Lighting Systems: Wiring Mazda MPV II рестайлинг

DRL SYSTEM WIRING DIAGRAM

For DRL system wiring diagrams, see HEADLIGHTS .

Scheme 56

Scheme 57

Scheme 58

1. Measure the voltage at the DRL control module terminals as indicated below.
2. Disconnect the DRL control module connector before inspecting for continuity at terminal 1E. If not as specified, inspect the parts listed under "Action." If the parts and wiring harnesses are okay but the system still does not work properly, replace the DRL control module.

Scheme 59

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the table/figure. REMOVING/INSTALLING MAP LIGHT -WITH SLIDING SUNROOF (1) Component/Step No. Component Description 1 Map light 2 Connector 3 Lens (See «LENS REMOVAL NOTE»(ref-178124-S07453247532005061100000) ) 4 Map light bulb (1) (Scheme 61)
3. Install in the reverse order of removal.

Scheme 60

1. Push the hooks of the lens using a tape-wrapped flathead screwdriver, and remove the lens.

Scheme 61

Scheme 62

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the table/figure. REMOVING/INSTALLING MAP LIGHT - WITHOUT SLIDING SUNROOF (OVERHEAD STORAGE COMPARTMENT) (1) Component/Step No. Component Description 1 Screw 2 Overhead Console 3 Connector 4 Lens (See «LENS REMOVAL NOTE»(ref-178124-S07453247532005061100000) ) 5 Map light bulb 6 Holder (1) (Scheme 63) REMOVING/INSTALLING MAP LIGHT - WITHOUT SLIDING SUNROOF (WITHOUT OVERHEAD STORAGE COMPARTMENT) (1) Component/Step No. Component Description 1 Map Light 2 Connector 3 Lens (See «LENS REMOVAL NOTE»(ref-178124-S07453247532005061100000) ) 4 Map Light Bulb (1) (Scheme 64)
3. Install in the reverse order of removal.

Scheme 63

Scheme 64

1. Push the hooks of the lens using a tape-wrapped flathead screwdriver, and remove the lens.

Scheme 65

Scheme 66

1. Remove the map light. (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-178124-S29974775072005061100000) .)
2. Inspect for continuity between the map light terminals using an ohmmeter. If not as specified, replace the map light.

Scheme 67

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the table/figure. REMOVING/INSTALLING INTERIOR LIGHT (1) Component/Step No. Component Description 1 Interior Light 2 Connector 3 Lens (See «LENS REMOVAL NOTE»(ref-178124-S20448431562005061100000) ) 4 Interior Light Bulb (1) (Scheme 69)
3. Install in the reverse order of removal.

Scheme 68

1. Insert a tape-wrapped flathead screwdriver into the service hole.
2. Push the hooks to remove the lens.

Scheme 69

Scheme 70

1. Remove the interior light. (See «INTERIOR LIGHT REMOVAL/INSTALLATION»(ref-178124-S37809582752005061100000) .)
2. Inspect for continuity between the interior light terminals using an ohmmeter. If not as specified, replace the interior light.

Scheme 71

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the table/figure. REMOVING/INSTALLING COURTESY LIGHT BULB (1) Component/Step No. Component Description 1 Lens (See «Lens Removal Note»(ref-178124-S38864187292005061100000) ) 2 Courtesy Light Bulb (1) (Scheme 73)
3. Install in the reverse order of removal.

Scheme 72

1. Using a tape-wrapped flathead screwdriver, unhook the hooks.

Scheme 73

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the table/figure. REMOVING/INSTALLING CARGO COMPARTMENT LIGHT (1) Component/Step No. Component Description 1 Cargo Compartment Light (See «Cargo Compartment Light Removal Note»(ref-178124-S32464911162005061100000) ) 2 Connector (1) (Scheme 75)
3. Install in the reverse order of removal.

Scheme 74

1. Insert a tape-wrapped flathead screwdriver into the service hole.
2. Press the clip with the flathead screwdriver to remove the cargo compartment light.

Scheme 75

Scheme 76

1. Remove the cargo compartment light. (See «CARGO COMPARTMENT LIGHT REMOVAL/INSTALLATION»(ref-178124-S08616821302005061100000) .)
2. Inspect for continuity between the cargo compartment light terminals using an ohmmeter. If not as specified, replace the cargo compartment light.

Scheme 77

1. Disconnect the negative battery cable.
2. Remove the column cover.
3. Remove the ignition key illumination bulb.
4. Install in the reverse order of removal.

Scheme 78

1. Disconnect the negative battery cable.
2. Remove the console. (See CONSOLE REMOVAL/INSTALLATION.)
3. Remove in the order indicated in the table/figure. REMOVING/INSTALLING FRONT ASHTRAY ILLUMINATION BULB (1) Component/Step No. Component Description 1 Clip 2 Socket 3 Front Ashtray Illumination Bulb (1) (Scheme 80)
4. Install in the reverse order of removal.

Scheme 79

Scheme 80

1. Disconnect the negative battery cable.
2. Remove the sunvisor.
3. Insert a tape-wrapped flathead screwdriver into the service hole.
4. Twist the flathead screwdriver to remove the lens.
5. Remove the vanity mirror illumination bulb.
6. Install in the reverse order of removal.

Scheme 81

Scheme 82

1. Remove the sunvisor.
2. Inspect for continuity between the vanity mirror illumination terminals using an ohmmeter. If not as specified, replace the sunvisor.

Scheme 83

1. Disconnect the negative battery cable.
2. Remove the glove compartment. (See GLOVE COMPARTMENT REMOVAL/INSTALLATION .)
3. Remove the socket and the glove compartment light bulb.
4. Install in the reverse order of removal.

Scheme 84

1. Disconnect the negative battery cable.
2. Remove the driver-side side panel.
3. Remove in the order indicated in the table/figure. REMOVING/INSTALLING PANEL LIGHT CONTROL SWITCH (1) Component/Step No. Component Description 1 Panel light control switch (See «PANEL LIGHT CONTROL SWITCH REMOVAL NOTE»(ref-178124-S04605281202005061100000) ) 2 Connector (1) see scheme 72
4. Install in the reverse order of removal.
