SUPPLIER IDENTIFICATION PROCEDURE
Note. The supplier can vary with the module. When asking the supplier (service center) for repair or replacement, identify the supplier and fill in the Audio Repair Order Form using the following procedures.
Identification Using The Label Or Inscribed Lettering
- Remove the audio unit.
- Verify the supplier by referring to the label attached to each unit.
Scheme 1
Scheme 2
Scheme 3
- Start the on-board diagnostic test mode.
- Identify the device and supplier codes by referring to the LCD display. NOTE: If no DTC is stored, no codes will be displayed.
Scheme 4
Scheme 5
- Start the on-board diagnostic test mode.
- While pressing the POWER button, simultaneously press the AUDIO CONT button for 2 s or more. CAUTION: Before clearing the memory, be sure to enter all of the DTCs displayed in the on-board diagnostic test mode in the Audio Repair Order Form.
- To stop the on-board diagnostic test mode, turn the ignition switch to the LOCK position.
Scheme 6
| DTC | Description |
|---|---|
| DTC 09: ER22 | BASE UNIT (PERIPHERAL CIRCUIT FOR TUNER) |
| DTC 09: ER20 | POWER SUPPLY CIRCUIT OF UNIT BASE |
| DTC 00: ER10 | CASSETTE DECK - BASE UNIT COMMUNICATION LINE |
| DTC 03: ER10 | CD PLAYER - BASE UNIT COMMUNICATION LINE |
| DTC 06: ER10 | CD CHANGER (UPPER MODULE) - BASE UNIT COMMUNICATION LINE |
| DTC 07: ER10 | MD PLAYER - BASE UNIT COMMUNICATION LINE |
| DTC 03: ER01 | CD PLAYER |
| DTC 03: ER02 | CD PLAYER |
| DTC 03: ER07 | CD PLAYER |
| DTC 00: ER01 | CASSETTE DECK |
| DTC 00: ER03 | CASSETTE DECK |
| DTC 00: ER04 | CASSETTE TAPE |
| DTC 06: ER01 | CD CHANGER (UPPER MODULE) |
| DTC 06: ER02 | CD CHANGER (UPPER MODULE) |
| DTC 06: ER07 | CD CHANGER (UPPER MODULE) |
| DTC 07: ER01 | MD PLAYER |
| DTC 07: ER02 | MD PLAYER |
| DTC 07: ER07 | MD PLAYER |
| DTC 07: ER08 | MD |
| DTC 10: ER01 | MP3 APPLICABLE CD PLAYER |
| DTC 10: ER02 | MP3 APPLICABLE CD PLAYER |
DIAGNOSTIC TROUBLE CODES (DTC) LIST
