Basic System (HVAC): Overview Mazda CX-9 I

Automatic HVAC System 12 illustrations ~650 words

Scheme 104

Scheme 104: HVAC BASIC SYSTEM LOCATION INDEX
Scheme 104: HVAC BASIC SYSTEM LOCATION INDEX

Scheme 105

Scheme 105: FRONT A/C UNIT REMOVAL/INSTALLATION
Scheme 105: FRONT A/C UNIT REMOVAL/INSTALLATION

Scheme 106

Scheme 106
Scheme 106

Scheme 107

Scheme 107
Scheme 107

Scheme 108

Scheme 108
Scheme 108

Scheme 109

Scheme 109
Scheme 109
  1. Disconnect the negative battery cable.
  2. Discharge the refrigerant. See «REFRIGERANT CHARGING»(/mazda/cx-9/i-2006-2012/remont/automatic-hvac-system/#refrigerant-system-hvac__refrigerant-charging) .
  3. Drain the engine coolant. See «ENGINE COOLANT REPLACEMENT [MZI-3.7]».
  4. Remove the following parts: Decoration panel. See «DECORATION PANEL REMOVAL/INSTALLATION». Front console box mat. See «FRONT CONSOLE BOX MAT REMOVAL/INSTALLATION». Indicator panel. See «INDICATOR PANEL REMOVAL/INSTALLATION». Front console box. See «FRONT CONSOLE BOX REMOVAL/INSTALLATION». Dashboard undercover. See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION». Side wall. See «SIDE WALL REMOVAL/INSTALLATION». Console panel. See «CONSOLE PANEL REMOVAL/INSTALLATION». Console cover. See «CONSOLE COVER REMOVAL/INSTALLATION». Console. See «CONSOLE REMOVAL/INSTALLATION». Front scuff plate inner. See «FRONT SCUFF PLATE REMOVAL/INSTALLATION». Front side trim. See «FRONT SIDE TRIM REMOVAL/INSTALLATION». Glove compartment. See «GLOVE COMPARTMENT REMOVAL/INSTALLATION». Hood release lever. See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION». Lower panel. See «LOWER PANEL REMOVAL/INSTALLATION». Lower column cover. See «COLUMN COVER REMOVAL/INSTALLATION». Driver-side air bag module. See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION». Steering wheel. See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION». Combination switch. See «COMBINATION SWITCH REMOVAL/INSTALLATION». Center panel. See «CENTER PANEL REMOVAL/INSTALLATION». Meter hood. See «METER HOOD REMOVAL/INSTALLATION». Instrument cluster. See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION». Audio unit. See «AUDIO UNIT REMOVAL/INSTALLATION». Steering shaft. See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION». A-pillar trim. See «A-PILLAR TRIM REMOVAL/INSTALLATION». Side panel. See «SIDE PANEL REMOVAL/INSTALLATION».
  5. Disconnect the front door wiring harness connector (Driver side). See «FRONT DOOR MODULE REMOVAL/INSTALLATION».
  6. Remove the brake switch from the brake pedal with the brake switch connector connected. See «BRAKE PEDAL REMOVAL/INSTALLATION».
  7. Remove the selector lever component. See «SELECTOR LEVER COMPONENT REMOVAL/INSTALLATION».
  8. Remove the windshield wiper arm. See «WINDSHIELD WIPER ARM AND BLADE REMOVAL/INSTALLATION».
  9. Remove the cowl grille. See «COWL GRILLE REMOVAL/INSTALLATION».
  10. Remove the windshield wiper motor. See «WINDSHIELD WIPER MOTOR REMOVAL/INSTALLATION».
  11. Remove the dashboard. See «DASHBOARD REMOVAL/INSTALLATION».
  12. Remove the rear heat duct fasteners and slide the rear heat duct rearward. See «REAR HEAT DUCT COMPONENT REMOVAL/INSTALLATION».
  13. Disconnect the drain hose.
  14. Remove the nuts.
  15. Remove the bracket.
  16. Remove the bolts.
  17. Remove the dashboard bracket.
  18. Remove the hose clips.
  19. Remove the front heater hose No. 3 and front heater hose No. 4. See «HEATER PIPE AND HOSE COMPONENT REMOVAL/INSTALLATION».
  20. Remove the front cooler pipe No. 1 bracket installation nut.
  21. Remove the nut.
  22. Remove the front cooler pipe No. 1 and front cooler pipe No. 4. See «REFRIGERANT LINE REMOVAL/INSTALLATION». CAUTION: If moisture or foreign material enters the refrigeration cycle, cooling ability will be lowered and abnormal noise or other malfunction could occur. Always plug open fittings immediately after removing any refrigeration cycle parts.
  23. Remove the nuts.
  24. Remove the front A/C unit. Do not allow compressor oil to spill.

Scheme 110

Scheme 110: FRONT A/C UNIT DISASSEMBLY/ASSEMBLY
Scheme 110: FRONT A/C UNIT DISASSEMBLY/ASSEMBLY
  1. Disassemble in the order indicated in the table.
  2. Assemble in the reverse order of disassembly.

Scheme 111

Scheme 111: FRONT EXPANSION VALVE REMOVAL/INSTALLATION
Scheme 111: FRONT EXPANSION VALVE REMOVAL/INSTALLATION

Scheme 112

Scheme 112
Scheme 112

Scheme 113

Scheme 113
Scheme 113
  1. Disconnect the negative battery cable.
  2. Discharge the refrigerant from the system. See «REFRIGERANT RECOVERY»(/mazda/cx-9/i-2006-2012/remont/automatic-hvac-system/#refrigerant-system-hvac__refrigerant-recovery) . See «REFRIGERANT CHARGING»(/mazda/cx-9/i-2006-2012/remont/automatic-hvac-system/#refrigerant-system-hvac__refrigerant-charging) .
  3. Remove the following parts: Windshield wiper blade. See «WINDSHIELD WIPER ARM AND BLADE REMOVAL/INSTALLATION» ) Cowl grille. See «COWL GRILLE REMOVAL/INSTALLATION». Windshield wiper motor. See «WINDSHIELD WIPER MOTOR REMOVAL/INSTALLATION». Cowl panel. See «COWL PANEL REMOVAL/INSTALLATION». Front cooler pipe No. 1 bracket installation nut Nut Front cooler pipe No. 1 and front cooler pipe No. 4. See «REFRIGERANT LINE REMOVAL/INSTALLATION». CAUTION: If moisture or foreign material enters the refrigeration cycle, cooling ability will be lowered and abnormal noise or other malfunction could occur. Always plug open fittings immediately after removing any refrigeration cycle parts.
  4. Remove the bolts.
  5. Remove the front expansion valve. Do not allow compressor oil to spill.
  6. Install in the reverse order of removal.
  7. Perform the refrigerant system performance test. (See «REFRIGERANT SYSTEM PERFORMANCE TEST»(/mazda/cx-9/i-2006-2012/remont/automatic-hvac-system/#refrigerant-system-hvac) .

Scheme 114

Scheme 114: AIR FILTER REMOVAL/INSTALLATION
Scheme 114: AIR FILTER REMOVAL/INSTALLATION

Scheme 115

Scheme 115
Scheme 115
  1. Remove the glove compartment service hole cover.
  2. Remove the cover in the direction of the arrow.
  3. Remove the air filter in the direction of the arrow.
  4. Install in the reverse order of removal.
