Window and Glass: Component Locations Mercury Monterey VIII

Special Tool(s)

SPECIAL TOOLS DESCRIPTION 73III Automotive Meter 105-R0057 or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

Scheme 30

Scheme 31

SPECIAL TOOLS DESCRIPTION Heavy Duty Riveter 501-D011 (D80L-23200-A)

SPECIAL TOOLS DESCRIPTION Heavy Duty Riveter 501-D011 (D80L-23200-A)

Scheme 32

1. Remove the front door trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-234524) .
2. Position the watershield aside.
3. Connect the window control switch.
4. If necessary, connect the battery.
5. Remove the rivets. Lower the window glass enough to gain access to the door window glass rivets.
6. Remove the door window glass.
7. To install, reverse the removal procedure.

SPECIAL TOOLS DESCRIPTION Heavy Duty Riveter 501-D011 (D80L-23200-A)

Scheme 33

Scheme 34

Scheme 35

1. Remove the front door trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-234524) .
2. Position the watershield aside.
3. Connect the window control switch.
4. If necessary, connect the battery.
5. Remove the rivets. Lower the window enough to gain access to the door window glass rivets.
6. If removing only the front door window glass regulator assembly and motor, tape the window in the closed position after removing the rivets.
7. Remove the 4 window regulator rivets.
8. Remove the 3 window regulator nuts. To install, tighten to 12 Nm (9 lb-ft).
9. Disconnect the electrical connector.
10. Remove the front door window regulator.
11. To install, reverse the removal procedure.

SPECIAL TOOLS DESCRIPTION Heavy Duty Riveter 501-D011 (D80L-23200-A)

SPECIAL TOOLS DESCRIPTION Interior Auto Glass Cut-Out Knife Kit (Electric) 164-R2450 or equivalent Rotunda Pneumatic Knife with Off-Set Blade 107-R1511 or equivalent

Scheme 36

SPECIAL TOOLS DESCRIPTION Rotunda Interior Auto Glass Cut-Out Knife Kit (Electric) 164-R2450 or equivalent Rotunda Pneumatic Knife with Off-Set Blade 107-R1511 or equivalent The Pumper 164-R2459 or equivalent

Scheme 37

SPECIAL TOOLS DESCRIPTION Interior Auto Glass Cut-Out Knife Kit (Electric) 164-R2450 or equivalent Interior Auto Glass Cut-Out Knife Kit (Air Powered) 164-R2451 or equivalent The Pumper 164-R2459 or equivalent

Scheme 38
