Seat System: Removal & Installation Mazda MX-5 NC рестайлинг

Seats 35 illustrations ~1150 words

SEAT BACK COMPONENT [DRIVER-SIDE] REMOVAL/INSTALLATION

WARNINGHandling a seat (with built-in side air bag) improperly can accidentally operate (deploy) the air bag which may seriously injure you. Read the service warnings before handling a seat (with built-in side air bag). (See AIR BAG SYSTEM SERVICE WARNINGS .)
CAUTIONAfter removing a seat, do not operate the slider lever. If the slider lever is operated, the left and right slide positions will deviate, and the slide adjuster may be damaged after the seat is installed. Verify that there are no malfunctions in the sliding mechanism after installing a seat. When performing the procedure with a seat removed from the vehicle, perform the procedure on a clean rag so as not to damage or soil the seat.

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8
  1. Turn the ignition switch to LOCK position.
  2. Remove the battery cover.
  3. Disconnect the negative battery cable and wait 1 min or more . (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) .)
  4. Remove the seat. (See «SEAT REMOVAL/INSTALLATION»(ref-430316-S38029062372011101700000) .)
  5. Remove the seat side cover. (See «SEAT SIDE COVER REMOVAL/INSTALLATION»(ref-430316-S03124420672011101700000) .)
  6. Disconnect the side air bag module connector, then remove the side air bag wiring harness. (See «SIDE AIR BAG CONNECTOR DISCONNECT NOTE»(ref-430316-S17816470452011101700000) )
  7. Disconnect the seat warmer connector.
  8. Lift up the cover of both sides in the direction of arrow shown in the illustration.
  9. Remove the nuts, then remove the seat back component.
  10. Install in the reverse order of removal.

Scheme 9

Scheme 9: Side Air Bag Connector Disconnect Note
Scheme 9: Side Air Bag Connector Disconnect Note
  1. Detach the tab as shown in the illustration and remove the connector from the seat connector.

Scheme 10

Scheme 10: SEAT BACK TRIM REMOVAL/INSTALLATION
Scheme 10: SEAT BACK TRIM REMOVAL/INSTALLATION

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16
  1. Turn the ignition switch to LOCK position.
  2. Remove the battery cover.
  3. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) .)
  4. Remove the screw, then remove the belt guide.
  5. Slide hook A in the direction of arrow (1), (2), (3) shown in the illustration to detach it from hook B.
  6. Open the fastener.
  7. Remove ring C, then remove the holder bracket C in the direction of arrow shown in the illustration.
  8. Pull out part A shown in the illustration to the front.
  9. Disconnect the seat warmer connector.
  10. Remove the seat back trim and the seat back pad as a single unit from the seat frame by pulling them in the direction of arrow shown in the illustration.
  11. Partially peal back the seat back trim from the seat back pad, remove rings C in the order of (4), (5), (6) and (7) shown in the illustration, then remove the seat back trim.
  12. Install in the reverse order of removal.

SEAT CUSHION TRIM REMOVAL/INSTALLATION

WARNINGHandling a seat (with built-in side air bag) improperly can accidentally operate (deploy) the air bag, which may seriously injure you. Read the service warnings before handling a seat (with built-in side air bag). (See AIR BAG SYSTEM SERVICE WARNINGS .)
CAUTIONAfter removing a seat, do not operate the slider lever. If the slider lever is operated, the left and right slide positions will deviate, and the slide adjuster may be damaged after the seat is installed. Verify that there are no malfunctions in the sliding mechanism after installing a seat. When performing the procedure with a seat removed from the vehicle, perform the procedure on a clean rag so as not to damage or soil the seat. When the passenger's seat is removed, perform the seat weight sensor inspection using the M-MDS after installing the passenger's seat. (See SEAT WEIGHT SENSOR INSPECTION .) When the passenger's seat is replaced with a new one, perform the seat weight sensor calibration using the M-MDS. (See SEAT WEIGHT SENSOR CALIBRATION .)

Scheme 17

Scheme 17: Driver-side
Scheme 17: Driver-side

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23
  1. Turn the ignition switch to LOCK position.
  2. Remove the battery cover.
  3. Disconnect the negative battery cable and wait 1 min or more . (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) .)
  4. Remove the seat. (See «SEAT REMOVAL/INSTALLATION»(ref-430316-S38029062372011101700000) .)
  5. Disconnect the connectors, then remove the side air bag wiring harness. (See «SIDE AIR BAG CONNECTOR DISCONNECT NOTE»(ref-430316-S17827074392011101700000) )
  6. Remove the bolts, then remove the seat cushion.
  7. Detach hook A as shown in the illustration in the direction of arrow (1) shown in the illustration.
  8. Detach hook B in the direction of arrow (2) shown in the illustration.
  9. Detach hook C in the direction of arrow (3) shown in the illustration.
  10. Detach hook D in the direction of arrow (4) shown in the illustration.
  11. Remove the seat cushion trim and the seat cushion pad from the seat cushion frame as a single unit.
  12. Remove rings C in the order of (5), (6), (7), (8) and (9) as shown in the illustration, then remove the seat cushion trim from the seat cushion pad in the direction of arrow shown in the illustration.
  13. Install in the reverse order of removal.

