Millenia, Protege & 626
Disconnect sub-switch harness connector. Check for continuity between specified sub-switch terminals with sub-switch button in specified position. See SUB-SWITCH CONTINUITY TEST table. see scheme 2or (Scheme 8). If continuity is not as specified, replace sub-switch.
| Application & Switch Position | Continuity Between Terminals | ||
|---|---|---|---|
| Millenia | |||
| UP | A & E; B & D | ||
| DOWN | B & E; D & F | ||
| Off (Neutral) | A & E; D & F | ||
| Protege | |||
| Passenger's Door | |||
| UP | B & F; C & E | ||
| DOWN | A & B; C & F | ||
| OFF (Neutral) | A & B; C & E | ||
| Rear Door | |||
| UP | A & B; D & E | ||
| DOWN | A & D; E & F | ||
| OFF (Neutral) | A & B; E & F | ||
| 626 | |||
| UP | A & E; B & C | ||
| DOWN | B & E; C & F | ||
| OFF (Neutral) | A & E; C & F | ||
SUB-SWITCH CONTINUITY TEST
Scheme 8
WINDOW MOTOR
| WARNING | Window regulator is spring-loaded to assist window motor during upward movement. Before separating window motor from regulator, securely position regulator arms in full-up position (if possible). This will relieve spring pressure as much as possible, preventing injury when window motor is separated from regulator. |
