OIL PAN GASKET

Note. For oil pan gasket identification, refer to illustrations. (Scheme 6)- (Scheme 11).

Identifying Oil Pan Gasket (FN4A-EL). Scheme 6

Identifying Oil Pan Gasket (GF4A-EL). Scheme 7

Identifying Oil Pan Gasket (LA4A-EL). Scheme 8

Identifying Oil Pan Gasket (LJ4A-EL). Scheme 9

Identifying Oil Pan Gasket (SB4A-EL). Scheme 10

Identifying Oil Pan Gasket (4R44E & 5R55E). Scheme 11

Transmission

Park vehicle on level ground. Apply parking brake. Warm engine to normal operating temperature. Briefly place selector lever in all gears, and then return to "P" position. Clean dipstick and insert in tube. Remove dipstick. On B-Series and 626, fluid level should be within crosshatched area on dipstick. On all others, fluid level should be between top and bottom notches on dipstick near bottom. Check fluid for discoloration and unusual smell. If necessary, add fluid. DO NOT overfill.

Transfer Case (B-Series 4WD)

Remove oil fill plug. If fluid is level with opening, install fill plug. If fluid is low, fill until fluid is level with fill plug opening. Install plug.

Transmission (B-Series)

Use Mazda ATF Type 5 or equivalent.

Transmission (Except B-Series)

Use Mercon III or M-III ATF.

Transfer Case (BW 1354)

Use Mercon III or M-III ATF.

B-Series

Raise and support vehicle. Loosen all oil pan bolts, except for 2 front bolts. Pry rear of oil pan in downward direction and allow fluid to drain into proper container. Remove remaining bolts from oil pan. Remove oil pan and discard old gasket. Remove bolt and oil filter screen. Clean and inspect oil pan and magnet. Lubricate o-rings with transmission fluid, and install onto oil filter screen. Clean oil pan and position magnet onto oil pan. Install oil pan using NEW gasket. Tighten oil pan bolts to specification, using crisscross pattern. See TORQUE SPECIFICATIONS . Add 4 qts. (3.8L) of Mazda ATF Type 5 transmission fluid. DO NOT overfill. Start engine, and shift transmission through all gears, ending in "P" position. With engine idling, check fluid level.

Except B-Series

Remove transmission dipstick. Remove drain plug from oil pan or transaxle case and allow fluid to drain into proper container. If oil pan is removed, discard old oil pan gasket. Clean oil pan and install using NEW gasket. Tighten bolts to specification. See TORQUE SPECIFICATIONS . Install NEW washer to drain plug. Add transmission fluid through dipstick tube. DO NOT overfill. Start engine, and shift transmission through all gears, ending in "P" position. With engine idling, check fluid level.

1. Place gearshift lever in "D" position. Hang a 3-lb. (1.3 kg) weight on gearshift lever. Move gearshift lever to "1" position, then back 2 detents to "D" position. Hang an 8-lb. (3.63 kg) weight on gearshift lever. Raise and support vehicle. Disconnect shifter cable from manual control lever. Pull out lock tab on shifter cable. Remove shifter cable from manual control lever. Place manual control lever in "D" position.
2. Rotate manual control lever fully counterclockwise, then rotate manual control lever clockwise to 2 detents to "D" position. Connect shifter cable to manual control lever. Push up on lock tab to lock cable in adjusted position. Remove weight from gearshift lever. Move gearshift lever through all positions, ensuring transmission is at full detent in each position.

MX-5 Miata

1. Remove rear console, gearshift lever knob, sleeve, and indicator panel. Loosen lock nut on gearshift lever. (Scheme 12) Place gearshift lever in "P" position by pushing adjustment lever forward.
2. Adjust lever so clearance between guide plate and guide pin are within tolerances, with push rod slightly depressed. (Scheme 13) Move gearshift lever from "N" to "D" position. Verify same clearance is between guide plate and guide pin. Install indicator panel, sleeve, gearshift lever knob and rear console.

Scheme 12

Scheme 13

Millenia

Remove air cleaner assembly. Place gearshift lever in "P" position. Loosen gearshift lever cable mounting nut at transaxle. Push cable toward cable bellows and hold in position. Center nut on cable in a no-load position. (Scheme 14) Tighten cable mounting nut to 12-16 ft. lbs. (16-22 N.m). Install air cleaner assembly. Move gearshift lever through all positions ensuring no components interfere with gearshift lever.

Scheme 14

MPV

Move gearshift lever to "P" position. Remove steering column covers. Loosen nut on gearshift lever. Pull gearshift lever rearward to "R" position, to side gate of "P" position. Tighten nut on gearshift lever to 12-16 ft. lbs. (16-22 N.m). Verify gearshift lever nut is exposed from nut at appropriate distance. (Scheme 15) Install steering column covers.

