Using M-MDS
Note. PIDs for the following parts are not available on this model. Go to the appropriate part inspection page. CMP sensor Main relay
Scheme 126
- Connect the M-MDS to the DLC-2.
- Turn the ignition switch to the ON position.
- Measure the PID value. If PID value is not within the specification, follow the instructions in Action column. NOTE: The PID/DATA MONITOR function monitors the calculated value of the input/output signals in the PCM. Therefore, an output device malfunction is not directly indicated as a malfunction of the monitored value for the output device. If a monitored value of an output device is out of specification, inspect the monitored value of the input device related to the output control. For input/output signals except those of the monitoring items, use a voltmeter to measure the PCM terminal voltage. The simulation items that are used in the ENGINE CONTROL SYSTEM OPERATION INSPECTION are as follows. ACCS, ALTF, ARPMDES, EVAPCP, EVAPCV, FAN_DUTY, FP, IMRC, IMTV, INJ_1~4, SEGRP, TEST, VT Duty1 wt
PID/DATA monitor table (reference)
| Monitor item (Definition) | Unit/Condition | Condition/Specification (Reference) | Inspection item | PCM terminal | |
|---|---|---|---|---|---|
| AAT (Ambient air temperature) | °C | °F | Indicates the ambient air temperature | IAT sensor | 1AC |
| AC_REQ (A/C request signal) | OFF/ON | A/C switch OFF: OFF A/C switch ON: ON | Perform applicable DTC troubleshooting | ||
| ACCS (A/C relay) | OFF/ON | A/C relay OFF: OFF A/C relay ON: ON | A/C relay Inspect following PIDs: RPM, TP REL, ECT. | 1I | |
| AFR (Target air fuel ratio) | Target air fuel ratio is displayed | A/F sensor | 2Z 2AC 2AD | ||
| AFR_ACT (Actual air fuel ratio) | Actual air fuel ratio is displayed | A/F sensor | 2Z 2AC 2AD | ||
| ALTF (Generator field coil control duty value) | % | Just after A/C switch ON and fan switch ON at idle: Duty value rises | Generator Inspect following PIDs: IAT, ECT, RPM, VPWR, ALTT V. | 2AA | |
| ALTT V (Generator output voltage) | V | Turn the ignition switch to the ON position: 0 V Idle: approx. 14 V (1) (E/L not operating) | Generator | 2AF | |
| APP (APP sensor) | % | Accelerator pedal released: approx. 0 % Accelerator pedal depressed: approx. 100% | APP sensor | 1AO 1AP | |
| APP1 (APP sensor No. 1) | % | Accelerator pedal released: approx. 15 % Accelerator pedal depressed: approx. 80 % | APP sensor No. 1 | 1AP | |
| V | Accelerator pedal released: 1.56-1.65V Accelerator pedal depressed: 3.65-3.93 V | ||||
| APP 2 (APP sensor No. 2) | % | Accelerator pedal released: approx. 7.5 % Accelerator pedal depressed: approx. 42 % | APP sensor No. 2 | 1AO | |
| V | Accelerator pedal released: approx. 0.4 V Accelerator pedal depressed: approx. 2.0 V | ||||
| ARPMDES (Target engine speed) | RPM | Indicate the target engine speed | Inspect following PIDs: IAT, RPM, MAP, ECT, MAF, TP REL, INGEAR, ALTT V. | ||
| BARO (Barometric pressure) | KPa, psi, Bar | Indicate the BARO | BARO sensor | ||
| V | Turn the ignition switch to the ON position (at sea level): approx. 4.1 V | ||||
| BOO (Brake switch) | OFF/ON | Brake pedal depressed: ON Brake pedal released: OFF | Brake switch No. 1 | 1AB | |
| BPA (2) (Brake pressure applied switch) | OFF/ON | Brake pedal depressed: ON Brake pedal released: OFF | Brake switch No. 2 | 1AF | |
| CATT11_DSD (Desired catalyst temperature bank one, sensor one) | °C | °F | Indicate the estimated catalytic converter temperature | Perform applicable DTC troubleshooting. | |
| CHRGLP (Generator warning light) | OFF/ON | Turn the ignition switch to the ON position: ON Idle: OFF | Perform applicable DTC troubleshooting. | ||
