Lighting Systems: Removal & Installation Mazda MX-5 NC рестайлинг

Steering Column Switches 16 illustrations ~696 words

FRONT COMBINATION LIGHT REMOVAL/INSTALLATION

WARNINGIncorrect servicing of the discharge headlights could result in electrical shock. Before servicing the discharge headlights, always refer to the discharge headlight service warnings. (See DISCHARGE HEADLIGHT SERVICE WARNINGS )

Scheme 53

Scheme 53
Scheme 53

Scheme 54

Scheme 54
Scheme 54

Scheme 55

Scheme 55
Scheme 55
  1. Remove the battery cover.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
  3. Remove the front bumper. (See «FRONT BUMPER REMOVAL/INSTALLATION»(ref-430315-S08524033602011101700000) )
  4. Remove the bolt and fastener shown in the illustration.
  5. Remove the bolt shown in the illustration.
  6. Remove the bolt shown in the illustration.
  7. Disconnect the connectors shown in the illustration.
  8. Remove the front combination light.
  9. Install in the reverse order of removal.
  10. Adjust the headlight aiming. (See «HEADLIGHT AIMING»(ref-430298-S12249058822011101700000) )

Scheme 56

Scheme 56
Scheme 56

Scheme 57

Scheme 57: Halogen type
Scheme 57: Halogen type
  1. Remove the battery cover.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
  3. Remove the washer tank. (RH) (See «WASHER TANK REMOVAL/INSTALLATION»(ref-430319-S11744659452011101700000) )
  4. Remove the fasteners. (LH)
  5. Slightly bent back the mudguard.
  6. Disconnect the connector. CAUTION: A halogen bulb generates extremely high heat when it is illuminated. If the surface of the bulb is soiled, excessive heat will build up and the life of the bulb will be shortened. When replacing the bulb, hold the metal flange, not the glass.
  7. Remove the cover.
  8. Remove the socket, then remove the headlight bulb.
  9. Install in the reverse order of removal.

Discharge headlight connector removal note

  1. Rotate the discharge headlight connector in the direction of the arrow shown in the illustration to remove it.

Scheme 58

Scheme 58
Scheme 58

Discharge headlight removal note

  1. Press sections A to release the bulb retaining wire and remove the discharge headlight.

Scheme 59

Scheme 59
Scheme 59

DISCHARGE HEADLIGHT CONTROL MODULE REMOVAL/INSTALLATION

WARNINGIncorrect servicing of the discharge headlights could result in electrical shock. Before servicing the discharge headlights, always refer to the discharge headlight service warnings. (See DISCHARGE HEADLIGHT SERVICE WARNINGS )
  1. Remove the battery cable.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
  3. Remove the front bumper. (See «FRONT BUMPER REMOVAL/INSTALLATION»(ref-430315-S08524033602011101700000) )
  4. Remove the front combination light. (See «FRONT COMBINATION LIGHT REMOVAL/INSTALLATION»(ref-430298-S37364986512011101700000) )
  5. Remove screws.
  6. Disconnect the discharge headlight control module connector. (See «DISCHARGE HEADLIGHT CONTROL MODULE REMOVAL/INSTALLATION»(ref-430298-S14881229292011101700000) note)
  7. Remove the discharge headlight control module.
  8. Install in the reverse order of removal.

Scheme 60

Scheme 60
Scheme 60

Discharge headlight control module connector removal note

  1. Remove the screw shown in the illustration.
  2. Disconnect the discharge headlight control module connector.

Scheme 61

Scheme 61
Scheme 61

COMBINATION SWITCH REMOVAL/INSTALLATION

WARNINGFor vehicles with DSC, if the negative battery cable or the steering angle sensor connector or ROOM 15 A fuse is disconnected, the stored initial position of the steering angle sensor will be cleared and the DSC will not operate properly, making the vehicle unsafe to drive. Perform the steering angle sensor initialization procedure after connecting the negative battery cable.
  1. Remove the battery cover.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
  3. Remove the following parts: Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-430310-S13032094912011101700000) ) Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-430311-S39290501642011101700000) ) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-430296-S08540555702011101700000) ) Clock spring (See «CLOCK SPRING REMOVAL/INSTALLATION»(ref-430310-S39445450312011101700000) )
  4. Disconnect the connector.
  5. Disconnect the steering angle sensor connector. (Vehicles with DSC)
  6. Remove the screws and then remove the combination switch.
  7. Install in the reverse order of removal.
  8. Perform the steering angle sensor initialization procedure. (Vehicles with DSC) (See «STEERING ANGLE SENSOR INITIALIZATION PROCEDURE»(ref-430291-S11560876092011101700000) )
  9. If the steering angle sensor (combination switch body) Is replaced, perform initialization of the DSC HU/CM steering angle signal. (See «STEERING ANGLE SIGNAL INITIALIZATION PROCEDURE»(ref-430291-S11225501102011101700000) )

Scheme 62

Scheme 62
Scheme 62

LIGHT SWITCH REMOVAL/INSTALLATION

  1. Remove the battery cover.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
  3. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-430296-S08540555702011101700000) )
  4. Disconnect the connector.
  5. Remove the screws and then remove the light switch.
  6. Install in the reverse order of removal.

Scheme 63

Scheme 63
Scheme 63

DRL CONTROL MODULE REMOVAL/INSTALLATION

  1. Remove the battery cover.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
  3. Disconnect the connectors.
  4. Remove the screw and then remove the DRL control module.
  5. Install in the reverse order of removal.

Scheme 64

Scheme 64
Scheme 64

FLASHER CONTROL MODULE REMOVAL/INSTALLATION

  1. Remove the battery cover.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
  3. Disconnect the connector.
  4. Remove the screw and then remove the flasher control module.
  5. Install in the reverse order of removal.

Scheme 65

Scheme 65
Scheme 65

Map Light Removal Note

  1. Insert a tape-wrapped fastener remover into the gap between the front header trim and the map light.
  2. Press the tab, and remove the map light.

Scheme 66

Scheme 66
Scheme 66

IGNITION KEY ILLUMINATION BULB REMOVAL/INSTALLATION

  1. Remove the battery cover.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
  3. Remove the upper column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-430296-S08540555702011101700000) )
  4. Remove the ignition key illumination bulb.
  5. Install in the reverse order of removal.

Scheme 67

Scheme 67
Scheme 67

DOOR SWITCH REMOVAL/INSTALLATION

  1. Remove the battery cover.
  2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
  3. Remove the screw.
  4. Disconnect the connector and remove the door switch.
  5. Install in the reverse order of removal.

Scheme 68

Scheme 68
Scheme 68
