TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Air Cleaner Housing Bolt | 12-16 (16-22) |
| Intake Manifold Bracket Bolts | 27-38 (37-51) |
| Starter Mounting Bolts | 24-33 (33-45) |
| INCH Lbs. (N.m) |
| Battery Cable Nut (Solenoid Terminal "B") | 78-113 (9-13) |
| Intake Air Duct Nut | 69-95 (8-11) |
Starting System Wiring Diagram (MX-6 2.0L A/T). Scheme 1
Scheme 1: Starting System Wiring Diagram (MX-6 2.0L A/T)
Starting System Wiring Diagram (MX-6 2.0L M/T). Scheme 2
Scheme 2: Starting System Wiring Diagram (MX-6 2.0L M/T)
Starting System Wiring Diagram (MX-6 2.5L A/T). Scheme 3
Scheme 3: Starting System Wiring Diagram (MX-6 2.5L A/T)
Starting System Wiring Diagram (MX-6 2.5L M/T). Scheme 4
Scheme 4: Starting System Wiring Diagram (MX-6 2.5L M/T)
