Engine - 3.0L 4V: Removal & Installation Mercury Sable IV

Removal and Installation

1. Remove the camshaft followers. Refer to «ROLLER FOLLOWERS»(ref-178953-S28317148392005062500000) .
2. Remove the hydraulic lash adjusters.
3. To install, reverse the removal procedure. Lubricate the hydraulic lash adjusters with clean motor oil.

Scheme 1099

Scheme 1100

Scheme 1101

Scheme 1102

Scheme 1103

1. Raise and support the vehicle.
2. Remove the RH front wheel.
3. Remove the RH front inner fender splash shield. Remove the screws and the pin-type retainers.
4. Remove the alternator splash shield.
5. Rotate the accessory drive belt tensioner clockwise and remove the accessory drive belt from the crankshaft pulley.
6. Remove the torque converter inspection cover.
7. Install the flywheel holding tool.
8. Remove the crankshaft pulley.
9. To install, reverse the removal procedure.

Scheme 1104

Scheme 1105

Scheme 1106

Scheme 1107

1. Remove the crankshaft pulley. Refer to «CRANKSHAFT PULLEY»(ref-178953-S34628305252005062500000) .
2. Remove the crankshaft damper bolt and washer.
3. Using the special tool, remove the crankshaft damper.

Scheme 1108

1. Apply silicone gasket and sealant to the end of the keyway slot.
2. Using the special tool, install the crankshaft damper.
3. Install the bolt and the washer and tighten in four stages. Stage 1: Tighten to 120 Nm (89 lb-ft). Stage 2: Loosen 360 degrees. Stage 3: Tighten to 50 Nm (37 lb-ft). Stage 4: Tighten 90 degrees.
4. Install the crankshaft pulley. Refer to «CRANKSHAFT PULLEY»(ref-178953-S34628305252005062500000) .

Scheme 1109

Scheme 1110

1. Remove the crankshaft vibration damper. Refer to «CRANKSHAFT VIBRATION DAMPER»(ref-178953-S25122215182005062500000) .
2. Using the special tool, remove the crankshaft front oil seal.

Scheme 1111

1. Using the special tool, install the crankshaft front oil seal.
2. Install the crankshaft vibration damper. Refer to «CRANKSHAFT VIBRATION DAMPER»(ref-178953-S25122215182005062500000) .

Scheme 1112

Scheme 1113

1. Remove the hydraulic lash adjusters. Refer to «HYDRAULIC LASH ADJUSTER»(ref-178953-S34746699002005062500000) .
2. Pressurize the cylinder using compressed air.
3. Using the special tool, remove the key, retainer, and valve spring.
4. To install, reverse the removal procedure.

Scheme 1114

Removal

1. Remove the valve spring. Refer to «VALVE SPRING»(ref-178953-S20714064872005062500000) .
2. Remove the valve seal.

Scheme 1115

1. Using the special tool, install the valve seal.
2. Install the valve spring. Refer to «VALVE SPRING»(ref-178953-S20714064872005062500000) .

Scheme 1116

Scheme 1117

Scheme 1118

Scheme 1119

Scheme 1120

Scheme 1121

Scheme 1122

1. Remove the LH exhaust manifold to pipe nuts.
2. Remove the coolant tube bracket bolt.
3. Disconnect and unclip the LH heated oxygen sensor (HO2S) electrical connector from the coolant tube.
4. Raise the support the vehicle.
5. Remove the pin-type retainers, bolts and the front splash shield.
6. Remove the lower exhaust manifold nuts.
7. Remove the coolant tube lower bracket bolt.
8. Lower the vehicle.
9. Remove the upper nuts and the exhaust manifold. Discard the gasket.

Scheme 1123

Scheme 1124

Scheme 1125

Scheme 1126

Scheme 1127

Scheme 1128

1. Position a new gasket and install the exhaust manifold. Tighten the nuts in the sequence shown.
2. Position the coolant tubes and tighten the bolt.
3. Connect the LH HO2S electrical connector.
4. Install the LH exhaust manifold-to-pipe nuts.
5. Raise the vehicle.
6. Install the coolant tube lower bracket bolt.
7. Position the front splash shield and install the pin-type retainers and bolts.

