The electronic engine controls consist of the following

1. PCM
2. Camshaft Position (CMP) sensor
3. Crankshaft Position (CKP) sensor
4. Mass Air Flow (MAF) sensor
5. Heated Oxygen Sensor (HO2S)
6. Catalyst Monitor Sensor (CMS)
7. Cylinder Head Temperature (CHT) sensor
8. Knock Sensor (KS)
9. Variable Camshaft Timing (VCT) oil control solenoid
10. Manifold Absolute Pressure (MAP) sensor

The PCM

1. accepts input from various engine sensors to compute the fuel flow rate necessary to maintain a prescribed air/fuel ratio throughout the entire engine operating range.
2. outputs a command to the fuel injectors to meter the appropriate quantity of fuel.

The CMP sensor

1. provides camshaft position information which is used by the PCM for fuel synchronization. Refer to «ELECTRONIC ENGINE CONTROLS - 2.5L»(/mercury/mariner/ii-2011-2011/remont/removal-installation/#electronic-engine-controls-25l-except-hybrid) article.

The CKP sensor

1. sends the PCM a signal indicating crankshaft position.
2. is essential for calculating spark timing.

The MAF sensor

1. uses a hot wire sensing element to measure the amount of air entering the engine.
2. sends the PCM a signal to determine the intake air mass. The PCM will then calculate the required fuel injector pulse width in order to provide the desired air/fuel ratio.

The HO2S

1. has the ability to create a voltage signal dependent on exhaust oxygen content.
2. provides feedback information to the PCM used to calculate fuel delivery.

The CMS

1. monitors oxygen content after it flows through the catalytic converter.
2. provides feedback information to the PCM used to calculate fuel delivery.

The CHT sensor

1. sends the PCM a signal indicating cylinder head temperature.
2. resistance decreases as coolant temperature increases. Refer to «ELECTRONIC ENGINE CONTROLS - 2.5L»(/mercury/mariner/ii-2011-2011/remont/removal-installation/#electronic-engine-controls-25l-except-hybrid) article.

The KS

1. is used to detect engine detonation.
2. sends a voltage signal to the PCM.
3. is able to provide a signal which retards the ignition timing, as necessary.

The VCT oil control solenoid

1. is an electrically controlled hydraulic valve that directs engine oil to the variable camshaft. Once the PCM transmits a signal, the solenoid moves a valve spool, directing oil into the camshaft phaser cavity. This action changes valve timing by either inducing an advance or retard condition. The camshaft is, thereby repositioned in relation to crankshaft timing and allows for optimum engine performance and lower emissions.

The MAP sensor

1. measures manifold vacuum and converts it to an electrical signal. This provides the PCM information on engine load.

PCM DTC Chart

PCM DTC CHART

MATERIAL SPECIFICATIONS

Scheme 41

ITEM DESCRIPTION

Removal and Installation

1. Disconnect the Camshaft Position (CMP) sensor electrical connector.
2. Remove the bolt and the CMP sensor. To install, tighten to 7 Nm (62 lb-in). Inspect the O-ring seal and install new as necessary.
3. To install, reverse the removal procedure.

Special Tool(s)

SPECIAL TOOLS Aligner, Crankshaft Sensor 303-1417 Timing Peg, Crankshaft TDC 303-507

Scheme 42

Scheme 43

Scheme 44

ITEM DESCRIPTION

Scheme 45

Scheme 46

Scheme 47

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(/mercury/mariner/ii-2011-2011/remont/hoistjack/#jacking-lifting) article.
2. Remove the 5 bolts, the pin-type retainer (not shown in illustration) and the RH splash shield.
3. Turn the crankshaft clockwise until the hole in the crankshaft pulley is in the 3 o'clock position.
4. Remove the engine plug bolt.
5. Install the Crankshaft TDC Timing Peg and turn the crankshaft clockwise until the crankshaft contacts the Crankshaft TDC Timing Peg.
6. Disconnect the Crankshaft Position (CKP) sensor electrical connector.
7. Remove the bolts and the CKP sensor.

Scheme 48

Scheme 49

Scheme 50

1. Install a 6 mm x 18 mm bolt in the crankshaft pulley and thread it into the front cover.
2. Install the CKP sensor and the 2 bolts. Do not tighten the bolts at this time.
3. Adjust the CKP sensor with the Crankshaft Sensor Aligner. Tighten the 2 CKP bolts to 7 Nm (62 lb-in).
4. Connect the CKP sensor electrical connector.
5. Remove the 6 mm x 18 mm bolt from the crankshaft pulley.
6. Install the engine plug bolt. Tighten to 20 Nm (177 lb-in).
7. Install the RH splash shield, 5 bolts and the pin-type retainer (not shown in illustration).

