Discharge Headlight Service Warnings

1. To prevent electrical shock when replacing the discharge headlight, dry hands thoroughly, and carry out work in an area out of rain.
2. When the light switch is on, approx. 25, 000 V of high voltage passes through the discharge headlight. Because of the danger of electrical shock, do not insert fingers or a tester.
3. When the headlights are on, high voltage flows around the socket and discharge headlight. When turning on the discharge headlights while working, always leave the headlights in the vehicle-installed condition to prevent electrical shock.

Scheme 70

Discharge Headlight Control Module Service Warnings

1. Because of the danger of electrical shock, when inspecting with a tester, do not inspect the discharge headlight control module as a single module or disassemble it.

Scheme 71

Discharge Headlight Control Module Reuse

1. If the discharge headlight control module is dented or damaged in any way, replace the unit with a new one to prevent electrical shock and improper operation.
2. Although the unit may temporarily operate normally even though it has received an impact, it is possible that the interior may have been damaged. When reusing the module, inspect the following items regarding discharge headlight illumination to verify that there are no malfunctions. Verify that the discharge headlights illuminate normally by testing them several times under cold illumination (headlights off for approx. 10 min or more and then turned on) and hot illumination (headlights on for approx. 15 min or more, turned off for approx. 1 min, and then turned on again) conditions. Inspect the headlight illumination in the period from directly after cold illumination until they are uniformly illuminated (approx. 5 min) and verify that there is no flickering or inconsistent brightness. Turn on the headlights for approx. 30 min with normal condition discharge headlights and verify that there is no brightness difference between the right and left, and that illumination is consistent.

Discharge type

Scheme 72

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
3. Remove the washer tank. (RH) (See «WASHER TANK REMOVAL/INSTALLATION»(ref-430319-S11744659452011101700000) )
4. Remove the fasteners. (LH)
5. Slightly bent back the mudguard.
6. Remove the cover. CAUTION: The discharge headlight generates extremely high heat when it is illuminated. If the surface of the discharge headlight is soiled, excessive heat will build up and the life of the discharge headlight will be shortened. When replacing the discharge headlight, hold the metal flange, not the glass.
7. Remove the discharge headlight connector. (See «DISCHARGE HEADLIGHT CONNECTOR REMOVAL NOTE»(ref-430298-S11050040722011101700000) )
8. Remove the discharge headlight (See «DISCHARGE HEADLIGHT REMOVAL NOTE»(ref-430298-S04726815052011101700000) )
9. Install in the reverse order of removal.

High-beam

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
3. Disconnect the connector. CAUTION: A halogen bulb generates extremely high heat when it is illuminated. If the surface of the bulb is soiled, excessive heat will build up and the life of the bulb will be shortened. When replacing the bulb, hold the metal flange, not the glass.
4. Remove the socket, then remove the headlight bulb.
5. Install in the reverse order of removal.

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

1. Point the headlight beams to a wall and verify that the headlight beams are as shown in the illustration.
2. Make a screen as shown in the illustration, using double-weight, white paper.
3. Adjust the tire pressure to the specification.
4. Position the unloaded vehicle on a flat, level surface.
5. Seat one person in the driver's seat.
6. Line up the vehicle with the wall so that the center of the headlight is 3 m {9.8 ft} away from the wall.
7. Measure the height at the center of the headlight. NOTE: Since the height of the vehicle varies depending on the vehicle situation, measure the height of the center of the headlight using the actual vehicle.
8. Align the center of the headlight with the center of the screen.
9. Block the light of the other headlight using a partition.
10. Start the engine and charge the battery.
11. Turn on the headlight low beams.
12. Verify that the elbow point of the headlight is in the position indicated on the screen. If the elbow point is not in the position indicated on the screen, perform the following adjustment: Insert a Phillips driver into the position shown in the illustration and adjust the headlights.

Discharge headlight inoperative

Scheme 80

Except Power Retractable Hardtop

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
3. Remove the partition board. (See «PARTITION BOARD REMOVAL/INSTALLATION»(ref-430296-S16092932432011101700000) )
4. Disconnect the high-mount brake light connector.
5. Press the tabs and remove the clips.
6. Install in the reverse order of removal.

Scheme 81

Scheme 82

1. Fully open the deck panel.
2. Partially peel back the seal cover.
3. Disconnect the high-mount brake light connector.
4. Remove the wiring harness and connector of the high-mount brake light from the deck panel.
5. Remove the nuts.
6. Remove the high-mount brake light.
7. Install in the reverse order of removal.

Scheme 83

Scheme 84

Scheme 85

1. Remove the battery cover.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) )
3. Move the license plate light in the direction of the arrow (1) and detach the tab.
4. Pull area A of the license plate light in the direction of the arrow (2) and remove the license plate light.
5. Disconnect the connector.
6. Remove the socket by rotating it in the direction of the arrow shown in the illustration.
7. Remove the license plate light bulb.
8. Install in the reverse order of removal.

Scheme 86