Scheme 15

Protege & 626

Remove center console. Place gearshift lever in "P" position. Unlock gearshift lever cable by sliding lock cover in direction as shown. (Scheme 16) Disconnect set button. Ensure gearshift lever is in "P" position on 626 2.5L, or "D" position on 626 2.3L. Connect set button. Lock gearshift lever cable by sliding lock cover in direction shown. Install center console. Move gearshift lever through all positions ensuring no components interfere with gearshift lever.

Scheme 16

INTERMEDIATE & OVERDRIVE BAND

Raise and support vehicle. Remove shifter cable and transmission range sensor. Remove and discard band lock nut. Using torque wrench, tighten band adjustment screw to 10 ft. lbs. (14 N.m). Back off band adjustment screw exactly 2 turns, and hold it so that it does not turn. Apply petroleum jelly to lock nut seal, and install NEW band lock nut. While holding band adjustment screw stationary, tighten band lock nut to 35-45 ft. lbs. (48-61 N.m). (Scheme 17) Install shifter cable and transmission range sensor. Lower vehicle.

Scheme 17

Loosen adjusting nuts "A" and "B". With throttle lever closed, adjust nut "B" in direction of arrow. (Scheme 18) Ensure cable does not come off bracket. Tighten both nut "A" and "B" by hand. With throttle lever in closed position, tighten nut "A" to 9-12 ft. lbs. (12-16 N.m). Ensure throttle cable moves smoothly. Ensure that there is no deflection or slack in throttle cable. Ensure throttle cable adjustment is.03-.05" (.8-1.5 mm) at dimension "C" with throttle and throttle cable in closed position. (Scheme 18)

Scheme 18

Place gearshift lever in "N" position. Remove nut retaining manual control outer lever and remove lever from manual shaft. Loosen Transmission Range (TR) sensor retaining bolts. Install Range Sensor Adjustor (307-351). (Scheme 19) Tighten TR sensor retaining bolts to 70-96 INCH lbs. (8-11 N.m). Install manual control outer lever and nut. Tighten nut to 30-40 ft. lbs. (41-54 N.m). Check for park gear engagement. Ensure vehicle only starts in "P" and "N" position, and back-up lights operate.

Scheme 19

Millenia (With LJ4A-EL Transmission)

1. Place gearshift lever in "N". Loosen TR switch mounting bolts. Rotate TR switch and insert a 5/32" alignment pin. Tighten TR switch mounting bolts to 22-34 INCH lbs. (3-4 N.m). Remove alignment pin.
2. Using a DVOM, check for continuity between TR switch terminals "B" and "H". (Scheme 20) If continuity does not exist, replace TR switch. Install selector rod to manual shaft lever.

Millenia, MPV & 626 (With GF4A-EL Transaxle)

Disconnect negative battery cable. Remove air cleaner assembly. Remove spring pin and clip and disconnect selector cable. Rotate manual shaft to "N" position. Disconnect Transaxle Range (TR) switch connector. Loosen TR switch mounting bolts. Using a DVOM, check for continuity between TR switch terminals "A" and "H". (Scheme 20) Adjust TR switch until continuity exists. Tighten TR switch mounting bolts to 70-96 INCH lbs. (8-11 N.m). Ensure TR switch and gearshift lever position are aligned. Connect TR switch connector, and selector cable. Install air cleaner assembly. Connect negative battery cable.

Protege

1. Disconnect negative battery cable. Remove battery, air cleaner assembly and battery tray. Remove splash shield. Remove clip and disconnect selector cable. Rotate manual shaft toward converter housing side fully, then rotate 2 notches to place shaft in "N" position. Disconnect Transaxle Range (TR) switch connector. Loosen TR switch mounting bolts.
2. Using a DVOM, check for continuity between TR switch terminals "A" and "H". (Scheme 20) Slowly rotate TR switch until continuity exists. Tighten TR switch mounting bolts to 70-96 INCH lbs. (8-11 N.m). Ensure TR switch and gearshift lever position are aligned. Connect TR switch connector, and selector cable. Install splash shield, air cleaner assembly, battery tray and battery. Connect negative battery cable.

Scheme 20

Disconnect negative battery cable. Remove selector rod from manual shaft lever. Rotate manual shaft to "N" position. Loosen sensor bolt. Align cut groove in switch to neutral reference line. (Scheme 21) Tighten sensor bolt to 35-60 INCH lbs. (4.0-6.8 N.m). Install selector rod to manual shaft lever. Connect negative battery cable.

Scheme 21

626 (With LA4A-EL Transaxle)

Disconnect negative battery cable. Remove battery, air cleaner assembly and battery tray. Place transaxle into "N" position. Loosen Transaxle Range (TR) switch mounting bolts. Install TR switch Alignment Tool (49 UN01 086) onto TR switch and align TR switch housing and manual shaft. (Scheme 22) Tighten TR switch mounting bolts to 97-115 INCH lbs. (11-13 N.m). Install air cleaner assembly, battery tray, and battery. Connect negative battery cable.