Scheme 24

Scheme 24: Passenger-side
Scheme 24: Passenger-side

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29
  1. Turn the ignition switch to LOCK position.
  2. Remove the battery cover.
  3. Disconnect the negative battery cable and wait 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) .)
  4. Remove the seat. (See «SEAT REMOVAL/INSTALLATION»(ref-430316-S38029062372011101700000) .)
  5. Remove the seat side cover. (See «SEAT SIDE COVER REMOVAL/INSTALLATION»(ref-430316-S03124420672011101700000) .
  6. Cut the bands securing the wiring harness.
  7. Disconnect the connectors, then remove the side air bag wiring harness. (See «SIDE AIR BAG CONNECTOR DISCONNECT NOTE»(ref-430316-S17827074392011101700000) )
  8. Remove rings C.
  9. Detach hook A in the direction of arrow (1) shown in the illustration.
  10. Detach hook B in the direction of arrow (2) shown in the illustration.
  11. Detach hook C from hook D in the direction of arrow (3) shown in the illustration.
  12. Remove the seat cushion trim and the seat cushion pad from the seat frame as a single unit.
  13. Remove rings C in the order of (4), (5), (6), (7) and (8) as shown in the illustration, then remove the seat cushion trim from the seat cushion pad in the direction of arrow shown in the illustration.
  14. Install in the reverse order of removal.

SEAT SIDE COVER REMOVAL/INSTALLATION

WARNINGHandling a seat (with built-in side air bag) improperly can accidentally operate (deploy) the air bag, which may seriously injure you. Read the service warnings before handling a seat (with built-in side air bag). (See AIR BAG SYSTEM SERVICE WARNINGS .)
CAUTIONAfter removing a seat, do not operate the slider lever. If the slider lever is operated, the left and right slide positions will deviate, and the slide adjuster may be damaged after the seat is installed. Verify that there are no malfunctions in the sliding mechanism after installing a seat. When performing the procedure with a seat removed from the vehicle, perform the procedure on clean rag so as not to damage or soil the seat. When the passenger's seat is removed, perform the seat weight sensor inspection using the M-MDS after installing the passenger's seat. (See SEAT WEIGHT SENSOR INSPECTION .) When the passenger's seat is replaced with a new one, perform the seat weight sensor calibration using the M-MDS. (See SEAT WEIGHT SENSOR CALIBRATION .)

Scheme 30

Scheme 30: Driver's seat
Scheme 30: Driver's seat

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35
  1. Turn the ignition switch to LOCK position.
  2. Remove the battery cover.
  3. Disconnect the negative battery cable and wait 1 min or more . (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) .)
  4. Remove the seat. (See «SEAT REMOVAL/INSTALLATION»(ref-430316-S38029062372011101700000) .)
  5. Remove the outer lift lever cover in the direction of arrow (1), (2) shown in the illustration to disengage the tab A and hook B.
  6. Remove the snap ring.
  7. Operate the lift lever in the direction of arrow (3) shown in the illustration.
  8. Using a flathead screwdriver, hold the spring and return the lift lever a bit to pull it up in the order of (4), (5) shown in the illustration.
  9. After operating the recliner knob in the upward direction (6), cut the area indicated in the illustration, then remove the recliner knob in the direction of arrow (7) shown in the illustration. CAUTION: The seat back folds forward when the recliner knob is operated. Be careful when operating the recliner knob.
  10. Remove the screw C.
  11. Remove the screw D and pull the seat side cover in the direction of arrow (8) shown in the illustration to disengage the hook E.

Scheme 36

Scheme 36: Passenger's seat
Scheme 36: Passenger's seat

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38
  1. Turn the ignition switch to LOCK position.
  2. Remove the battery cover.
  3. Disconnect the negative battery cable and wait 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) .)
  4. Remove the seat. (See «SEAT REMOVAL/INSTALLATION»(ref-430316-S38029062372011101700000) .)
  5. After operating the recliner knob in the upward direction (1), cut the area indicated in the illustration, then remove the recliner knob in the direction of arrow (2) shown in the illustration. CAUTION: The seat back folds forward when the recliner knob is operated. Be careful when operating the recliner knob.
  6. Remove the screw A.
  7. Pull the seat side cover in the direction of arrow (3) shown in the illustration to disengage the tab B.
  8. Pull the seat side cover in the direction of arrow (4) shown in the illustration to disengage the tab C.
  9. Install in the reverse order of removal.

SEAT REMOVAL/INSTALLATION

WARNINGHandling a seat (with built-in side air bag) improperly can accidentally operate (deploy) the air bag, which may seriously injure you. Read the service warnings before handling a seat (with built-in side air bag). (See AIR BAG SYSTEM SERVICE WARNINGS .)
CAUTIONAfter removing a seat, do not operate the slider lever. If the slider lever is operated, the left and right slide positions will deviate, and the slide adjuster may be damaged after the seat is installed. Verify that there are no malfunctions in the sliding mechanism after installing a seat. When performing the procedure with a seat removed from the vehicle, perform the procedure on a clean rag so as not to damage or soil the seat. When the passenger's seat is removed, perform the seat weight sensor inspection using the M-MDS after installing the passenger's seat. (See SEAT WEIGHT SENSOR INSPECTION .) When the passenger's seat is replaced with a new one, perform the seat weight sensor calibration using the M-MDS. (See SEAT WEIGHT SENSOR CALIBRATION .)

Scheme 39

Scheme 39
Scheme 39

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41
  1. Turn the ignition switch to the LOCK position.
  2. Remove the battery cover.
  3. Disconnect the negative battery cable and wait 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) .)
  4. Press connector tab A in the direction of arrow shown in the illustration.
  5. Pull out the connector lock in the direction of arrow shown in the illustration and disconnect the connector.
  6. Remove the anchor cover, (passenger-side) (See «SEAT BELT REMOVAL/INSTALLATION»(ref-430314-S08485788462011101700000) .)
  7. Remove the bolts, then remove the seat.
  8. Install in the reverse order of removal.
  9. Perform the seat weight sensor initialization procedure. (See «SEAT WEIGHT SENSOR CALIBRATION»(ref-430310-S01229725752011101700000) .)
