Seat Belt System: Removal & Installation Mazda MX-5 NC рестайлинг

Restraints Control Systems 5 illustrations ~353 words

SEAT BELT REMOVAL/INSTALLATION

WARNINGHandling the front seat belt (pre-tensioner seat belt) improperly can accidentally deploy the pretensioner seat belt, which may seriously injure you. Read the service warnings and cautions before handling the front seat belt (pre-tensioner seat belt). (See AIR BAG SYSTEM SERVICE WARNINGS .) (See AIR BAG SYSTEM SERVICE CAUTIONS .)
WARNINGThe side air bag sensor is attached to the lower part of the B-pillar. When working around the B-pillar, disconnect the negative battery cable or work carefully, avoiding excessive impact to the lower part of the B-pillar.
CAUTIONThe ELR (emergency locking retractor) has a spring that will unwind if the retractor cover is removed. The spring cannot be rewound by hand. If this occurs, the ELR will not work properly. Therefore, do not disassemble the retractor.

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4
  1. Turn the ignition switch to the LOCK position.
  2. Remove the battery cover.
  3. Disconnect the negative battery cable and wait for 1 min or more . (See «BATTERY REMOVAL/INSTALLATION [LF]»(ref-430294-S35932810402011101700000) .)
  4. Remove the following the parts: Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-430296-S42659527912011101700000) .) Quarter trim (See «QUARTER TRIM REMOVAL/INSTALLATION»(ref-430296-S19001214662011101700000) .) Scuff plate (See «SCUFF PLATE REMOVAL/INSTALLATION»(ref-430296-S23280190182011101700000) .) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-430296-S18767630022011101700000) .) Aeroboard (See «AEROBOARD REMOVAL/INSTALLATION»(ref-430296-S39585070462011101700000) .) Seat back bar garnish (front) (See «SEAT BACK BAR LOWER GARNISH REMOVAL/INSTALLATION»(ref-430296-S11299234462011101700000) .) Back trim (See «BACK TRIM REMOVAL/INSTALLATION»(ref-430296-S24537138642011101700000) .)
  5. Using a flathead screwdriver, lift the locking device carefully, however do not remove it.
  6. Disconnect the pre-tensioner seat belt connector.
  7. Insert your hand through part a shown in the illustration and pull the anchor cover outward. (passenger-side)
  8. Remove the bolt A.
  9. Remove the bolt B
  10. Remove the seat belt.
  11. Remove the retractor screen.
  12. Install in the reverse order of removal.
  13. Turn the ignition switch to the ON position.
  14. Verify that the air bag system warning light illuminates for approx. 6 s and goes out. If the air bag system warning light does not operate, refer to the on-board diagnostic system (air bag system) and perform inspection of the system. (See «FLOWCHART»(ref-478580-S20482194222012061100000) .)
  1. Verify that the belt is installed properly with no twists or kinks.
  2. Verify that there is no damage to the seat belt and no deformation of the metal fittings. If there is any malfunction, replace the seat belt.

Scheme 5

Scheme 5: ELR
Scheme 5: ELR

Scheme 6

Scheme 6
Scheme 6
  1. Verify that the belt can be pulled out smoothly, and that it retracts smoothly. If there is any malfunction, replace the seat belt.
  2. Verify that the retractor locks when the belt is pulled quickly. If there is any malfunction, replace the seat belt.
  3. Remove the retractor.
  4. While pulling the seat belt out, make sure that the seat belt does not lock when the retractor is tilted slowly up to 15 ° from the mounted position and locks when the retractor is tilted 40 ° or more . If there is any malfunction, replace the seat belt.
