SPECIFICATIONS
| Application | Specification |
|---|
| Compressor Type | (1) Panasonic Rotary Vane |
| Compressor Belt Deflection |
| 2.3L Engine | (2) |
| 2.5L Engine (3) |
| New | .22-.25" (5.5-6.5 mm) |
| Used | .26-.29" (6.5-7.5 mm) |
| Compressor Oil Capacity (4) | 5.9 ozs. |
| Refrigerant (R-134a) Capacity | 26.5 ozs. |
| System Operating Pressures (5) |
| High Side | 170-220 psi (11.9-15.5 kg/cm 2 |
| Low Side | 14-21 psi (1.0-1.5 kg/cm 2 |
| (1) Check underhood A/C specification label or A/C compressor label. (2) Automatic belt tensioner is used. (3) Measure with 22 lbs. (10 kg) pressure applied midway on longest belt run. (4) Use ATMOS GU-10 (PAG) refrigerant oil. (5) With ambient temperature at about 77°F (25°C). |
| (1) | Check underhood A/C specification label or A/C compressor label. |
| (2) | Automatic belt tensioner is used. |
| (3) | Measure with 22 lbs. (10 kg) pressure applied midway on longest belt run. |
| (4) | Use ATMOS GU-10 (PAG) refrigerant oil. |
| (5) | With ambient temperature at about 77°F (25°C). |
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Compressor Mounting Bolt | 12-16 (16-22) |
| Refrigerant Line Fitting |
| Condenser | 12-21 (16-29) |
| Low Pressure Hose | 19-28 (26-39) |
| INCH Lbs. (N.m) |
| Air Bag Module Bolt |
| Driver-Side | 61-87 (6.9-9.8) |
| Compressor Head Bolt (2.3L Engine) |
| Top Bolt (4) | 78- 104 (8.9-11.7) |
| Back Bolt (2) | 113-156 (12.8-17.6) |
| Pressure Switch | 78-95 (8.9-10.7) |
| Refrigerant Line Fitting |
| Compressor | 57-82 (6.4-9.3) |
| Receiver-Drier | 70-173 (7.9-19.6) |
Automatic A/C-Heater System Wiring Diagram (2000 Millenia With 2.3L Engine - 1 Of 2). Scheme 1
Scheme 1: Automatic A/C-Heater System Wiring Diagram (2000 Millenia With 2.3L Engine - 1 Of 2)
Automatic A/C-Heater System Wiring Diagram (2000 Millenia With 2.3L Engine - 2 Of 2). Scheme 2
Scheme 2: Automatic A/C-Heater System Wiring Diagram (2000 Millenia With 2.3L Engine - 2 Of 2)
Automatic A/C-Heater System Wiring Diagram (2000 Millenia With 2.5L Engine - 1 Of 2). Scheme 3
Scheme 3: Automatic A/C-Heater System Wiring Diagram (2000 Millenia With 2.5L Engine - 1 Of 2)
Automatic A/C-Heater System Wiring Diagram (2000 Millenia With 2.5L Engine - 2 Of 2). Scheme 4
Scheme 4: Automatic A/C-Heater System Wiring Diagram (2000 Millenia With 2.5L Engine - 2 Of 2)
Automatic A/C-Heater System Wiring Diagram (2001 Millenia With 2.3L Engine - 1 Of 2). Scheme 5
Scheme 5: Automatic A/C-Heater System Wiring Diagram (2001 Millenia With 2.3L Engine - 1 Of 2)
Automatic A/C-Heater System Wiring Diagram (2001 Millenia With 2.3L Engine - 2 Of 2). Scheme 6
Scheme 6: Automatic A/C-Heater System Wiring Diagram (2001 Millenia With 2.3L Engine - 2 Of 2)
Automatic A/C-Heater System Wiring Diagram (2001 Millenia With 2.5L Engine - 1 Of 2). Scheme 7
Scheme 7: Automatic A/C-Heater System Wiring Diagram (2001 Millenia With 2.5L Engine - 1 Of 2)
Automatic A/C-Heater System Wiring Diagram (2001 Millenia With 2.5L Engine - 2 Of 2). Scheme 8
Scheme 8: Automatic A/C-Heater System Wiring Diagram (2001 Millenia With 2.5L Engine - 2 Of 2)