Scheme 1129

Scheme 1130

Scheme 1131

Scheme 1132

Scheme 1133

Scheme 1134

1. Remove the cowl panel grille.
2. Remove the RH valve cover. Refer to «VALVE COVER RH»(ref-178953-S26541368892005062500000) .
3. Disconnect the exhaust gas recirculation (EGR) tube from the exhaust manifold.
4. Raise and support the vehicle.
5. Remove the RH manifold-to-Y-pipe nuts.
6. Remove the engine support insulator nut.
7. Lower the vehicle.
8. Using the special tool, raise the engine until the exhaust manifold can be removed.
9. Remove the nuts in the sequence shown and remove the exhaust manifold. Discard the gasket.

Scheme 1135

Scheme 1136

Scheme 1137

Scheme 1138

1. Position a new gasket and install the exhaust manifold nuts in the sequence shown.
2. Using the special tool, lower the engine.
3. Raise the vehicle.
4. Install the engine support insulator nut.
5. Install the RH exhaust manifold to pipe bolts.
6. Lower the vehicle.
7. Remove the special tools.
8. Install the RH valve cover. Refer to «VALVE COVER RH»(ref-178953-S26541368892005062500000) .
9. Install the cowl panel grille.

Scheme 1139

Scheme 1140

Scheme 1141

Scheme 1142

Scheme 1143

1. Remove the coolant bypass tube. Refer to ENGINE COOLING .
2. Remove the LH exhaust manifold-to-pipe nuts.
3. Remove the water pump. Refer to ENGINE COOLING .
4. Remove the LH camshafts. Refer to «CAMSHAFTS LH»(ref-178953-S23591863292005062500000) .
5. Remove the camshaft followers.
6. Remove the hydraulic lash adjusters.
7. Remove the nuts and remove the exhaust manifold. Discard the gasket.
8. Remove the bolts in the sequence shown and remove the cylinder head. Discard the gasket and the bolts.

Scheme 1144

Scheme 1145

Scheme 1146

Scheme 1147

1. Position the LH cylinder head, gasket and install the bolts in the sequence shown in six stages. Tighten the bolts in six stages. Stage 1: Tighten to 40 Nm (30 lb-ft). Stage 2: Tighten bolts 90 degrees. Stage 3: Loosen one full turn. Stage 4: Tighten to 40 Nm (30 lb-ft). Stage 5: Tighten 90 degrees. Stage 6: Tighten 90 degrees.
2. Position a new gasket and install the exhaust manifold nuts in the sequence shown.
3. Install the hydraulic lash adjusters. Lubricate the hydraulic lash adjusters with clean motor oil.
4. Install the camshaft followers. Lubricate the camshaft followers with clean motor oil.
5. Install the LH camshafts. Refer to «CAMSHAFTS LH»(ref-178953-S23591863292005062500000) .
6. Install the water pump. Refer to ENGINE COOLING .
7. Install the LH exhaust manifold-to-pipe nuts.
8. Install the coolant bypass tube. Refer to ENGINE COOLING .

Scheme 1148

Scheme 1149

Scheme 1150

Scheme 1151

Scheme 1152

Scheme 1153

1. Remove the coolant bypass tube. Refer to ENGINE COOLING .
2. Remove the RH camshafts. Refer to «CAMSHAFTS RH»(ref-178953-S23544687882005062500000) .
3. Raise and support the vehicle.
4. Remove the RH exhaust manifold-to-pipe bolts.
5. Lower the vehicle.
6. Disconnect the exhaust gas recirculation (EGR) tube from the exhaust manifold.
7. Remove the camshaft followers.
8. Remove the hydraulic lash adjusters.
9. Remove the nuts in the sequence shown and remove the exhaust manifold. Discard the gasket.
10. Remove the bolts in the sequence shown and remove the cylinder head. Discard the gasket and the bolts.

