Lighting Systems: Overview Mazda MPV II рестайлинг

Scheme 1

Scheme 2

Scheme 3

1. Disconnect the negative battery cable.
2. Remove the front bumper. (See FRONT BUMPER REMOVAL/INSTALLATION.)
3. Remove in the order indicated in the table/figure. REMOVING/INSTALLING FRONT COMBINATION LIGHT (1) Component/Step No. Component Description 1 Connector 2 Bolt 3 Fastener 4 Bracket 5 Front Combination Light (1) (Scheme 3)
4. Install in the reverse order of removal.
5. Adjust the headlight aiming. (See «HEADLIGHT ADJUSTMENT»(ref-178124-S32517349122005061100000).)

Scheme 4

1. Adjust the tire air pressure to the specification.
2. Position the unloaded vehicle on a flat, level surface.
3. Seat one person in the driver's seat.
4. Position the vehicle straight ahead and perpendicularly to a wall.
5. Set the headlights 3 m {10 ft} from the white screen.
6. While adjusting one headlight, disconnect the connector of the other.
7. Start the engine to charge the battery.
8. Adjust the headlights by turning the adjusting screws as shown in the figure. Loosen the screws first, then tighten them.