| COLP (Refrigerant pressure sensor) | OFF/ON | Refrigerant pressure is above 1.96 Mpa {20.0 kgf/cm 2 , 284 psi}: ON | Refrigerant pressure sensor | ||
| ECT (Engine coolant temperature) | °C | °F | Indicate the ECT | ECT sensor | 2AH |
| V | ECT 20°C {68°F}: 3.04-3.14 V ECT 80°C {176°F}: 0.76-0.83 V | ||||
| EQ_RAT11 (Equivalence ratio (lambda)) | Idling after warm-up: approx. 1 | Perform applicable DTC troubleshooting. | 2Z 2AC 2AD | ||
| EQ_RAT11_DSD (Desired equivalence ratio (lambda)) | Idling after warm-up: approx. 1 | Perform applicable DTC troubleshooting. | |||
| ETC_ACT (Electronic throttle control actual) | ° | Indicate the desired TP by angle | Perform applicable DTC troubleshooting. | 2BE, 2BF | |
| ETC_DSD (Electronic throttle control desired) | % | Indicate the desired TP by percent | TP sensor Inspect following PIDs: APP1, APP2, ETC_ACT. | ||
| ° | Indicate the desired TP by angle | ||||
| EVAPCP (Purge solenoid valve duty value) | % | Turn the ignition switch to the ON position: 0% Idle: 0% | Purge solenoid valve Inspect following PIDs: IAT, RPM, ECT, MAF, O2S11, INGEAR, VPWR. | 1BA | |
| EVAPCV (Evaporative emission canister vent valve) | OFF/ON | Simulation item (EVAPCV) is ON: ON | CV solenoid valve | 1M | |
| FAN_DUTY (Fan control module) | % | When all of following condition are met: 50% Test mode ON WOT | Fan control module | 1R | |
| FCL (Fuel cap warning light) | OFF/ON | Fuel cap warning light not illuminated: OFF Fuel cap warning light illuminated: ON | Perform applicable DTC troubleshooting. | ||
| FLI (Fuel level) | % | Fuel gauge level F: approx. 100% Fuel gauge level E: approx. 0% | Perform applicable DTC troubleshooting. | ||
| FP (Fuel pump relay) | OFF/ON | Turn the ignition switch to the ON position: OFF Idle: ON Cranking: ON | Fuel pump relay Inspect following PIDs: RPM. | 1BG | |
| FTP (Fuel tank pressure sensor) | KPa, psi, Bar | Indicate the fuel tank pressure | Fuel tank pressure sensor | 1AH | |
| V | Fuel tank pressure is equal to barometric pressure: approx. 2.6 V | ||||
| FUELPW (Fuel injector duration) | Sec | Idle (after warm up): approx. 2.2 ms | Fuel injector Inspect following PIDs: IAT, MAF, TP REL, MAP, ECT, RPM, O2S11, O2S12, INGEAR, VPWR, ALTT V. | 2AZ 2BB 2BC 2BD | |
| FUELSYS (Fuel system status) | OL/CL/CL-Fault/OL-Fault/OL-Drive | Idle (after warm up): CL | Fuel injector Inspect following PIDs: IAT, MAF, TP REL, MAP, ECT, RPM, O2S11, O2S12, INGEAR, VPWR, ALTT V. | ||
| HTR11 (A/F sensor heater) | OFF/ON | Idle (after warm up): ON<=>OFF | A/F sensor Inspect following PIDs: IAT, MAF, TP REL, ECT, RPM. | 2A | |
| HTR12 (HO2S heater) | OFF/ON | Idle (after warm up): ON<=>OFF | HO2S heater Inspect following PIDs: IAT, MAF, ECT, RPM. | 2B | |
| IAT (Intake air temperature) | °C | °F | Indicate the IAT | IAT sensor | 1AC |
| V | IAT 20°C {68°F}: approx. 2.38 V IAT 60°C {140°F}: approx. 0.89 V | ||||
| IMRC (Variable tumble solenoid valve) | OFF/ON | ECT below 60°C {140°F} and engine speed below 3,750 RPM : On ECT above 60°C {140°F} while idling.: Off | Variable tumble solenoid valve Inspect following PIDs: TP REL, ECT, RPM. | 21 | |
| IMRC_POS (Variable tumble shutter valve switch) | V | ECT below 60°C {140°F} and engine speed below 3,750 RPM : 3.408-4.432 V ECT above 60°C {140°F} while idling.: 0.808-1.832 V | Variable tumble shutter valve switch | 2R | |
| IMTV (Variable Intake air control solenoid valve) | OFF/ON | Engine speed is below approx. 4,400 RPM: On Others: Off | Variable intake air control solenoid valve Inspect following PIDs: RPM. | 2J | |
