Wiper System/washer System: Adjustments Mazda CX-5 I

WINDSHIELD WASHER NOZZLE ADJUSTMENT

Scheme 6

Scheme 7

1. Insert a tape-wrapped precision flathead screwdriver into the adjustment hole of the windshield washer nozzle and adjust it to the area where washer fluid is sprayed as shown in the figure. (Scheme 6): Adjusting Windshield Washer Nozzle Using Flathead Screwdriver (Scheme 7): Identifying Windshield Washer Nozzle Adjustment Dimensions

Scheme 8

Scheme 9

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Set the front over fender aside. (See «FRONT OVER FENDER REMOVAL/INSTALLATION»(ref-615469-S26249008432014051000000) ).
3. Set the mudguard (RH) aside. (See «MUDGUARD REMOVAL/INSTALLATION»(ref-615433-S03927761162014051000000) ).
4. Remove the front bumper. (See «FRONT BUMPER REMOVAL/INSTALLATION»(ref-615469-S29267101842014051000000) ).
5. Inspect for continuity according to washer fluid level between the washer fluid-level sensor terminals. (Scheme 8): Identifying Washer Fluid Level Sensor Terminals Continuity If not as indicated in the table, replace the washer fluid-level sensor. (See «WASHER FLUID-LEVEL SENSOR REMOVAL/INSTALLATION»(ref-615468-S16364360972014051000000) ). (Scheme 9): Identifying Washer Fluid-Level Sensor Connector Terminals Continuity

Scheme 10

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Set the front over fender aside. (See «FRONT OVER FENDER REMOVAL/INSTALLATION»(ref-615469-S26249008432014051000000) ).
3. Set the mudguard (RH) aside. (See «MUDGUARD REMOVAL/INSTALLATION»(ref-615433-S03927761162014051000000) ).
4. Remove the front bumper. (See «FRONT BUMPER REMOVAL/INSTALLATION»(ref-615469-S29267101842014051000000) ).
5. Disconnect the washer fluid-level sensor connector.
6. Remove the washer fluid-level sensor. NOTE: If the washer fluid-level sensor is removed with washer fluid in the washer tank, the washer fluid may leak out. When removing the washer fluid-level sensor from the washer tank, place a container under the washer tank to collect washer fluid, and perform the procedure.
7. Remove the grommet.
8. Install in the reverse order of removal. (Scheme 10): Identifying Washer Tank, Washer Fluid-Level Sensor, Connector And Grommet

Scheme 11

Scheme 12

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Remove the front over fender. (See «FRONT OVER FENDER REMOVAL/INSTALLATION»(ref-615469-S26249008432014051000000) ).
3. Remove the mudguard (RH). (See «MUDGUARD REMOVAL/INSTALLATION»(ref-615433-S03927761162014051000000) ).
4. Remove the windshield wiper arm and blade. (See «WINDSHIELD WIPER ARM AND BLADE REMOVAL/INSTALLATION»(ref-615468-S12815760182014051000000) ).
5. Disconnect the windshield washer hose A from the washer motor.
6. Remove the windshield washer hose A from the washer tank hook.
7. Remove the windshield washer hose A from clips A.
8. Disconnect the windshield washer hose A from the joint pipe A and remove it. (Scheme 11): Disconnecting Windshield Washer Hose A From Washer Motor
9. Remove the cowl grille. (See «COWL GRILLE REMOVAL/INSTALLATION»(ref-615433-S35529177272014051000000) ).
10. Disconnect the windshield washer hose B from the joint pipe A.
11. Disconnect the windshield washer hose B from the joint pipe B and remove it.
12. Disconnect the windshield washer hose C from the windshield washer nozzle A.
13. Disconnect the windshield washer hose C from the joint pipe B and remove it.
14. Disconnect the windshield washer hose D from the joint pipe B.
15. Disconnect the windshield washer hose D from the joint pipe C and remove it.
16. Disconnect the windshield washer hose E from the windshield washer nozzle B.
17. Disconnect the windshield washer hose E from the joint pipe C and remove it. (Scheme 12): Removing Cowl Grille
18. Install in the reverse order of removal.