Scheme 51

ITEM DESCRIPTION

Removal

1. Retrieve the module configuration. Carry out the module configuration retrieval steps of the Programmable Module Installation (PMI) procedure. For additional information, refer to «MODULE CONFIGURATION»(ref-434520) article.
2. Detach the wiring harness retainer from the cowl stud bolt.
3. Disconnect the 3 PCM electrical connectors.
4. Remove the 2 bolts and the PCM.
5. Remove and inspect the PCM cowl seal. Install new if damaged.

Installation

1. Install the PCM cowl seal.
2. Install the PCM and the 2 bolts. Tighten to 8 Nm (71 lb-in).
3. Connect the 3 PCM electrical connectors.
4. Attach the wiring harness retainer to the cowl stud bolt.
5. Restore the module configuration. Carry out the module configuration restore steps of the Programmable Module Installation (PMI) procedure. For additional information, refer to «MODULE CONFIGURATION»(ref-434520) article.

Scheme 52

ITEM DESCRIPTION

1. Disconnect the Mass Air Flow (MAF) sensor electrical connector.
2. Remove the 2 screws and the MAF sensor. To install, tighten to 10 Nm (89 lb-in).
3. To install, reverse the removal procedure.

Scheme 53

ITEM DESCRIPTION

1. For additional information, refer to the appropriate procedures in this service information.

SPECIAL TOOLS Socket, Exhaust Gas Oxygen Sensor 303-476 (T94P-9472-A)

Scheme 54

MATERIAL SPECIFICATIONS

Scheme 55

Scheme 56

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(/mercury/mariner/ii-2011-2011/remont/hoistjack/#jacking-lifting) article.
2. Disconnect the Heated Oxygen Sensor (HO2S) electrical connector.
3. Using the Exhaust Gas Oxygen Sensor Socket, remove the HO2S. Calculate the correct torque wrench setting for the following torque. Refer to the Torque Wrench Adapter Formulas in the illustration. To install, tighten to 48 Nm (35 lb-ft).
4. To install, reverse the removal procedure.

SPECIAL TOOLS Socket, Exhaust Gas Oxygen Sensor 303-476 (T94P-9472-A)

Scheme 57

MATERIAL SPECIFICATIONS

Scheme 58

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(/mercury/mariner/ii-2011-2011/remont/hoistjack/#jacking-lifting) article.
2. Disconnect the Catalyst Monitor Sensor (CMS) electrical connector.
3. Using the Exhaust Gas Oxygen Sensor Socket, remove the CMS. Calculate the correct torque wrench setting for the following torque. Refer to the Torque Wrench Adapter Formulas in the illustration. To install, tighten to 48 Nm (35 lb-ft).
4. To install, reverse the removal procedure.

Scheme 59

ITEM DESCRIPTION

1. Detach the Cylinder Head Temperature (CHT) sensor cover and position aside.
2. Disconnect the CHT sensor electrical connector.
3. Remove the CHT sensor. To install, tighten to 12 Nm (106 lb-in).
4. To install, reverse the removal procedure.

Scheme 60

ITEM DESCRIPTION

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(/mercury/mariner/ii-2011-2011/remont/hoistjack/#jacking-lifting) article.
2. Remove the intake manifold. For additional information, refer to «ENGINE MECHANICAL - 2.5L HYBRID»(/mercury/mariner/ii-2011-2011/remont/mechanical/#engine-mechanical-25l-hybrid) article.
3. Remove the bolt and the Knock Sensor (KS). To install, tighten to 20 Nm (177 lb-in).
4. To install, reverse the removal procedure.

Scheme 61

ITEM DESCRIPTION

1. Remove the valve cover. For additional information, refer to «ENGINE MECHANICAL - 2.5L HYBRID»(/mercury/mariner/ii-2011-2011/remont/mechanical/#engine-mechanical-25l-hybrid) article.
2. Remove the bolt and the Variable Camshaft Timing (VCT) oil control solenoid. To install, tighten to 10 Nm (89 lb-in).
3. To install, reverse the removal procedure.

MATERIAL SPECIFICATIONS

Scheme 62

ITEM DESCRIPTION

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(/mercury/mariner/ii-2011-2011/remont/hoistjack/#jacking-lifting) article.
2. Remove the Throttle Body (TB). For additional information, refer to «FUEL CHARGING AND CONTROLS - HYBRID»(/mercury/mariner/ii-2011-2011/remont/fuel-system/#fuel-charging-system-fuel-control-system-hybrid) article.
3. Disconnect the Manifold Absolute Pressure (MAP) sensor electrical connector.
4. Using a tool like KD Tool #58181 or Lisle T25 Torx Bit, remove the screw and the MAP sensor. To install, tighten to 3 Nm (27 lb-in).
5. To install, reverse the removal procedure.