| INGEAR (Load/no load condition) | OFF/ON | Driving range: On Except above: Off | TR switch | ||
| IVS (CTP condition) | Idle/Off_Idle | CTP: Idle Others: Off Idle | Perform applicable DTC troubleshooting. | ||
| KNOCKR (Knocking retard) | ° | Turn the ignition switch to the ON position: 0° Idle: 0° | KS | 2U 2V | |
| LOAD (Engine load) | % | Turn the ignition switch to the ON position: 0% Idle (after warm up): approx.15% | Inspect following PIDs: MAP, IAT, MAF, RPM. | ||
| LONGFT1 (long term fuel trim) | % | Idle (after warm up): -15-20% | Perform applicable DTC troubleshooting. | ||
| MAF (Mass airflow) | G/sec | Indicate the MAF | MAF sensor | 1AK | |
| V | Turn the ignition switch to the ON position: approx. 0.7 V Idle (after warm up): approx. 1.2 V | ||||
| MAP (Manifold absolute pressure) | KPa, psi, Bar | Indicate the MAP | MAP sensor | 2AG | |
| V | Turn the ignition switch to the ON position (at sea level): approx. 4.1 V Idle: approx. 1.2 V | ||||
| MIL (Malfunction indicator lamp) | OFF/ON | DTC stored: On DTC not stored: Off | Perform applicable DTC troubleshooting. | ||
| MIL_DIS (Travelled distance since the MIL illuminated) | Km | Miles | Indicate the travelled distance since the MIL illuminated | ||
| O2S11 (A/F sensor) | A | Idle (After warm up): approx. 0 mA | A/F sensor | 2Z 2AC 2AD | |
| O2S12 (HO2S) | V | Idle (After warm up): 0-1.0 V | HO2S | 2Q | |
| RO2FT1 (HO2S fuel trim) | % | Idle (after warm up): approx. -0.03-0.03 | Perform applicable DTC troubleshooting. | ||
| RPM (Engine speed) | RPM | Indicate the engine speed | CKP sensor | 2W | |
| SC_CANCEL (2) (CANCEL switch) | Inactive/Active | CANCEL switch pressed in: Active Except above: Inactive | Cruise control switch | 1AQ | |
| SC_OFF (2) (ON/OFF switch) | Inactive/Active | ON/OFF switch pressed in (OFF): Active Except above: Inactive | Cruise control switch | 1AQ | |
| SC ON (2) (ON/OFF switch) | Inactive/Active | ON/OFF switch pressed in (ON): Active Except above: Inactive | Cruise control switch | 1AQ | |
| SC_RES (2) (RESUME switch) | Inactive/Active | RESUME switch pressed in: Active Except above: Inactive | Cruise control switch | 1AQ | |
| SC_SET (2) (SET(-) switch) | Inactive/Active | SET(-) switch pressed in: Active Except above: Inactive | Cruise control switch | 1AQ | |
| SC_SET (2) (SET(+) switch) | Inactive/Active | SET(+) switch pressed in: Active Except above: Inactive | Cruise control switch | 1AQ | |
| SCCS (2) (Cruise control switch) | V | OFF switch pressed in: approx. 0.05 V CANCEL switch pressed in: approx. 0.98 V SET(-) switch pressed in: approx. 1.88 V SET(+) switch pressed in: approx. 2.73 V RESUME switch pressed in: approx. 3.45 V ON switch pressed in (ON): approx. 4.05 V | Cruise control switch | 1AQ | |
| SEGRP (EGR valve (stepping motor) position) | Turn the ignition switch to the ON position: 0 Idle: 0 step Cranking: 0-52 | EGR valve Inspect following PIDs: MAF, TP REL, ECT, RPM, VSS. | 2AT, 2AW, 2AX, 2BA | ||
| SEGRP DSD (Desired EGR valve position) | % | Indicate the desired EGR valve position | Inspect following PIDs: MAF, TP REL, ECT, RPM, VSS. | ||
| SHRTFT1 (Short term fuel trim) | % | Idle (after warm up): approx.-25- 25% | Perform applicable DTC troubleshooting. | ||
| SPARKADV (Ignition timing) | ° | Indicate the ignition timing | Ignition coil Inspect following PIDs: MAF, TP REL, ECT, RPM, INGEAR, VPWR. | 2G, 2H, 2K, 2L | |
| TEST (Test mode) | OFF/ON | Test mode ON: On Test mode OFF: Off | |||
| TH_M (Thermostat monitor) | Indicates heat radiation ratio (heat radiation when thermostat is malfunctioning/heat radiation when thermostat is normal) when thermostat monitoring is finished | Thermostat | |||
