Entertainment System: Overview Mazda MPV II рестайлинг

Scheme 62

Scheme 63

Scheme 64

Scheme 65

1. Disconnect the negative battery cable.
2. Remove the antenna mast.
3. Remove the mounting nut and base using snap-ring pliers.
4. Remove the passenger-side side panel. (See SIDE PANEL REMOVAL/INSTALLATION .)
5. Disconnect the antenna plug.
6. Partially peel off the right side mud guard.
7. Remove the bolt, then remove the antenna.

Scheme 66

1. Tape the antenna plug to the string.
2. Pass the antenna and string through the hole in the front fender.
3. Install the bolt, then install the antenna.
4. Connect the antenna plug.
5. Install the passenger-side side panel. (See SIDE PANEL REMOVAL/INSTALLATION .)
6. Install the mounting nut and base.
7. Install the antenna mast.
8. Connect the negative battery cable.

Scheme 67

Scheme 68

1. Disconnect the antenna plug.
2. Verify that there is no continuity between the antenna terminals as shown using an ohmmeter. If not as specified, replace the antenna.
3. Verify that there is continuity between the antenna terminals as shown using an ohmmeter. If not as specified, replace the antenna.

Scheme 69

1. Disconnect the negative battery cable.
2. Remove the front door trim. (See FRONT DOOR TRIM REMOVAL/INSTALLATION .)
3. Remove the screws.
4. Disconnect the connector and remove the front door speaker.
5. Install in the reverse order of removal.

Scheme 70

Scheme 71

1. Remove the front door speaker.
2. Inspect for resistance between the front door speaker terminals using an ohmmeter. Touch the leads of an ohmmeter to the front door speaker terminals and verify that the front door speaker clicks. If not as specified, replace the front door speaker.

Scheme 72

1. Disconnect the negative battery cable.
2. Remove the rear side trim. (See REAR SIDE TRIM REMOVAL/INSTALLATION .)
3. Remove the screws.
4. Disconnect the connector and remove the rear speaker.
5. Install in the reverse order of removal.

Scheme 73

Scheme 74

1. Remove the rear speaker.
2. Inspect for resistance between the rear speaker terminals using an ohmmeter. Touch the leads of an ohmmeter to the rear speaker terminals and verify that the rear speaker clicks. If not as specified, replace the rear speaker.

Scheme 75

1. Disconnect the negative battery cable.
2. Remove the A-pillar trim. (See A-PILLAR TRIM REMOVAL/INSTALLATION .)
3. Remove in the order indicated in the table/figure. REMOVING/INSTALLING FRONT TWEETER Component/Step No. Component Description 1 Front tweeter (See «FRONT TWEETER REMOVAL NOTE»(ref-178066-S04296981442005061000000) ) 2 Connector
4. Install in the reverse order of removal.

Scheme 76

1. Insert a hand between the A-pillar and the dashboard, then compress the hooks of the front tweeter from the back of the dashboard.

Scheme 77

Scheme 78

1. Remove the front tweeter.
2. Inspect for resistance between the front tweeter terminals using an ohmmeter. Touch the leads of an ohmmeter to the front tweeter terminals and verify that the front tweeter clicks. If not as specified, replace the front tweeter.

Scheme 79

1. Disconnect the negative battery cable.
2. Remove the rear side trim. (See REAR SIDE TRIM REMOVAL/INSTALLATION .)
3. Remove in the order indicated in the table/figure. REMOVING/INSTALLING REAR TWEETER Component/Step No. Component Description 1 Connector 2 Screw 3 Rear tweeter
4. Install in the reverse order of removal.

Scheme 80

Scheme 81

1. Remove the rear tweeter.
2. Inspect for resistance between the rear tweeter terminals using an ohmmeter. Touch the leads of an ohmmeter to the rear tweeter terminals and verify that the rear tweeter clicks. If not as specified, replace the rear tweeter.

Scheme 82

1. Disconnect the negative battery cable.
2. Remove the driver-side rear side trim. (See REAR SIDE TRIM REMOVAL/INSTALLATION .)
3. Remove in the order indicated in the table/figure. REMOVING/INSTALLING WOOFER Component/Step No. Component Description 1 Connector 2 Bolt 3 Woofer
4. Install in the reverse order of removal.

Scheme 83

Scheme 84

1. Remove the driver-side rear speaker.
2. Inspect the rear speakers. (See «REAR SPEAKER INSPECTION»(ref-178066-S33968476502005061000000) .)
3. Disconnect the woofer connector.
4. Inspect continuity between the rear speaker terminals and the woofer terminals using an ohmmeter. If not as specified, replace the related wiring harnesses.
5. Verify that there is battery positive voltage at woofer connector terminal H using a voltmeter. If not as specified, replace the related wiring harnesses.
6. Inspect continuity between woofer connector terminal J and body ground using an ohmmeter. If not as specified, replace the related wiring harnesses.

Scheme 85

1. Disconnect the negative battery cable.
2. Remove the audio unit. (See «AUDIO UNIT REMOVAL/INSTALLATION»(ref-178066-S24938864122005061000000) .)
3. Remove the passenger-side side panel. (See SIDE PANEL REMOVAL/INSTALLATION .)
4. Disconnect the connection between the antenna and the antenna feeder.
5. Remove in the order indicated in the table/figure. REMOVING/INSTALLING ANTENNA FEEDER Component/Step No. Component Description 1 Clip 2 Antenna feeder
6. Install in the reverse order of removal.

Scheme 86

Scheme 87

1. Disconnect the connection between the antenna and the antenna feeder.
2. Verify that there is no continuity between the antenna feeder terminals A and B using an ohmmeter. If not as specified, replace the antenna feeder.
3. Inspect for continuity between the antenna feeder terminals using an ohmmeter. If not as specified, replace the antenna feeder.

Scheme 88

1. Disconnect the negative battery cable.
2. Remove the meter hood. (See METER HOOD REMOVAL/INSTALLATION .)
3. Remove in the order indicated in the table/figure. REMOVING/INSTALLING AUDIO UNIT Component/Step No. Component Description 1 Screw 2 Connector 3 Audio unit CAUTION: Make certain that the wiring harness and antenna feeder are not caught between the unit and dashboard. If the harness or the antenna feeder is caught between the unit and dashboard, it may cause trouble or malfunctions.
4. Install in the reverse order of removal.

Scheme 89

1. Disconnect the negative battery cable.
2. Remove the audio unit. (See «AUDIO UNIT REMOVAL/INSTALLATION»(ref-178066-S24938864122005061000000) .)
3. Remove in the order indicated in the table/figure. REMOVING/INSTALLING UPPER MODULE Component/Step No. Component Description 1 Screw (See «SCREW INSTALLATION NOTE»(ref-178066-S17891749472005061000000) ) 2 Upper module (See «UPPER MODULE REMOVAL NOTE»(ref-178066-S12176390212005061000000) ) 3 Cover (See «COVER REMOVAL NOTE»(ref-178066-S04903743982005061000000) )
4. Install in the reverse order of removal.

Scheme 90

1. Insert a screwdriver into the hole stamped mark.
2. To remove upper module, lift it by pushing down the screwdriver's handle.

Scheme 91

1. Insert a tape-wrapped screwdriver between the cover and the base unit, then unlatch hook A.
2. To unlatch hook B, pull the cover upward.