Scheme 1154

Scheme 1155

Scheme 1156

Scheme 1157

Scheme 1158

1. Position the RH cylinder head, gasket and install the bolts in the sequence shown in six stages. Tighten the bolts in six stages. Stage 1: Tighten to 40 Nm (30 lb-ft). Stage 2: Tighten bolts 90 degrees. Stage 3: Loosen one full turn. Stage 4: Tighten to 40 Nm (30 lb-ft). Stage 5: Tighten 90 degrees. Stage 6: Tighten 90 degrees.
2. Position a new gasket and install the exhaust manifold nuts in the sequence shown.
3. Install the hydraulic lash adjusters. Lubricate the hydraulic lash adjusters with clean motor oil.
4. Install the camshaft followers. Lubricate the camshaft followers with clean motor oil.
5. Connect the EGR tube to the exhaust manifold.
6. Raise and support the vehicle.
7. Install the RH exhaust manifold-to-pipe bolts.
8. Lower the vehicle.
9. Install the RH camshafts. Refer to «CAMSHAFTS RH»(ref-178953-S23544687882005062500000) .
10. Install the coolant bypass tube. Refer to ENGINE COOLING .

1. Raise and support the vehicle.
2. Position a drain pan and remove the oil filter.
3. Remove the oil pressure sender. Disconnect the electrical connector. Remove the sender.
4. To install, reverse the removal procedure.

Scheme 1159

Scheme 1160

Scheme 1161

1. Remove the oil level indicator.
2. Remove the oil level indicator tube. Remove the stud. Remove the oil level indicator tube.
3. Inspect the O-ring seal at the end of the oil level indicator tube and install a new O-ring seal if necessary.
4. To install, reverse the removal procedure. Lubricate the O-ring seal with clean motor oil.

Scheme 1162

Scheme 1163

Scheme 1164

Scheme 1165

Scheme 1166

1. Raise and support the vehicle.
2. Remove the front RH wheel.
3. Remove the RH front inner wheel splash shield. Remove the screws and the pin-type retainer.
4. Remove the dual converter Y-pipe.
5. Secure the exhaust system and remove the jackstand.
6. Drain the engine oil. Install a new drain plug gasket and tighten the drain plug to 27 Nm (20 lb-ft).
7. Remove the bolts, nuts and the engine-to-transaxle bracket.
8. Remove the torque converter inspection cover.
9. Remove the 18 bolts and the oil pan.

Scheme 1167

Scheme 1168

Scheme 1169

Scheme 1170

Scheme 1171

Scheme 1172

Scheme 1173

1. Clean all sealing surfaces on the engines and the oil pan with metal surface cleaner.
2. Position a new gasket on the oil pan.
3. Apply a 10 mm (0.40 in) diameter dot of silicone gasket and sealer to the areas indicated.
4. Position the oil pan and hand tighten the oil pan-to-transaxle bolts.
5. Tighten the oil pan bolts in the sequence shown.
6. Tighten the oil pan-to-transaxle bolts.
7. Install the torque converter inspection cover.
8. Position the engine-to-transaxle bracket and install the nuts and the bolt.
9. Position a jackstand and release the exhaust system.
10. Install the dual converter Y-pipe.
11. Install the RH front inner wheel splash shield. Install the screws and the pin-type retainer.
12. Install the RH wheel.
13. Lower the vehicle.
14. Install the LH exhaust manifold-to-pipe nuts.
15. Fill crankcase to correct level with clean motor oil.

Scheme 1174

Scheme 1175

1. Remove the oil pan. Refer to «OIL PAN»(ref-178953-S03297030382005062500000) .
2. Remove the nut, bolts and the oil pump screen and pick-up tube.
3. Remove and inspect the O-ring seal.

Scheme 1176

Scheme 1177

1. Install the O-ring seal.
2. Install the oil pump screen cover and tube. Position the oil pump screen and pick up tube. Install the bolts. Install the nut. Tighten the nut in two stages. Stage 1: Tighten to 10 Nm (89 lb-in). Stage 2: Tighten 45 degrees.
3. Install the oil pan. Refer to «OIL PAN»(ref-178953-S03297030382005062500000) .

