Engine - Lubrication - 2.5L: Maintenance Mazda Tribute II

ENGINE LUBRICATION COMPONENTS EXPLODED VIEW - 2.5L

Oil Filter Adapter, Oil Filter Element and Engine Oil Pressure (EOP) Switch

Scheme 16

Oil Filter Adapter, Spin On Oil Filter and Engine Oil Pressure (EOP) Switch

Scheme 17

Note. Automatic transaxle shown in figure, manual transaxle similar.

Oil Pan, Oil Pump Screen and Pickup Tube, Front Wheel Drive (FWD) Vehicles

Scheme 18

Oil Pan, Oil Pump Screen and Pickup Tube, All Wheel Drive (AWD) Vehicles

Scheme 19

Oil Pan, Oil Pump Screen and Pickup Tube

Scheme 20

Scheme 21

1. For additional information, see the procedures in this service information.

Scheme 22

1. With the vehicle in NEUTRAL, position in on a hoist. See «LIFTING»(ref-348626-S31954056142009112700000) .
2. Remove the 5 bolts and the RH splash shield. To install, tighten to 9 N.m {0.9 kgf.m, 80 in.lbf}.
3. Disconnect the Engine Oil Pressure (EOP) switch electrical connector.
4. If equipped, remove the oil filter element.
5. If equipped, remove the spin on oil filter. To install, lubricate the spin on oil filter gasket with clean engine oil and tighten the oil filter three-fourths turn after the oil filter gasket makes contact with the oil filter adapter.
6. Remove the 4 bolts and the oil filter adapter. To install, tighten to 25 N.m {2.5 kgf.m, 18 ft.lbf}. NOTE: Discard the gasket.
7. To install, reverse the removal procedure.