| °C | °F | Indicates engine coolant temperature when thermostat monitoring is finished | |||
| TH_M_MAX (Thermostat monitor max) | Indicates upper limit of heat radiation ratio (heat radiation when thermostat is malfunctioning/heat radiation when thermostat is normal) for thermostat monitoring execution | Thermostat | |||
| °c | °F | Indicates upper limit of engine coolant temperature for thermostat monitoring execution | |||
| TH_M_MIN (Thermostat monitor min) | Indicates lower limit of heat radiation ratio (heat radiation when thermostat is malfunctioning/heat radiation when thermostat is normal) for thermostat monitoring execution | Thermostat | |||
| °c | °F | Indicates lower limit of engine coolant temperature for thermostat monitoring execution | |||
| TP REL (Relative throttle position) | % | Accelerator pedal released: approx. 3% Accelerator pedal depressed: approx. 75% | TP sensor | 2AK 2AL | |
| TP1 (TP sensor No. 1) | % | Accelerator pedal released: approx. 12% Accelerator pedal depressed: approx. 84% | TP sensor No. 1 | 2AK | |
| V | Accelerator pedal released: approx. 0.6 V Accelerator pedal depressed: approx. 4.2 V | ||||
| TP2 (TP sensor No. 2) | % | Accelerator pedal released: approx. 12% Accelerator pedal depressed: approx. 84% | TP sensor No. 2 | 2AL | |
| V | Accelerator pedal released: approx. 4.4 V Accelerator pedal depressed: approx. 0.8 V | ||||
| TPCT (TP sensor voltage at CTP) | V | Turn the ignition switch to the ON position: approx. 0.5 V | TP sensor | 2AK 2AL | |
| VPWR (Battery positive voltage) | V | Turn the ignition switch to the ON position: B+ | Battery | 1C | |
| VSS (Vehicle speed) | KPH | Indicate the vehicle speed | Perform applicable DTC troubleshooting. | ||
| VT ACT1 (Actual valve timing) | ° | Idle: approx. 0° Racing after warm up: 0-25° | CMP sensor | 2S | |
| VT DIFF1 (Difference between target and actual valve timing) | ° | Idle: approx. 0° | CMP sensor OCV Inspect following PIDs: TP REL, ECT, RPM. | 2E 2S | |
| VT DUTY1 (Oil control valve duty value) | % | Idle: approx. 11.5% | OCV Inspect following PIDs: TP REL, ECT, RPM. | 2E | |
| (1) Calculated value; differs from terminal voltage (2) With cruise control system | |||||
| (1) | Calculated value; differs from terminal voltage |
| (2) | With cruise control system |
PID/DATA MONITOR CHART
- Following PIDs are for the ATX models. If inspects for following PIDs, (See «ON-BOARD DIAGNOSTIC SYSTEM PID/DATA MONITOR INSPECTION [FS5A-EL]»(ref-375402-S21806660812010102800000) .)
Without Using the M-MDS
| CAUTION | The PCM terminal voltages vary with change in measuring conditions and vehicle conditions. Always carry out a total inspection of the input systems, output systems, and PCM to determine the cause of trouble. Otherwise, a wrong diagnosis will be made. |
PCM CONFIGURATION [L5]
Note. Use the IDS (laptop PC) because the PDS (Pocket PC) does not support the PCM CONFIGURATION.
- Connect the M-MDS to the DLC-2.
- After the vehicle is identified, select the following items from the initial screen of the M-MDS. When using the IDS (laptop PC) Select the "Module Programming".
- Then, select items from the screen menu in the following order. Select "Programmable Module Installation". Select "PCM".
- Perform the configuration according to the directions on the screen.
- Retrieve DTCs by the M-MDS, then verify that there is no DTC present. If a DTC(s) is detected, perform the applicable DTC inspection. (See «DTC TABLE [L5]»(ref-375346-S28771957642010102800000) .)
