STEERING LOCK UNIT INSPECTION

  1. Measure the voltage at each terminal is as indicated in the Terminal Voltage Tables. If the voltage is not as specified in the Terminal Voltage Table (Reference), inspect the parts under "Inspection item(s)" and related wiring harnesses.
  2. If the system does not work properly even though the inspection items or related wiring harnesses do not have any malfunction, replace the steering look unit.

Scheme 2

Scheme 2: Terminal Voltage Table (Reference)
TerminalSignal nameConnected toMeasured conditionVoltage (V)Inspection item(s)
CInterior light power supplyBCM Ignition key illuminationUnder any conditionB+Ignition key illumination bulb BCM (See BODY CONTROL MODULE (BCM) INSPECTION ) Related wiring harnesses
DIgnition key illumination controlBCM Ignition key illuminationIgnition switch off and driver side door opened.1.0 or lessIgnition key illumination bulb BCM (See BODY CONTROL MODULE (BCM) INSPECTION ) Related wiring harnesses
15 s or more after all doors closed.B+
EPush switch signalKeyless control moduleStart knob pressedB+Keyless control module (See KEYLESS CONTROL MODULE INSPECTION [ADVANCED KEYLESS SYSTEM] ) Related wiring harnesses
Start knob released1.0 or less
FPower supplyBCMUnder any conditionB+BCM (See BODY CONTROL MODULE (BCM) INSPECTION ) Related wiring harnesses
GKey reminder switch signalKeyless control moduleKey insertedB+Keyless control module (See KEYLESS CONTROL MODULE INSPECTION [ADVANCED KEYLESS SYSTEM] ) Related wiring harnesses
Key removed1.0 or less
IPower supplyBCMUnder any conditionB+BCM (See BODY CONTROL MODULE (BCM) INSPECTION ) Related wiring harnesses
KSerial communicationKeyless control moduleBecause this terminal is for communication, good/no good judgment by terminal voltage is not possible.Keyless control module (See KEYLESS CONTROL MODULE INSPECTION [ADVANCED KEYLESS SYSTEM] ) Related wiring harnesses
LGNDBody groundUnder any condition1.0 or lessRelated wiring harnesses
