Scheme 45
Scheme 46
- Position a dial indicator against the wheel hub.
- Push and pull the wheel hub by hand in the axial direction and measure the wheel bearing play. Maximum wheel bearing play 0.05 mm {0.002 in}
- If the bearing play exceeds the specification, replace and tighten the lockout to the specified torque and retest. Replace the wheel bearing if necessary.
Scheme 47
Scheme 48
- Remove the hub bolt using the SSTs. NOTE: If the dust cover interferes with the wheel hub bolt and the wheel hub bolt cannot be removed. Tap the part shown in the figure with a chisel lightly and bend the processing point back to the steering knuckle side.
- Install the hub bolt into the wheel hub and install a washer and hub nut on the hub bolt.
- Tighten the hub nut while holding the wheel hub using a brass bar.
