GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Generator | |
| Generator pulley ratio | 2.66:1 |
| Rating | 90/154 amp (max) @ 600-2,500 engine RPM |
| Second rating for Taurus X | 102/170 amp (max) @ 670-2,300 engine RPM |
| Voltage regulator type | Electronic internal with generator |
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Generator B+ nut | 12 |
| Generator nut/bolts | 47 |
| Generator stud | 8 |
TORQUE SPECIFICATIONS
The generator (including an internal voltage regulator) is belt-driven by the engine accessory drive system. When the engine is started, the generator begins to generate AC which is internally converted to DC. This current is then supplied to the vehicle electrical system through the output (B+) terminal of the generator.
A new voltage regulator and generator must be installed as an assembly. The B+ red radial adapter can be replaced as a separate component.
Refer to CHARGING SYSTEM - GENERAL INFORMATION article.
Scheme 11
| Item | Part Number | Description |
|---|---|---|
| 1 | 10346 | Generator |
| 2 | Generator electrical connector (part of 14B060) | |
| 3 | Generator B+ terminal (part of 14B060) | |
| 4 | W705790 | Generator B+ nut |
| 5 | W709986 | Generator bolt (lower) |
| 6 | W709985 | Generator stud (replacement bolts, W709986-S437) |
| 7 | W520414 | Generator stud nut |
| 8 | 8620 | Front end accessory drive belt |
