts? YES : REPAIR the ground circuit for the lamp in question. TEST the system for normal operation. NO : REPAIR circuit VLN33 (GY/VT) for the lamp in question. TEST the system for normal operation.
Pinpoint Test D: The Courtesy Lamps Do Not Turn On With One Door Open
Refer to appropriate SYSTEM WIRING DIAGRAMS article, Remote Keyless Entry and Alarm for schematic and connector information.
| CAUTION | Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector. |
- D1 CHECK THE DOOR AJAR PIDs Key in ON position. Enter the following diagnostic mode on the diagnostic tool: SJB DataLogger Check the SJB door ajar switch PIDs while opening and closing all the doors. Do all the door ajar switch PID values agree with the door positions? YES : Go to D4 . NO : Go to D2 .
- D2 CHECK THE DOOR AJAR SWITCH OPERATION Disconnect: Suspect Door Ajar Switch Do the courtesy lamps illuminate? YES : INSTALL a new door ajar switch in question. REFER to «HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS»(ref-293464) article. TEST the system for normal operation. NO : Go to D3 .
- D3 CHECK THE DOOR AJAR SWITCH CIRCUIT FOR A SHORT TO GROUND Key in OFF position. Disconnect: SJB C2280c Measure the resistance between the suspect door ajar switch, harness side and ground as follows: Location Connector-Pin Circuit LF C526-2 CPL26 (GN/VT) RF C602-2 CPL31 (WH) LR C715-2 CPL36 (GN) RR C820-2 CPL39 (YE) Is the resistance greater than 10,000 ohms? YES : Go to D4 . NO : REPAIR the circuit in question. TEST the system for normal operation.
- D4 CHECK FOR CORRECT SJB OPERATION Disconnect all the SJB connectors. Check for: corrosion damaged pins pushed-out pins Connect all the SJB connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new SJB. REFER to «MULTIFUNCTION ELECTRONIC MODULES»(ref-293473) article. TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.
Pinpoint Test E: The Courtesy Lamps Do Not Turn On With the Liftgate Open
Refer to appropriate SYSTEM WIRING DIAGRAMS article, Remote Keyless Entry and Alarm for schematic and connector information.
| CAUTION | Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector. |
- E1 CHECK THE LTM OR THE LIFTGATE LATCH Key in OFF position. Disconnect: LTM C4174a or Liftgate Latch C4185 Do the courtesy lamps illuminate? YES : If equipped with a power liftgate, go to E5 . If equipped with a manual liftgate, INSTALL a new liftgate latch. REFER to «HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS»(ref-293464) article. TEST the system for normal operation. NO : Go to E2 .
- E2 CHECK THE REAR WIPER MOTOR Disconnect: Rear Wiper Motor C476 Do the courtesy lamps illuminate? YES : INSTALL a new rear wiper motor. REFER to «WIPERS AND WASHERS»(ref-293471) article. TEST the system for normal operation. NO : Go to E3 .
- E3 CHECK CIRCUIT CPL58 (GY/OG) FOR A SHORT TO GROUND Disconnect: SJB C2280c Measure the resistance between the SJB C2280c-16, circuit CPL58 (GY/OG), harness side and ground. Is the resistance greater than 10,000 ohms? YES : Go to E4 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the self-test.
- E4 CHECK FOR CORRECT SJB OPERATION Disconnect all the SJB connectors. Check for: corrosion damaged pins pushed-out pins Connect all the SJB connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new SJB. REFER to «MULTIFUNCTION ELECTRONIC MODULES»(ref-293473) article. TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.
- E5 CHECK FOR CORRECT LTM OPERATION Disconnect all the LTM connectors. Check for: corrosion damaged pins pushed-out pins Connect all the LTM connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new LTM. REFER to «BODY CLOSURES»(ref-293463) article. TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.
Pinpoint Test F: The Courtesy Lamps Are Inoperative - From The Dimmer Switch
Refer to appropriate SYSTEM WIRING DIAGRAMS article, Interior Lamps for schematic and connector information.
PINPOINT TEST F: PINPOINT TEST F: THE COURTESY LAMPS ARE INOPERATIVE - FROM THE DIMMER SWITCH
| CAUTION | Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector. |
Scheme 9
Scheme 10
- F1 CHECK THE DIMMABLE BACKLIGHTING OPERATION Place the headlamp switch in the PARKLAMP position. Monitor the instrument panel dimmable backlighting while rotating the instrument panel dimmer switch from full ON to full OFF. Does the dimmable backlighting intensity change with the instrument panel dimmer switch position? YES : Go to F2 . NO : REFER to «INSTRUMENT CLUSTER AND PANEL ILLUMINATION»(ref-293523) article.
