Engine Ignition - 3.0L (4V): Specifications Mercury Mariner II

GENERAL SPECIFICATIONS

GENERAL SPECIFICATIONS

TORQUE SPECIFICATIONS

TORQUE SPECIFICATIONS

The electronic ignition system is a coil-on-plug ignition system. The coil-on-plug ignition system consists of the following components

1. Camshaft position (CMP) sensor
2. Crankshaft position (CKP) sensor
3. Ignition coil-on-plugs
4. Spark plugs

The CMP sensor

1. is a variable reluctance sensor.
2. is mounted in the front cover.
3. is triggered by the high point mark on the LH exhaust camshaft.
4. provides camshaft rotational location information to the PCM.

The CKP sensor

1. is a variable reluctance sensor.
2. is triggered by a 36-minus-1 tooth trigger wheel mounted on the crankshaft.
3. provides base timing and crankshaft speed (RPM) to the PCM.

The ignition coil-on-plugs

1. change low voltage signals from the PCM to high voltage pulses.
2. supplies the high voltage pulses to the spark plugs.
3. are connected directly to each spark plug.

The spark plugs

1. change high voltage pulses into a spark which ignites the fuel and air mixture.
2. originally equipped on the vehicle have a platinum-enhanced active electrode for long life.

Refer to the Introduction - Gasoline Engines article.

Scheme 3

Scheme 4

1. For additional information, refer to the procedures in this article.
