Pattern 4
Note. A dotted line wave pattern is output for BCM terminal 5AB, however, it appears as a solid line in the oscilloscope where it overlaps the voltage output for terminal 1F from the seat position memory control module.
Scheme 96
- Terminal: 5AB (+) <==> body ground (-)
- Oscilloscope setting: 2 V/DIV (Y), 1 ms/DIV (X), DC range
Using M-MDS
Note. Use the IDS (laptop PC) because the PDS (Pocket PC) does not support the PERSONALIZATION FEATURES SETTING PROCEDURE.
Scheme 97
- Connect the M-MDS to DLC-2.
- After the vehicle is identified, select the following items from the initial screen of the M-MDS. When using the IDS (laptop PC) Select the "Module Programming".
- Then, select items from the screen menu in the following order. Select "Programmable Parameters". Select "Personality", "Interior lighting", "Washer/Wiper", "Security" or "Power Door Locks".
- Select an item name, and then select option.
Items of "Personality"
| M-MDS display | Function | Initial setting | Setting content | Control unit |
|---|---|---|---|---|
| Smart turn | The "turn light system" function can be set. | Disabled | Disabled/Enabled | BCM |
| Auto relock timer (without SKE) | Auto re-lock operation timing can be changed. | 30sec | 30sec/60sec/90sec/Disabled | BCM |
| 2 stage door unlocking (without SKE) | 2-step unlocking system can be set. | Enabled | Disabled/Enabled | BCM |
| Answer feed back (hazard) | Answer back hazard can be set to inoperable. | Enabled | Enabled/Disabled | BCM |
| Answer feed back (horn) | Answer back horn can be set to inoperable. | Enabled | Enabled/Disabled | BCM |
| Room lamp timer (When Doors closed) | The elapsed time between the doors closing and the interior light turning off can be adjusted. | 15s | 7.5s/15s/30s/60s | BCM |
| Room lamp timer (When Doors unlocked) | The elapsed time between the doors unlocking and the interior light turning off can be adjusted. | 30s | 7.5s/15s/30s/60s | BCM |
| Window opening with Advanced-key/Transmitter | Exterior open function can be set. | Enabled | Disabled/Enabled | BCM |
| Window closing/opening with Request switch | Exterior open/close function can be set. | Enabled | Disabled/Enabled | BCM |
CONTROL UNIT CHART
Items of "Interior lighting"
| M-MDS display | Function | Initial setting | Setting content | Control unit |
|---|---|---|---|---|
| Auto room lamp (when IG-OFF) | The automatic illumination function of the interior light after the ignition is switched off can be canceled. | Enabled | Enabled/Disabled | BCM |
| Room Lamp Battery Saver Timer | The elapsed time for the interior light to automatically turn off when a door is ajar can be adjusted. | 30min | 30min/60min/10min | BCM |
| Room Lamp Battery Saver | The automatic illumination function of the interior light to automatically turn off can be canceled. | Enabled | Enabled/Disabled | BCM |
INTERIOR LIGHTING REFERENCE
Items of "Washer/Wiper"
| M-MDS display | Function | Initial setting | Setting content | Control unit |
|---|---|---|---|---|
| Rear wiper interlocked to window washer switch | The wiper action in conjunction with the rear washer operation can be canceled. | Enabled | Enabled/Disabled | BCM |
WASHER/WIPER REFERENCE
Items of "Security"
| M-MDS display | Function | Initial setting | Setting content | Control unit |
|---|---|---|---|---|
| Burglar alarm start up method | Theft-deterrent system start up; method can be changed. | Transmitter and key | Transmitter and key/Transmitter | BCM |
SECURITY CHART
Items of "Power Door Locks"
Applied VIN (assumed)
- JM3 ER2W3*A# 300001-300162
- JM3 ER2W5*A# 300001-300162
- JM3 ER2WL*A# 300001-300162
- JM3 ER2WM*A# 300001-300162
- JM3 ER4W3*A# 300001-300162
- JM3 ER4WL*A# 300001-300162
| M-MDS display | Function | Initial setting | Setting content | Control unit |
|---|---|---|---|---|
| Auto door lock (When vehicle start) | Auto lock function can be set. | Enabled | Disabled/Enabled | BCM |
| Auto door lock (When changed gear-selector) | Auto lock/unlock function can be changed. | Disabled | Disabled, All doors lock/unlock, All doors lock/Driver-side door unlock, All doors lock | BCM |
| Auto door lock (When IG-Off) | Auto unlock function can be set. | All doors unlock | Disabled/All doors unlock/Driver-side door unlock | BCM |
FUNCTION CHART
Not Using M-MDS
Applied VIN (assumed)
- JM3 ER2W3*A# 300001-300162
- JM3 ER2W5*A# 300001-300162
- JM3 ER2WL*A# 300001-300162
- JM3 ER2WM*A# 300001-300162
- JM3 ER4W3*A# 300001-300162
- JM3 ER4WL*A# 300001-300162
Auto door lock system
| Setting content | Function | Initial setting | Control unit |
|---|---|---|---|
| Disabled | Auto lock/unlock function can be changed. | Auto door lock operation based on vehicle speed. Auto door unlock operation based on ignition switch position. | BCM |
| Auto door lock operation based on vehicle speed. | |||
| Auto door lock operation based on vehicle speed. Auto door unlock operation based on ignition switch position. | |||
| Auto door lock operation based on shift position. | |||
| Auto door lock operation based on shift position. Auto door unlock operation based on shift position. |
AUTO DOOR LOCK SYSTEM REFERENCE
Setting procedure
