Engine - Intake-Air System [1.3L]: Overhaul Mazda RX-8 I рестайлинг

Mechanical 3 illustrations ~127 words

INTAKE MANIFOLD DISASSEMBLY/ASSEMBLY [13B-MSP]

  1. Remove the intake manifold. (See «INTAKE MANIFOLD REMOVAL/INSTALLATION [13B-MSP]»(ref-367618-S20462601902010072700000) ).
  2. Remove the APV position sensor No. 1. (See «AUXILIARY PORT VALVE (APV) POSITION SENSOR REMOVAL/INSTALLATION [13B-MSP]»(ref-367617-S41371173102010072700000) ).
  3. Remove the APV position sensor No. 2. (See «AUXILIARY PORT VALVE (APV) POSITION SENSOR REMOVAL/INSTALLATION [13B-MSP]»(ref-367617-S41371173102010072700000) ).
  4. Remove in the order indicated in the figure below.
  5. Install in the reverse order of removal.

Scheme 158

Scheme 158
Scheme 158

Scheme 159

Scheme 159: SECONDARY SHUTTER VALVE (SSV) SOLENOID VALVE INSPECTION [13B-MSP]
Scheme 159: SECONDARY SHUTTER VALVE (SSV) SOLENOID VALVE INSPECTION [13B-MSP]

Scheme 160

Scheme 160
Scheme 160
  1. Disconnect the negative battery cable.
  2. Remove the SSV solenoid valve. (See «INTAKE-AIR SYSTEM REMOVAL/INSTALLATION [13B-MSP]»(ref-367618-S14848159782010072700000) ).
  3. Inspect for airflow using the steps in the figure below. If there is any malfunction, replace the SSV solenoid valve. (See «INTAKE-AIR SYSTEM REMOVAL/INSTALLATION [13B-MSP]»(ref-367618-S14848159782010072700000) ). If as specified, carry out the "Circuit Open/Short Inspection".