- F2 CHECK THE DIMMER SWITCH Key in OFF position. Disconnect: Instrument Panel Dimmer Switch C2065 Connect a fused (5A) jumper wire between the instrument panel dimmer switch C2065-5, circuit CLN28 (GN/BU), harness side and the instrument panel dimmer switch C2065-4, circuit RLN29 (WH/OG), harness side. Do the courtesy lamps illuminate? YES : REMOVE the jumper wire. INSTALL a new headlamp switch. REFER to «EXTERIOR LIGHTING»(ref-293485) article. TEST the system for normal operation. NO : REMOVE the jumper wire. Go to F3 .
- F3 CHECK CIRCUIT CLN28 (GN/BU) FOR AN OPEN Disconnect: SJB C2280b Measure the resistance between the SJB C2280b-51, circuit CLN28 (GN/BU), harness side and the instrument panel dimmer switch C2065-5, circuit CLN28 (GN/BU), harness side. Is the resistance less than 5 ohms? YES : Go to F4 . NO : REPAIR the circuit. TEST the system for normal operation.
- F4 CHECK FOR CORRECT SJB OPERATION Disconnect all the SJB connectors. Check for: corrosion damaged pins pushed-out pins Connect all the SJB connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new SJB. REFER to «MULTIFUNCTION ELECTRONIC MODULES»(ref-293473) article. TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.
Pinpoint Test G: The Puddle Lamp(s) are Inoperative
Refer to appropriate SYSTEM WIRING DIAGRAMS article, Interior Lamps for schematic and connector information.
| CAUTION | Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector. |
Scheme 11
- G1 CHECK THE PUDDLE LAMP OPERATION Open any door and observe the puddle lamps. Are both the puddle lamps inoperative? YES : Go to G2 . NO : Go to G3 .
- G2 CHECK CIRCUIT CLN25 (VT) FOR AN OPEN Key in OFF position. Disconnect: SJB C2280c NOTE: If the fuse fails, repair circuit CLN25 (VT) for a short to ground. Connect a fused (5A) jumper wire between the SJB C2280c-12, circuit CLN25 (VT), harness side and battery positive. Do the puddle lamps illuminate? YES : REMOVE the jumper wire. Go to G5 . NO : REMOVE the jumper wire. REPAIR the circuit. RUN the on-demand self-test (required to clear certain DTCs). CORRECT any unresolved DTCs. CLEAR all DTCs. TEST the system for normal operation.
- G3 CHECK THE EXTERIOR MIRROR NOTE: Make sure the suspect puddle lamp bulb is OK before continuing diagnostics. Disconnect: Suspect Exterior Mirror NOTE: The courtesy lamps must be active during this test. Open any door. Measure the voltage between the suspect exterior mirror connector, harness side as follows: Location Connector-Pin/ Circuit Connector-Pin/ Circuit LH exterior mirror C516-5 CLN25 (VT) C516-7 GD133 (BK) RH exterior mirror C625-5 CLN25 (VT) C625-7 GD148 (BK/YE) Is the voltage greater than 10 volts? YES : INSTALL a new exterior mirror in question. REFER to «REAR VIEW MIRRORS»(ref-293465) article. TEST the system for normal operation. NO : Go to G4 .
- G4 CHECK CIRCUIT CLN25 (VT) FOR AN OPEN (INDIVIDUAL PUDDLE LAMP INOPERATIVE) NOTE: The courtesy lamps must be active during this test. Open any door. Measure the voltage between the LH exterior mirror connector C516-5, circuit CLN25 (VT), harness side and ground; or between the RH exterior mirror connector C625-5, circuit CLN25 (VT), harness side and ground. Is the voltage greater than 10 volts? YES : For the LH exterior mirror, REPAIR circuit GD133 (BK) for an open. TEST the system for normal operation. For the RH exterior mirror, REPAIR circuit GD148 (BK/YE) for an open. TEST the system for normal operation. NO : REPAIR circuit CLN25 (VT) for an open. TEST the system for normal operation.
- G5 CHECK FOR CORRECT SJB OPERATION Disconnect all the SJB connectors. Check for: corrosion damaged pins pushed-out pins Connect all the SJB connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new SJB. REFER to «MULTIFUNCTION ELECTRONIC MODULES»(ref-293473) article. TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. RUN the on-demand self-test (required to clear certain DTCs). CORRECT any unresolved DTCs. CLEAR all DTCs. TEST the system for normal operation.
Pinpoint Test H: The Puddle Lamps Stay On Continuously
Refer to appropriate SYSTEM WIRING DIAGRAMS article, Interior Lamps for schematic and connector information.
