Lighting Systems: Other Mazda Tribute I facelift

EXTERIOR LIGHTING

The exterior lighting consists of the following

1. headlamps
2. side lamps/front turn signal lamps
3. rear lamps
4. high-mounted stoplamps
5. fog lamps
6. parking lamps
7. license plate lamps
8. backup lamps
9. side repeater lamps
10. brake pedal position (BPP) switch
11. fog lamp switch
12. multifunction switch

The headlamp switch is integrated into the multifunction switch.

DAYTIME RUNNING LAMPS (DRL)

The daytime running lamps (DRL) system consists of the following

1. Daytime running lamps (DRL) control module Resistor Relay

The daytime running lamps control module operates the low beam headlamps at a reduced voltage when the ignition switch is in the ON position, the parking brake is disengaged, and the headlamp switch is OFF. Although the DRL system uses the low beam filament of the headlamp, it has a voltage-reducing resistor to dim the headlamps for daytime operation. This allows the flash-to-pass function during DRL system operation.

The DRL module is located under the instrument panel on the driver-side.

The DRL resistor is a part of the DRL module. For removal and installation, refer to DAYTIME RUNNING LAMPS (DRL) MODULE .

The DRL relay is mounted under the DRL module and is available separately.

Scheme 24

1. Disconnect the battery ground cable. Refer to BATTERY DISCONNECT .
2. Remove the nut and the DRL module. Disconnect the electrical connectors. Transfer parts as necessary.
3. To install, reverse the removal procedure.

Scheme 25

Scheme 26

Scheme 27

1. Remove the wheel and tire. Refer to WHEEL AND TIRE .
2. Position the inner fender well aside. Remove the bolts. Remove the pin-type retainers. Remove the screw. Position the inner fender well aside.
3. Remove the lamp socket from the lamp assembly.
4. Remove the bulb.
5. To install, reverse the removal procedure.

Scheme 28

Scheme 29

Scheme 30

Scheme 31

1. Remove the tire and wheel. Refer to WHEEL AND TIRE .
2. Position the inner fender well aside. Remove the bolts. Remove the pin-type retainers. Remove the screw. Position the inner fender well aside.
3. Disconnect the electrical bulb assembly and position aside.
4. Remove the fog lamp assembly. Remove the bolts. Remove the fog lamp assembly. NOTE: This step may not be necessary if the fog lamp comes with bracket.
5. Remove the fog lamp from the fog lamp bracket. Remove the adjusting screw and spring. Squeeze the top and bottom of the fog lamp bracket. Remove the fog lamp from the fog lamp bracket.
6. To install, reverse the removal procedure.

INTERIOR LIGHTING

The interior lighting system consists of the following

1. console lamp assembly (with roof opening panel)
2. interior/map reading lamp assembly
3. cargo lamp assembly
4. generic electronic module (GEM)
5. interior lamp switch
6. cargo lamp switch

Interior/Map Reading Lamp

The interior/map reading lamp assembly is equipped with two independently operated map lamps and one interior lamp and has a three-position switch: OFF, DOOR, and ON. The interior/map reading lamp assembly operates automatically when any of the doors are opened.

Cargo Lamp

A cargo lamp is located in the cargo area and has a three position switch: OFF, DOOR, and ON. The lamp is operated by an integral switch in the liftgate latch.

Scheme 32

Scheme 33

1. Remove the instrument panel dimmer switch.
2. Disconnect the electrical connector.
3. To install, reverse the removal procedure.

Scheme 34

Scheme 35

1. Disconnect the battery ground cable. Refer to BATTERY DISCONNECT .
2. Remove the interior/map reading lamp lens.
3. Remove the interior/map reading lamp assembly. Remove the screws. Remove the interior/map reading lamp. Disconnect the electrical connector.
4. To install, reverse the removal procedure.

Scheme 36

Scheme 37

1. Disconnect the battery ground cable. Refer to BATTERY DISCONNECT .
2. Remove the cargo lamp assembly from the head-liner.
3. Remove the cargo lamp assembly. Disconnect the electrical connectors. Remove the cargo lamp assembly.
4. To install, reverse the removal procedure.

STEERING COLUMN SWITCHES

The steering column switches consist of the following

1. multifunction switch
2. ignition switch

Scheme 38

Scheme 39

Scheme 40

1. Disconnect the battery ground cable. Refer to BATTERY DISCONNECT .
2. Remove the upper steering column shroud.
3. Remove the lower steering column shroud. Remove the screws. Remove the lower steering column shroud.
4. Remove the multifunction switch. Disconnect the electrical connector. Remove the screws. Remove the multifunction switch.
5. To install, reverse the removal procedure.

Scheme 41

Scheme 42

1. Disconnect the battery ground cable. Refer to BATTERY DISCONNECT . NOTE: If equipped with an automatic transaxle, apply the parking brake and position the transaxle range selector lever to the 1 position.
2. Position the instrument panel center finish panel rearward. Remove the screws. Position the instrument cluster finish panel rearward.
3. Remove the hazard flasher switch. Disconnect electrical connector. Remove the screws. Remove the hazard flasher switch.
4. To install, reverse the removal procedure.
