Power Systems: Other Mazda CX-9 I

Ignition Switch/steering Lock 11 illustrations ~222 words

FUSE SERVICE CAUTIONS

CAUTIONDetermine and correct the cause of the burnt fuse before replacing it with the specified type, if the fuse is replaced before doing this, it may burn again.

Scheme 4

Scheme 4: MAIN FUSE REMOVAL/INSTALLATION
Scheme 4: MAIN FUSE REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the main fuse block cover.
  3. Remove in the order indicated in the table.
  4. Install in the reverse order of removal.

Scheme 5

Scheme 5: IGNITION SWITCH REMOVAL/INSTALLATION
Scheme 5: IGNITION SWITCH REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the column cover. See «COLUMN COVER REMOVAL/INSTALLATION»(ref-345331-S39771315522009102000000) .
  3. Remove in the order indicated in the table.
  4. Install in the reverse order of removal.

Scheme 6

Scheme 6: IGNITION SWITCH INSPECTION
Scheme 6: IGNITION SWITCH INSPECTION

Scheme 7

Scheme 7
Scheme 7
  1. Verify that the continuity between the ignition switch terminals is as indicated in the table. If not as indicated in the table, replace the ignition switch.

Scheme 8

Scheme 8: KEY REMINDER SWITCH REMOVAL/INSTALLATION
Scheme 8: KEY REMINDER SWITCH REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Remove the column cover. See «COLUMN COVER REMOVAL/INSTALLATION»(ref-345331-S39771315522009102000000) .
  3. Disconnect the key reminder switch connector.
  4. Remove the key reminder switch.
  5. Install in the reverse order of removal.

Scheme 9

Scheme 9: KEY REMINDER SWITCH INSPECTION
Scheme 9: KEY REMINDER SWITCH INSPECTION

Scheme 10

Scheme 10
Scheme 10
  1. Disconnect the negative battery cable.
  2. Remove the column cover. See «COLUMN COVER REMOVAL/INSTALLATION»(ref-345331-S39771315522009102000000) .
  3. Disconnect the key reminder switch connector.
  4. Inspect for continuity between the key reminder switch terminals using a tester. If there is any malfunction, replace the key reminder switch.

Relay type

Terminal typePart name
4 terminalsType AMain relay No. 1 Fuel pump relay Rear window defroster relay Starter relay Back-up light relay A/C relay TNS relay Horn relay Seat warmer relay RH H/L HI relay Main relay No. 2 H/L LOW relay Seat warmer relay LH Front fog light relay
Type BFront blower relay Rear blower relay Fan relay Cooling fan relay No. 1 Cooling fan relay No. 2

RELAY TYPE REFERENCE

Scheme 11

Scheme 11: Type A
Scheme 11: Type A

Scheme 12

Scheme 12
Scheme 12
  1. Verify the continuity between the relay terminals. If not as indicated in the table, replace the relay.

Scheme 13

Scheme 13: Type B
Scheme 13: Type B

Scheme 14

Scheme 14
Scheme 14
  1. Verify the continuity between the relay terminals. If not as indicated in the table, replace the relay.