- H1 CHECK CIRCUIT CLN25 (VT) FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: SJB C2280c Key in ON position. Do the puddle lamps continue to illuminate? YES : REPAIR the circuit. CLEAR the DTCs. REPEAT the self-test. NO : Go to H2 .
- H2 CHECK FOR CORRECT SJB OPERATION Disconnect all the SJB connectors. Check for: corrosion damaged pins pushed-out pins Connect all the SJB connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new SJB. REFER to «MULTIFUNCTION ELECTRONIC MODULES»(ref-293473) article. TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test.
Pinpoint Test I: The Demand Lamps Are Inoperative
Refer to appropriate SYSTEM WIRING DIAGRAMS article, Interior Lamps for schematic and connector information.
| CAUTION | Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector. |
Scheme 12
- I1 CHECK CIRCUIT CLN09 (YE/GN) FOR AN OPEN Key in OFF position. Disconnect: SJB C2280d NOTE: If the fuse fails, repair circuit CLN09 (YE/GN) for a short to ground. Connect a fused (5A) jumper wire between the SJB C2280d-21, circuit CLN09 (YE/GN), harness side and battery positive. Do the demand lamps illuminate when switched on? YES : VERIFY the SJB fuse 25 (10A) is OK. If OK, go to I2 . NO : REPAIR the circuit. TEST the system for normal operation.
- I2 CHECK FOR CORRECT SJB OPERATION Disconnect all the SJB connectors. Check for: corrosion damaged pins pushed-out pins Connect all the SJB connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new SJB. REFER to «MULTIFUNCTION ELECTRONIC MODULES»(ref-293473) article. TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.
Pinpoint Test J: An Individual Demand Lamp Is Inoperative
Refer to appropriate SYSTEM WIRING DIAGRAMS article, Interior Lamps for schematic and connector information.
| CAUTION | Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector. |
- J1 CHECK CIRCUIT CLN09 (YE/GN) FOR AN OPEN Key in OFF position. Disconnect: Suspect Demand Lamp Key in ON position. Measure the voltage between the suspect demand lamp, harness side and ground as follows: Location Connector-Pin Circuit RH vanity mirror lamp C906-1 CLN09 (YE/GN) LH vanity mirror lamp C907-1 CLN09 (YE/GN) Overhead console C9013-3 CLN09 (YE/GN) 2ND row interior lamp C961-3 CLN09 (YE/GN) 3RD row interior lamp C963-3 CLN09 (YE/GN) Is the voltage greater than 10 volts? YES : Go to J2 . NO : REPAIR the circuit in question. TEST the system for normal operation.
- J2 CHECK THE GROUND CIRCUIT FOR AN OPEN Measure the resistance between the suspect demand lamp, harness side and ground as follows: Location Connector-Pin Circuit RH vanity mirror lamp C906-2 GD133 (BK) LH vanity mirror lamp C907-2 GD133 (BK) Overhead console C9013-1 GD133 (BK) 2ND row interior lamp C961-2 GD147 (BK/VT) 3RD row interior lamp C963-2 GD147 (BK/VT) Is the resistance less than 5 ohms? YES : INSTALL a new interior lamp for the lamp in question. TEST the system for normal operation. NO : REPAIR the circuit in question. TEST the system for normal operation.
Pinpoint Test K: The Luggage Compartment Lamp Is Inoperative/Does Not Operate Correctly
Refer to appropriate SYSTEM WIRING DIAGRAMS article, Interior Lamps for schematic and connector information.
Refer to appropriate SYSTEM WIRING DIAGRAMS article, Remote Keyless Entry and Alarm for schematic and connector information.
| CAUTION | Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector. |
Scheme 13
Scheme 14
Scheme 15
Scheme 16
Scheme 17
- K1 CHECK THE LUGGAGE COMPARTMENT LATCH Open the luggage compartment using the integrated keyhead transmitter (IKT) or the luggage compartment release switch on the instrument panel. Does the luggage compartment open? YES : Go to K2 . NO : REFER to «HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS»(ref-293464) article.
- K2 CHECK THE LUGGAGE COMPARTMENT AJAR PID Key in ON position. Enter the following diagnostic mode on the diagnostic tool: SJB DataLogger Monitor the SJB luggage compartment ajar switch PID (DECKLID) while opening and closing the luggage compartment. Does the luggage compartment ajar switch PID value agree with the luggage compartment positions? YES : Go to K5 . NO : Go to K3 .