Scheme 1178

1. Remove the oil pump screen cover and tube. Refer to «OIL PUMP SCREEN AND PICKUP TUBE»(ref-178953-S10794452862005062500000) .
2. Remove the nuts and the oil pan baffle.

Scheme 1179

1. Position the oil pan baffle and install the nuts. Tighten the nuts in two stages. Stage 1: Tighten to 10 Nm (89 lb-in). Stage 2: Tighten 45 degrees.
2. Install the oil pump screen cover and tube. Refer to «OIL PUMP SCREEN AND PICKUP TUBE»(ref-178953-S10794452862005062500000) .

Scheme 1180

Scheme 1181

1. Remove the timing drive components. Refer to «TIMING DRIVE COMPONENTS»(ref-178953-S35591184642005062500000) .
2. Remove the oil pump screen cover and tube. Refer to «OIL PUMP SCREEN AND PICKUP TUBE»(ref-178953-S10794452862005062500000) .
3. Remove the damper bolt and the crankshaft sprocket.
4. Remove the bolts in the indicated sequence and remove the oil pump.

Scheme 1182

Scheme 1183

1. Position the oil pump and install the bolts in the sequence shown.
2. Install the crankshaft sprocket.
3. Install the oil pump screen cover and tube. Refer to «OIL PUMP SCREEN AND PICKUP TUBE»(ref-178953-S10794452862005062500000) .
4. Install the timing drive components. Refer to «TIMING DRIVE COMPONENTS»(ref-178953-S35591184642005062500000) .

Scheme 1184

1. Remove the transaxle. Refer to «REMOVAL & INSTALLATION - A/T»(ref-155920) .
2. Remove the bolts and the flexplate.
3. To install, reverse the removal procedure.

Scheme 1185

Scheme 1186

Scheme 1187

Scheme 1188

1. Remove the flexplate. Refer to «FLEXPLATE»(ref-178953-S18220787832005062500000) .
2. Using the special tools, remove the crankshaft rear oil seal.

Installation

1. Using the special tools, install the crankshaft rear oil seal.
2. Install the flexplate. Refer to «FLEXPLATE»(ref-178953-S18220787832005062500000) .

Scheme 1189

Scheme 1190

Scheme 1191

Scheme 1192

Scheme 1193

1. Raise and support vehicle.
2. Remove the right front wheel.
3. Remove the engine support insulator nut.
4. Lower the vehicle.
5. Remove the cowl panel grilles.
6. Install the 3-Bar Engine Support.
7. Using the special tools, raise the engine to gain clearance necessary to remove the mount.
8. Remove the RH front inner fender splash shield.
9. Remove the two upper bolts and remove the engine support insulator.
10. To install, reverse the removal procedure.

Scheme 1194

Scheme 1195

Scheme 1196

Scheme 1197

1. Raise and support the vehicle.
2. Remove the right front wheel.
3. Remove the engine support insulator nut.
4. Lower the vehicle.
5. Remove the cowl panel grille.
6. Using the special tools, raise the engine to gain clearance to remove the engine support insulator.
7. Raise and support the vehicle.
8. Remove the nut and through bolt and the engine support insulator.
9. To install, reverse the removal procedure.

