Power Tilt Steering Column: Removal & Installation Mazda Millenia I рестайлинг

Removal & Installation

1. Remove combination switch. Remove in order indicated in illustration. (Scheme 7)
2. Reverse order to install.

Scheme 7

Tilt Switch Removal Note

1. Remove screws. Release tabs of tilt switch from turn lever boot.
2. Slide tilt switch in direction indicated by arrow, then remove it along turn lever. (Scheme 8)

Scheme 8

Tilt Switch Installation Note

After installing tilt switch, route harnesses of combination switch as shown in illustration. (Scheme 9)

Scheme 9

Scheme 10

Scheme 11

1. Set harness length from shaft contact portion as shown in illustration. (Scheme 10)
2. Install band clip as shown in illustration. (Scheme 11)

1. Remove in order indicated in illustration. (Scheme 12)
2. Install in reverse order of removal.

Scheme 12