- K3 CHECK THE LUGGAGE COMPARTMENT AJAR SWITCH Disconnect: Luggage Compartment Lid Latch C4223 Enter the following diagnostic mode on the diagnostic tool: SJB DataLogger Monitor the SJB luggage compartment ajar switch PID (DECKLID). Connect a (5A) jumper wire between the luggage compartment latch C4223-1, circuit CPL58 (GY/OG) harness side, and the luggage compartment latch C4223-4, circuit GD147 (BK/VT) harness side. Does the luggage compartment ajar switch PID indicate ajar with the jumper wire removed and closed with the jumper wire connected? YES : REMOVE the jumper wire. INSTALL a new luggage compartment lid latch. REFER to «HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS»(ref-293464) article. TEST the system for normal operation. NO : REMOVE the jumper wire. Go to K4 .
- K4 CHECK CIRCUIT CPL58 (GY/OG) FOR AN OPEN AND SHORT TO GROUND Key in OFF position. Disconnect: SJB C2280c Measure the resistance between the luggage compartment lid latch C4223-1, circuit CPL58 (GY/OG), harness side and the SJB C2280c-16, circuit CPL58 (GY/OG), harness side; and between the luggage compartment lid latch C4223-1, circuit CPL58 (GY/OG), harness side and ground. Is the resistance less than 5 ohms between the luggage compartment lid latch and the SJB, and greater than 10,000 ohms between the luggage compartment lid latch and ground? YES : Go to K8 . NO : REPAIR the circuit. CLEAR the DTCs. REPEAT the self-test.
- K5 CHECK CIRCUIT CLN09 (YE/GN) FOR AN OPEN NOTE: Make sure all other demand lamps are operating before continuing this pinpoint test. Disconnect: Luggage Compartment Lamp C428 Key in ON position. Measure the voltage between the luggage compartment lamp C428-1, circuit CLN09 (YE/GN), harness side and ground. Is the voltage greater than 10 volts? YES : Go to K6 . NO : REPAIR the circuit. TEST the system for normal operation.
- K6 CHECK THE LUGGAGE COMPARTMENT LATCH Disconnect: Luggage Compartment Lid Latch C4223 Connect: Luggage Compartment Lamp C428 Monitor the luggage compartment lamp. Connect a (5A) jumper wire between the luggage compartment latch C4223-2, circuit CLN13 (WH/BU) harness side, and the luggage compartment latch C4223-4, circuit GD147 (BK/VT) harness side. Is the luggage compartment lamp illuminated with the jumper wire installed and off with it removed? YES : REMOVE the jumper wire. INSTALL a new luggage compartment lid latch. REFER to «HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS»(ref-293464) article. TEST the system for normal operation. NO : REMOVE the jumper wire. Go to K7 .
- K7 CHECK CIRCUIT CLN13 (WH/BU) FOR AN OPEN AND SHORT TO GROUND Key in OFF position. Disconnect: Luggage Compartment Lamp C428 Measure the resistance between the luggage compartment lid latch C4223-2, circuit CLN13 (WH/BU), harness side and the luggage compartment lamp C428-2, circuit CLN13 (WH/BU), harness side; and between the luggage compartment lid latch C4223-2, circuit CLN13 (WH/BU), harness side and ground. Is the resistance less than 5 ohms between the luggage compartment lid latch and the luggage compartment lamp, and greater than 10,000 ohms between the luggage compartment lid latch and ground? YES : INSTALL a new luggage compartment lamp. TEST the system for normal operation. NO : REPAIR the circuit. TEST the system for normal operation.
- K8 CHECK FOR CORRECT SJB OPERATION Disconnect all the SJB connectors. Check for: corrosion damaged pins pushed-out pins Connect all the SJB connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new SJB. REFER to «MULTIFUNCTION ELECTRONIC MODULES»(ref-293473) article. TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. TEST the system for normal operation.
Pinpoint Test L: The Battery Saver Does Not Deactivate After Time-Out
Refer to appropriate SYSTEM WIRING DIAGRAMS article, Interior lamps for schematic and connector information.
- L1 CHECK THE SJB IGNITION SWITCH PID Key in ON position. Enter the following diagnostic mode on the diagnostic tool: SJB DataLogger Monitor the SJB ignition switch PID (IGN_SW) while rotating the ignition switch through all positions. Does the ignition switch PID agree with the ignition switch positions? YES : Go to L2 . NO : REFER to «STEERING COLUMN SWITCHES»(ref-293477) article.
- L2 CHECK CIRCUIT CLN09 (YE/GN) FOR A SHORT TO VOLTAGE Key in OFF position. Disconnect: SJB C2280d Key in ON position. Operate the demand lamps. Do the demand lamps illuminate? YES : REPAIR the circuit. TEST the system for normal operation. NO : Go to L3 .
- L3 CHECK FOR CORRECT SJB OPERATION Disconnect all the SJB connectors. Check for: corrosion damaged pins pushed-out pins Connect all the SJB connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new SJB. REFER to «MULTIFUNCTION ELECTRONIC MODULES»(ref-293473) article. TEST the system for normal operation. NO : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.