Scheme 1198

Scheme 1199

Scheme 1200

Scheme 1201

Scheme 1202

Scheme 1203

Scheme 1204

Scheme 1205

Scheme 1206

Scheme 1207

Scheme 1208

Scheme 1209

Scheme 1210

Scheme 1211

Scheme 1212

Scheme 1213

Scheme 1214

Scheme 1215

Scheme 1216

Scheme 1217

Scheme 1218

Scheme 1219

Scheme 1220

Scheme 1221

Scheme 1222

Scheme 1223

Scheme 1224

Scheme 1225

Scheme 1226

Scheme 1227

Scheme 1228

Scheme 1229

Scheme 1230

Scheme 1231

Scheme 1232

Scheme 1233

Scheme 1234

Scheme 1235

Scheme 1236

Scheme 1237

Scheme 1238

Scheme 1239

Scheme 1240

Scheme 1241

Scheme 1242

Scheme 1243

Scheme 1244

Scheme 1245

Scheme 1246

Scheme 1247

Scheme 1248

Scheme 1249

Scheme 1250

Scheme 1251

Scheme 1252

1. Disconnect the battery ground cable.
2. Remove the steering shaft pinch bolt.
3. Remove the cowl vent screen.
4. Remove the ground strap bolt.
5. Loosen the bolt and disconnect the powertrain control module (PCM) electrical connector.
6. Disconnect the evaporative emission system hoses.
7. Disconnect the mass air flow (MAF) sensor electrical connector.
8. Remove the air cleaner outlet tube. Disconnect the crankcase ventilation hoses. Loosen the clamps. Remove the tube.
9. Release the clamps and remove the air cleaner cover.
10. Remove the pin-type retainers and the accelerator cable splash shield.
11. Disconnect and unclip the accelerator and cruise control cables.
12. Disconnect the throttle position (TP) sensor and idle air control (IAC) valve electrical connectors.
13. Disconnect the transaxle range sensor electrical connector.
14. Remove the nut and unclip the shifter cable from the bracket.
15. Loosen the bolt and disconnect the harness connector.
16. Drain the cooling system. Refer to ENGINE COOLING .
17. Recover the A/C system. Refer to «REFRIGERANT SYSTEM RECOVERY»(ref-178710-S17932127632005062100000) .
18. Relieve the fuel pressure. Refer to «FUEL SYSTEM PRESSURE RELEASE»(ref-142370-S36646181352002073100000) .
19. Disconnect the low pressure A/C line spring lock coupling at the accumulator/drier. Refer to «SPRING LOCK COUPLING»(ref-178710-S38808236292005062100000) .
20. Remove the heater hose bracket nut.
21. Disconnect the heater hoses.
22. Remove the heater hose bracket nut.
23. Disconnect the coolant recovery bottle hose.
24. Remove the nut and disconnect the starter motor ground cable.
25. Disconnect the upper radiator hose.
26. Disconnect the power steering fluid hose from the reservoir.
27. Remove the two LH exhaust manifold-to-pipe nuts.
28. Raise and support the vehicle.
29. Drain the engine oil.
30. Remove the LH and RH front wheels.
31. Remove the pin-type retainers, bolts, and the front splash shield.
32. Remove the LH and RH inner fender splash shield pin-type retainers and remove the splash shield.
33. Remove the starter cable cover.
34. Remove the nut and disconnect the cable from the starter.
35. Remove the LH and RH sway bar end link nuts.
36. 36. NOTE: Insert a steel rod to prevent the rotor from turning. Remove the halfshaft nut and washer. Discard the nut.
37. 37. NOTE: RH shown, LH similar. Remove the LH and RH ball joint nuts.
38. 38. Using the special tool, separate the control arm from the ball joint.
39. 39. NOTE: RH shown, LH similar. Remove the LH and RH tie rod end cotter pin and castle nut.
40. 40. Using the special tool, separate the tie rod end from the knuckle.
41. 41. Using the special tools, push the halfshaft out of the hub.
42. 42. Remove the RH exhaust manifold-to-pipe bolts.
43. 43. Remove the nuts and the dual converter Y-pipe.
44. 44. Disconnect the power steering and transaxle hoses from the cooler.
45. 45. Disconnect the transaxle cooler line.
46. 46. Remove the nut and disconnect the A/C high pressure line at the condenser.
47. 47. Remove four bolts and remove the radiator support bracket.
48. 48. Disconnect the lower radiator hose and the reservoir supply hose.
49. 49. Disconnect the engine block heater electrical connector.
50. 50. Unclip the engine block heater harness.
51. 51. Remove the torque converter inspection cover.
52. 52. NOTE: Index the flexplate and torque converter by marking one stud. Remove the four torque converter-to-flexplate nuts.
53. 53. Using the special tool, support the subframe.
54. 54. Remove the four subframe bolts and lower the subframe engine/transaxle assembly.
55. 55. Remove the coolant tube lower mounting bolt.
56. 56. Remove the coolant tube mounting bolt and position the tube away from the cylinder head.
57. 57. Remove the engine support brace.
58. 58. Install the special tool.
59. 59. Using the special tools, support the engine and transaxle at the LH and RH cylinder heads.
60. 60. Disconnect the power steering pressure line and remove the clamp bolt.
61. 61. Remove the LH engine mount-to-frame nut.
62. 62. Remove the RH engine mount-to-frame nut.
63. 63. Remove the engine-to-transaxle bracket bolt.
64. 64. Remove the bolts and separate the engine from transaxle.
65. 65. Mount the engine on a suitable engine stand.

