On-Board Diagnostic [Multi Information Display]: Overview Mazda CX-7 I рестайлинг

Scheme 99

Scheme 100

1. Connect the M-MDS to the DLC-2.
2. After the vehicle is identified, select the following items from the initialization screen of the M-MDS. When using the IDS (laptop PC) Select "Self Test". Select "Modules". Select "MID". When using the PDS (Pocket PC) Select "Module Tests". Select "MID". Select "Self Test".
3. Verify the DTC according to the directions on the screen. If any DTCs are displayed, perform troubleshooting according to the corresponding DTC inspection.
4. After completion of repairs, clear all DTCs stored in the multi information display. (See «CLEARING DTC [MULTI INFORMATION DISPLAY]».)

Scheme 101

1. Connect the M-MDS to the DLC-2.
2. After the vehicle is identified, select the following items from the initialization screen of the M-MDS. When using the IDS (laptop PC) Select "Self Test". Select "Modules". Select "MID". When using the PDS (Pocket PC) Select "Module Tests". Select "MID". Select "Self Test".
3. Verify the DTC according to the directions on the screen.
4. Press the clear button on the DTC screen to clear the DTC.
5. Turn the ignition switch to the LOCK position.
6. Turn the ignition switch to the ON position and wait for 5 s or more.
7. Perform the DTC inspection. (See «DTC INSPECTION [MULTI INFORMATION DISPLAY]».)
8. Verify that no DTCs are displayed.
