Basic System (HVAC): Removal & Installation Mazda CX-9 I

Automatic HVAC System 2 illustrations ~338 words

A/C Compressor Installation Note

CAUTIONDue to the high moisture-absorption characteristics of the compressor oil, it may absorb moisture if left over a long period of time thereby negatively affecting A/C operation. Drain the compressor oil and refill within 10 min. of each other.

Scheme 137

Scheme 137
Scheme 137
  1. Rotate new A/C compressor shaft six to eight revolutions while collecting refrigerant oil in a clean measuring device. Use this refrigerant oil to refill new compressor. Do not allow refrigerant oil to become contaminated.
  2. Rotate old A/C compressor shaft six to eight revolutions while collecting refrigerant oil in a separate, clean measuring device.
  3. Compare those oil amounts. The amount of the oil drained from the new A/C compressor should be greater than the old one.
  4. Pour the same amount oil of drained from the old A/C compressor back into the new A/C compressor. A/C compressor oil type DENSO OIL8 A/C compressor oil sealed volume (approx. quantity) 160 ml {160 cc, 5.41 fl oz.}

Scheme 138

Scheme 138: CONDENSER REMOVAL/INSTALLATION
Scheme 138: CONDENSER REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Discharge the refrigerant. See «REFRIGERANT CHARGING»(ref-345382-S20015181932009102000000) .
  3. Drain the engine coolant. See «ENGINE COOLANT REPLACEMENT [MZI-3.7]»(ref-345349-S00631216152009102000000) .
  4. Remove the air cleaner and fresh air duct component. See «INTAKE-AIR SYSTEM REMOVAL/INSTALLATION [MZI-3.7]»(ref-345348-S33859003282009102000000) .
  5. Remove the cooling fan component. See «FAN MOTOR INSPECTION [MZI-3.7]»(ref-345349-S13027118752009102000000) .
  6. Disconnect the ATF oil cooler hose from the radiator.
  7. Remove the radiator. See «RADIATOR REMOVAL/INSTALLATION [MZI-3.7]»(ref-345349-S14550150072009102000000) .
  8. Remove the nut and disconnect front cooler pipes No. 3 and No. 4. See «REFRIGERANT LINE REMOVAL/INSTALLATION»(ref-345376-S13106311512009102000000) .
  9. Remove the front cooler pipe No. 3 bracket. See «REFRIGERANT LINE REMOVAL/INSTALLATION»(ref-345376-S13106311512009102000000) .
  10. Remove the bolts and two condenser brackets.
  11. Remove in the order indicated in the table. Do not allow remaining compressor oil in the refrigerant line to spill. CAUTION: If moisture or foreign material enters the refrigeration cycle, cooling ability will be lowered and abnormal noise or other malfunction could occur. Always plug open fittings immediately after removing any refrigeration cycle parts.
  12. Install in the reverse order of removal.
  13. Refill the engine coolant. See «ENGINE COOLANT REPLACEMENT [MZI-3.7]»(ref-345349-S00631216152009102000000) .
  14. Inspect for engine coolant leakage. See «ENGINE COOLANT LEAKAGE INSPECTION [MZI-3.7]»(ref-345349-S10451290312009102000000) .
  15. Inspect the ATF level. See «AUTOMATIC TRANSAXLE FLUID (ATF) INSPECTION [AW6A-EL, AW6AX-EL]»(ref-345375-S33035555352009102000000) .
  16. Perform the refrigerant system performance test. See «REFRIGERANT SYSTEM PERFORMANCE TEST»(ref-345382-S20017527322009102000000) .
