Lighting Systems: Removal & Installation Mazda CX-7 I рестайлинг

DISCHARGE HEADLIGHT CONTROL MODULE REMOVAL/INSTALLATION

Scheme 11

1. Disconnect the negative battery cable.
2. Remove the front bumper. (See «FRONT BUMPER REMOVAL/INSTALLATION»(ref-375392-S25264795932010102800000) .)
3. Remove the front combination light. (See «FRONT COMBINATION LIGHT REMOVAL/INSTALLATION»(ref-375320-S35175580102010102800000) .)
4. Remove in the order indicated in the table.
5. Install in the reverse order of removal.

SIDE TURN LIGHT REMOVAL/INSTALLATION

Note. Side turn lights are integrated with the power outer mirror.

1. Disconnect the negative battery cable.
2. Remove the power outer mirror. (See «OUTER MIRROR GLASS REMOVAL»(ref-375321-S19852846142010102800000) .) (See «POWER OUTER MIRROR REMOVAL/INSTALLATION»(ref-375321-S36265626782010102800000) .)
3. Install in the reverse order of removal.

Scheme 12

Scheme 13

1. Disconnect the negative battery cable.
2. Remove the service hole cover.
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Scheme 14

Scheme 15

1. Disconnect the negative battery cable.
2. Remove the service hole cover.
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Scheme 16

1. Disconnect the negative battery cable.
2. Remove the cover in the interior of the liftgate.
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Scheme 17

1. Disconnect the negative battery cable.
2. Remove the rear finisher. (See «REAR FINISHER REMOVAL/INSTALLATION»(ref-375375-S14706990682010102800000) .)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

COMBINATION SWITCH REMOVAL/INSTALLATION

Scheme 18

1. Disconnect the negative battery cable.
2. Remove the following parts: Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-375340-S17292282012010102800000) .) Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-375364-S15088001982010102800000) .) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-375422-S22241475042010102800000) .)
3. Disconnect the connector.
4. Remove the screws.
5. Remove the combination switch.
6. Install in the reverse order of removal.
7. Perform the steering angle sensor reference point setting. (See «STEERING ANGLE SENSOR INITIALIZATION PROCEDURE»(ref-375320-S27923995692010102800000) .)

HAZARD WARNING SWITCH REMOVAL/INSTALLATION

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

1. Disconnect the negative battery cable.
2. Remove the following parts: Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-375422-S00635045162010102800000) .) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-375422-S25498401972010102800000) .) Audio unit (See «AUDIO UNIT REMOVAL/INSTALLATION»(ref-375342-S35395625342010102800000) .)
3. Remove the screws.
4. Disconnect the connector.
5. Turn the hazard warning switch off. NOTE: Turning off the hazard warning switch provides better visibility of the connection area between the hazard warning switch and the hazard warning switch panel.
6. Insert a tape-wrapped flathead screwdriver in the position shown in the illustration, lift it up in the direction of the arrow and shift the tab.
7. Pull out the hazard warning switch in the direction of the arrow shown in the illustration. CAUTION: If the hazard warning switch is forcefully removed, the hazard warning switch panel will interfere with the audio panel and cause scratching or other damage. When removing the hazard warning switch, pull it out while pressing the hazard warning switch panel.
8. Remove the hazard warning switch panel in the direction of the arrow shown in the illustration.
9. Remove the screw.
10. Remove the short-code from the hook.

Scheme 24

1. Install in the order shown in the illustration.
2. Install the following parts: Audio unit (See «AUDIO UNIT REMOVAL/INSTALLATION»(ref-375342-S35395625342010102800000) .) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-375422-S25498401972010102800000) .) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-375422-S00635045162010102800000) .)
3. Connect the negative battery cable.

Scheme 25

Scheme 26

1. Verify that the continuity between the hazard warning switch terminals is as indicated in the table. If not as indicated in the table, replace the hazard warning switch.

Scheme 27

Scheme 28

1. Verify that the continuity is as indicated in the table. If not as indicated in the table, replace the short-code.

Scheme 29

Scheme 30

1. Verify that continuity between the headlight leveling switch terminals is as indicated in the table. If not as indicated in the table, replace the headlight leveling switch.

Scheme 31

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the table.
3. Install in the reverse order of removal.

Switch Bezel Component Removal Note

1. Access the switch bezel component from behind of the dashboard, and squeeze the tabs of the switch bezel component.
2. Remove the switch bezel component from the dashboard.

AUTO LIGHT/WIPER CONTROL MODULE REMOVAL/INSTALLATION

Scheme 32

1. Disconnect the negative battery cable.
2. Remove the meter hood. (See «METER HOOD REMOVAL/INSTALLATION»(ref-375422-S12837313052010102800000) .)
3. Remove the instrument cluster. (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-375337-S06830601912010102800000) .)
4. Remove in the order indicated in the table.
5. Install in the reverse order of removal.
6. Perform the auto light/wiper control module configuration. (See «AUTO LIGHT/WIPER CONTROL MODULE CONFIGURATION»(ref-375320-S07788748992010102800000) .)