Special Tool(s)

Scheme 1253

Scheme 1254

Scheme 1255

Scheme 1256

Scheme 1257

Scheme 1258

Scheme 1259

Scheme 1260

Scheme 1261

Scheme 1262

Scheme 1263

Scheme 1264

Scheme 1265

Scheme 1266

Scheme 1267

Scheme 1268

Scheme 1269

Scheme 1270

Scheme 1271

Scheme 1272

Scheme 1273

Scheme 1274

Scheme 1275

Scheme 1276

Scheme 1277

Scheme 1278

Scheme 1279

Scheme 1280

Scheme 1281

Scheme 1282

Scheme 1283

Scheme 1284

Scheme 1285

Scheme 1286

Scheme 1287

Scheme 1288

Scheme 1289

Scheme 1290

Scheme 1291

Scheme 1292

Scheme 1293

Scheme 1294

Scheme 1295

Scheme 1296

Scheme 1297

Scheme 1298

Scheme 1299

Scheme 1300

Scheme 1301

Scheme 1302

Scheme 1303

Scheme 1304

Scheme 1305

Scheme 1306

Scheme 1307

Scheme 1308

Scheme 1309

Scheme 1310

Scheme 1311

Scheme 1312

Scheme 1313

Scheme 1314

Scheme 1315

Scheme 1316

Scheme 1317

Scheme 1318

Scheme 1319

Scheme 1320

Scheme 1321

1. Remove the accessory drive belt.
2. Remove the power steering pressure hose.
3. Remove the generator. Disconnect the electrical connector. Remove the bolt. Remove the studs. Remove the generator.
4. Remove the bolts and the power steering pump.
5. Disconnect the A/C compressor. Disconnect the compressor electrical connector. Disconnect the pressure sensor electrical connector. Disconnect the harness from the bracket.
6. Remove the bolts and the A/C compressor.
7. Remove the bolts and the A/C compressor bracket.
8. Disconnect the camshaft position (CMP) sensor electrical connector.
9. Disconnect the harness from the front LH valve cover studs.
10. Disconnect the oil pressure sensor.
11. Install the special tool to hold the flywheel.
12. Remove the crankshaft pulley.
13. Remove the crankshaft damper bolt and washer.
14. Using the special tool, remove the crankshaft vibration damper.
15. Remove the special tool.
16. Remove the crankshaft position (CKP) sensor. Disconnect the electrical connector. Remove the bolt. Remove the sensor.
17. Disconnect the differential pressure feedback exhaust gas recirculation (EGR) transducer electrical connector.
18. Loosen and disconnect the EGR tube from the manifold.
19. Disconnect the throttle position sensor (TPS) and idle air control (IAC) valve electrical connectors.
20. Disconnect the positive crankcase ventilation (PCV) and evaporative emissions (EVAP) hose from the upper intake.
21. Disconnect the exhaust gas recirculation (EGR) vacuum regulator solenoid electrical connector.
22. Remove the bolts and the upper intake manifold. Inspect the gaskets. Discard if damaged.
23. Disconnect the RH radio ignition interference capacitor, heated oxygen sensor (HO2S) electrical connectors and ignition coil electrical connector.
24. Remove the knock sensor bolt.
25. Disconnect the coolant temperature sensor electrical connectors.
26. Disconnect the harness from the coolant tube.
27. Disconnect and unclip the LH HO2S electrical connector from the coolant tube.
28. Disconnect the LH and RH spark plug wires.
29. Remove the stud nuts, and the ignition coil.
30. Disconnect the fuel injector electrical connectors.
31. Remove the bolts and the lower intake manifold.
32. Remove the fuel charging harness. Disconnect the harness from the stud. Remove the harness nut.
33. Remove the nuts and the LH exhaust manifold. Discard the gasket.
34. Remove the nuts and the RH exhaust manifold. Discard the gasket.
35. Remove the nuts and the EVAP tube from the RH valve cover.
36. Remove the water pump drive belt.
37. Disconnect the water pump outlet hose.
38. Remove the bolts and the water pump.
