Control System (Body Control Module): Removal & Installation Mazda CX-7 I рестайлинг

BODY CONTROL MODULE (BCM) REMOVAL/INSTALLATION

Note. Perform the theft-deterrent system initialization when the BCM is replaced with a new one.

Scheme 91

Scheme 92

Scheme 93

Scheme 94

Scheme 95

1. Disconnect the negative battery cable.
2. Remove the following parts: Front scuff plate (LH) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-375422-S33927733892010102800000) .) Front side trim (LH) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-375422-S05380344012010102800000) .) Console panel (See «CONSOLE PANEL REMOVAL/INSTALLATION»(ref-375422-S16179305552010102800000) .) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-375422-S05218780952010102800000) .)
3. Set the hood release lever out of the way. (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-375401-S08980162612010102800000) .)
4. Remove the lower panel. (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-375422-S28238229142010102800000) .)
5. Remove the dashboard wiring harness connector clip from the BCM.
6. Disconnect the connectors shown in the figure.
7. Remove the bolts shown in the figure.
8. Raise the BCM in the direction of the arrow (1) shown in the figure, pull it in the direction of the arrow (2), and remove the tab from the body.
9. Pull the BCM outward and remove the pin from the body.
10. Remove the BCM.
11. Install in the reverse order of removal.
