Multifunction Electronic Modules System: Other Mercury Sable V

Module Controlled Functions

Note. The smart junction box (SJB) is also known as the generic electronic module (GEM).

The vehicle is equipped with a SJB and a driver seat module (DSM).

Smart Junction Box (SJB)

Note. The time out for the battery saver relay and the accessory delay relay (both are controlled by the SJB) is 1 minute if the vehicle has less than 80 km (50 miles). Once the vehicle passes the approximate mileage threshold of 80 km (50 miles), the time out for both relays will be the normal 10 minute time out, as described by the Owner's Literature. For the battery saver relay, Refer to INTERIOR LIGHTING article. For the accessory delay relay, refer to GLASS, FRAMES AND MECHANISMS article.

The SJB is a combination of a multifunction control module and a central junction box (CJB). The following systems are controlled by the SJB

1. Accessory delay relay
2. Battery saver relay
3. Exterior lighting
4. Interior lighting
5. Heated rear window
6. Horn
7. Perimeter anti-theft
8. Power door locks (including smart locks, autolocking and liftgate/luggage compartment lid release)
9. Remote keyless entry (RKE)/keyless entry keypad
10. Tire pressure monitoring system (TPMS)

Driver Seat Module (DSM)

The DSM controls the user selected comfort functions. These functions are the memory seat, memory mirrors and memory pedals. Up to 2 personal settings can be programmed into the DSM memory and when selected, the DSM returns the user adjustable features to the programmed positions. For additional information on programming the memory feature, refer to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS article.

Special Tools Illustration Tool Name Tool Number Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

Scheme 77

Special Tools Illustration Tool Name Tool Number Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

Special Tools Illustration Tool Name Tool Number Heavy-Duty Riveter 501-D011 (D80L-23200-A)

Scheme 78