39. Remove the bolts and studs and the RH and LH valve cover. Remove and discard the gaskets.
40. Remove the bolt and stud and the coolant tube.
41. Remove the bolts and studs and the oil pan. Discard the gasket.
42. Remove the bolts, nut and the oil pick-up tube and screen.
43. Remove the nuts and the oil pan baffle.
44. Remove the oil filter.
45. Remove the stud and the oil level indicator and tube.
46. Remove the oil pressure sensor.
47. Remove the bolts, studs, and the front cover.
48. Remove the crankshaft front seal from the front cover.
49. Remove the ignition pulse wheel.
50. Install the damper bolt.
51. Remove the LH and RH spark plugs.
52. Rotate the crankshaft clockwise to position the crankshaft keyway in the 11 o'clock position and position the camshafts in the correct position. This will position the number one cylinder at top dead center (TDC). Verify that the camshafts are correctly located. If not, rotate the crankshaft one additional turn and re-check.
53. Rotate the crankshaft clockwise 120 degrees to the 3 o'clock position to locate the RH camshafts in the neutral position.
54. Verify that the RH camshafts are correctly positioned.
55. Remove the RH timing chain tensioner arm. Remove the bolts. Remove the tensioner. Remove the tensioner arm.
56. Remove the bolts, RH timing chain guide and the timing chain.
57. Rotate the crankshaft clockwise 600 degrees (1-2/3 turns) to position the crankshaft keyway in the 11 o'clock position. This will position the LH camshafts in the neutral position.
58. Remove the LH timing chain and tensioner arm. Remove the bolts. Remove the tensioner. Remove the tensioner arm.
59. Remove the LH timing chain and timing chain guide.
60. Remove the damper bolt and the crankshaft sprockets.
61. Using the special tools, remove the water pump drive pulley.
62. Using the special tools, remove the camshaft oil seal.
63. Remove the intake camshaft oil seal retainer.
64. Loosen the LH camshaft cap bolts in the indicated sequence and remove the camshaft caps. Tap the caps lightly with a soft faced mallet to loosen the camshaft caps.
65. Loosen the RH camshaft cap bolts in the indicated sequence and remove the camshaft caps. Tap the caps lightly with a soft faced mallet to loosen the camshaft caps.
66. Remove the LH and RH camshafts.
67. Remove the LH and RH camshaft followers. Mark the location of the followers using a permanent-type marker.
68. Loosen the bolts in the indicated sequence and remove the LH and RH cylinder heads. Discard the gaskets.
69. Remove the bolts and the oil separator. Discard the gaskets.
70. Remove the bolts in the indicated sequence and remove the oil pump.
71. Using the special tool, remove the cylinder ridge.
72. Remove the connecting rod cap bolts. Hold the piston/rod assembly to keep it from falling from the engine block.
73. Using the special tool, remove the piston/rod assembly from the engine block.
74. Remove the engine block from the stand and place on a workbench.
75. Remove the bolts and the flexplate.
76. Remove the bolts and studs in the indicated sequence and remove the lower cylinder block.
77. Remove the crankshaft rear main seal and remove the crankshaft.
78. Remove the crankshaft key.
79. Remove the crankshaft thrust bearing from the cylinder block.
80. Remove the bearings from the lower cylinder block.
81. Remove the crankshaft main bearings from the cylinder block.
82. Inspect the cylinder block, lower cylinder block, cylinder heads, pistons and connecting rods. Refer to ENGINE COOLING .
