| A/C Compressor Bracket (Lower Bolts) | 18 (25) |
| A/C Compressor Bracket (Upper Bolts) | 35 (48) |
| A/C Compressor Mounting Bolts | 18 (25) |
| A/C Manifold & Tube Assembly Bolt | 15 (20) |
| Accessory Drive Belt Idler Pulley | 33 (45) |
| Accessory Drive Belt Tensioner | 18 (25) |
| Camshaft Journal Caps (1) | 14 (19) |
| Camshaft Sensor Bolt | 15 (20) |
| Camshaft Timing Sprocket | 50 (68) |
| Catalyst Monitor Sensor | 30 (40) |
| Catalytic Converter Bracket/Bolts | 18 (25) |
| Catalytic Converter Pipe Bracket/Bolts & Nuts | 30 (40) |
| Catalytic Converter Nuts | 35 (48) |
| Clutch Pedal Position Switch Lock Nut | 12 (16) |
| Clutch Pressure Plate (2) | 18 (25) |
| Clutch Slave Cylinder | 16 (22) |
| Coil/Coil Bracket | 15 (20) |
| Connecting Rod Caps |
| Step 1 | 26 (35) |
| Step 2 | Additional 90 Degrees |
| Coolant Tube Bolts & Nut | 15 (20) |
| Coolant Tube Stud | 18 (25) |
| Crankshaft Main Bearing Caps (3) |
| Step 1 | 18 (25) |
| Step 2 | Additional 60 Degrees |
| Crankshaft Pulley | 85 (115) |
| Cylinder Block (Lower) (4) | 22 (30) |
| Cylinder Head Bolts (5) |
| Step 1 | 15 (20) |
| Step 2 | 30 (40) |
| Step 3 | Additional 90 Degrees |
| Differential Mounting Bracket-To-Sub-Frame | 85 (115) |
| Differential-To-Bracket (Two Larger Outer Bolts) | 85 (115) |
| Differential-To-Bracket (Four Small Inner Bolts) | 59 (80) |
| EGR Tube | 18 (25) |
| EGR Tube Fitting | 47 (63) |
| Engine Mount | 41 (55) |
| Engine Mount Bracket (Lower) | 37 (50) |
| Engine Mount Bracket (Upper) Bolt | 57 (77) |
| Engine Mount Bracket (Upper) Nuts | 72 (98) |
| Engine Mount Bracket (Upper) Studs | 25 (34) |
| Exhaust Gasket Nuts | 37 (50) |
| Exhaust Manifold (6) | 12 (16) |
| Flywheel | 83 (112) |
| Fuel Pump Module | 60 (81) |
| Fuel Tank Straps | 41 (55) |
| Generator | 33 (45) |
| Generator Bracket | 35 (48) |
| Generator Bracket Smaller Top Bolt | 18 (25) |
| Generator Lower Bolts | 35 (48) |
| Ground Strap | 25 (34) |
| Intake Manifold (7) | 13 (18) |
| Knock Sensor | 15 (20) |
| Lifting Eye (Bracket) | 18 (25) |
| Lifting Eye (Front) | 26 (35) |
| Lifting Eye (Rear) | 11 (15) |
| Lower Control Arm Ball Joint Pinch Bolt & Nut | 52 (70) |
| Oil Cooler | 43 (58) |
| Oil Drain Plug | 18 (25) |
| Oil Pressure Sensor | 20 (27) |
| PCV Tube | 17 (23) |
| Power Distribution Box Electrical Connections | 9 (12) |
| Power Steering Bracket (Bolts To Engine) | 20 (27) |
| Power Steering Line Bracket Bolt | 15 (20) |
| Power Steering Mounting Bolts | 18 (25) |
| Rear Differential Mass Damper Bolts | 35 (48) |
| Spark Plugs | 11 (15) |
| Starter | 20 (27) |
| Tailpipe "U" Bolt | 37 (50) |
| Timing Belt Idler Pulley | 18 (25) |
| Timing Belt Tensioner | 18 (25) |
| Transaxle Mounting Bolts To Engine | 33 (45) |
| Transaxle Mount (Rear) | 41 (55) |
| Transaxle Mount (Through Bolt) | 66 (90) |
| Water Pump Adapter | 15 (20) |
| Water Pump Bolts | 12 (16) |
| Water Pump Pulley | 17 (23) |
| Wheel Hub Nut | 214 (290) |
| Wheel Lug Nuts | 98 (133) |
| INCH Lbs. (N.m) |
| Accelerator Cable | 80 (9) |
| Accelerator Cable Bracket | 89 (10) |
| Accelerator Pedal Mounting Bolts | 80 (9) |
| Air Cleaner Mounting Bolt | 71 (8) |
| Air Cleaner Pipe Hose Clamp | 27 (3) |
| Battery Tray Bolts | 71 (8) |
| Block Heater | 18 (2) |
| CHT Sensor | 89 (10) |
| Coolant Tube Bracket Bolt | 89 (10) |
| Cooling Fan Bolts | 89 (10) |
| Crankcase Vent Oil Separator | 89 (10) |
| Crankshaft Position Sensor | 62 (7) |
| Cruise Control Unit | 89 (10) |
| EGR Tube Bracket Bolt | 89 (10) |
| EGR Vacuum Regulator Solenoid | 62 (7) |
| EGR Valve | 80 (9) |
| Engine Appearance Cover | 53 (6) |
| EVAP Canister Bracket Assembly Bolts | 62 (7) |
| EVAP Vapor Management Valve Nuts | 89 (10) |
| Fuel Filler Tube | 89 (10) |
| Fuel Injection Supply Manifold | 89 (10) |
| Fuel Pulse Damper | 53 (6) |
| Generator Electrical Connector | 71 (8) |
| Ground Wire | 89 (10) |
| Ground Wire Line Bracket | 80 (9) |
| Heat Shield | 89 (10) |
| IAC Valve | 89 (10) |
| Ignition Coil Bolts | 53 (6) |
| Oil Level Indicator | 89 (10) |
| Oil Pan Bolts (8) |
| Step 1 | 53 (6) |
| Step 2 | 106 (12) |
| Oil Pump Cover/Screen | 89 (10) |
| PCM Ground | 80 (9) |
| PCM Mounting Bolt & Nuts | 53 (6) |
| PCM Wire Harness | 53 (6) |
| PNP Switch | 80 (9) |
| Power Steering Line Bracket | 89 (10) |
| Pressure Relief Valve | 71 (8) |
| Radiator Supports | 89 (10) |
| Splash Shield (Right Front Lower) | 80 (9) |
| Starter Power Line Nut | 106 (12) |
| Starter Connector "B" | 44 (5) |
| Thermostat Housing Bolts | 89 (10) |
| Throttle Body | 62 (7) |
| Timing Belt Cover (Inner) | 89 (10) |
| Timing Belt Cover (Lower) | 62 (7) |
| Timing Belt Cover (Upper) | 71 (8) |
| Valve Cover | 80 (9) |
| (1) Tighten the bolts in several two-turn passes. Tighten in sequence. (Scheme 63) (2) Tighten in sequence. (Scheme 64) (3) Tighten in sequence. (Scheme 65) (4) Tighten in sequence. (Scheme 66) (5) Tighten in sequence. (Scheme 67) (6) Tighten in sequence. (Scheme 68) (7) Tighten in sequence. (Scheme 69) (8) Tighten in sequence. (Scheme 70) |