Scheme 13

Scheme 14

Scheme 15

1. Pull the cap in the direction of the arrows (1) shown in the figure and remove it in the direction of the arrow (2) with tabs A, B released. (Scheme 13): Removing Rear Wiper Arm Cap
2. Remove the nut with the rear wiper arm and blade pressed. (Scheme 14): Removing Nut With Rear Wiper Arm With Torque Specifications
3. Raise the rear wiper arm and detach it from the serrated connecting part in the direction of the arrow (1) shown in the figure.
4. Install in the reverse order of removal. (See «REAR WIPER ARM INSTALLATION NOTE»(ref-615468-S39766367342014051000000) ).
5. Adjust the rear wiper arm and blade. (See «REAR WIPER ARM AND BLADE ADJUSTMENT»(ref-615468-S09676184462014051000000) ). (Scheme 15): Removing Rear Wiper Arm

Scheme 16

1. Move the rear wiper blade in the direction of the arrow (1) shown in the figure to detach the rear wiper blade from the rear wiper arm.
2. Move the rear wiper blade in the direction of the arrow (2) and remove it from the rear wiper arm in the direction I of the arrow (3). (Scheme 16): Removing Rear Wiper Blade
3. Install in the reverse order of removal.

Scheme 17

1. Clean the serrated connecting part with a wire brush before installing the rear wiper arm. (Scheme 17): Cleaning Serrated Connecting Part Using Wire Brush

Scheme 18

1. Switch the ignition ON (engine off or on).
2. Operate the rear wiper.
3. Verify that the rear wiper is operating and stop the rear wiper.
4. Verify that the rear wiper is stopped at the auto-stop position.
5. Remove the rear wiper arm and blade. (See «REAR WIPER ARM AND BLADE REMOVAL/INSTALLATION»(ref-615468-S07645924262014051000000) ).
6. Install the rear wiper arm to the serrated connecting part, adjust the rear wiper blade end to the area shown in the figure while sliding the rear wiper arm onto the grooves of the serrated connecting part one by one, and temporarily tighten the nut. NOTE: If the rear wiper arm and blade is not installed to the position shown in the figure, repeat the adjustment procedure. (Scheme 18): Identifying Rear Wiper Arm Adjustment Position
7. After adjusting the rear wiper arm and blade, tighten the nut completely. (See «REAR WIPER ARM AND BLADE REMOVAL/INSTALLATION»(ref-615468-S07645924262014051000000) ).

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Remove the following parts: Rear wiper arm and blade (See «REAR WIPER ARM AND BLADE REMOVAL/INSTALLATION»(ref-615468-S07645924262014051000000) ). Liftgate upper trim (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-615455-S41758863582014051000000) ). Liftgate side trim (See «LIFTGATE SIDE TRIM REMOVAL/INSTALLATION»(ref-615455-S24037188362014051000000) ). Liftgate recess (See «LIFTGATE RECESS REMOVAL/INSTALLATION»(ref-615455-S32409649192014051000000) ). Liftgate lower trim (See «LIFTGATE LOWER TRIM REMOVAL/INSTALLATION»(ref-615455-S05003104712014051000000) ).
3. Remove the rear wiper motor connector. (Scheme 19): Removing Rear Wiper Motor Connector
4. Remove bolts shown in the figure. (Scheme 20): Identifying Rear Wiper Motor Mounting Bolts With Torque Specifications
5. Pull out the rear wiper motor from the outer bushing hole and remove it. (Scheme 21): Identifying Rear Wiper Motor And Outer Bushing
6. Press in the outer bushing from the outside of the liftgate in the direction of the arrow (1) shown in the figure. (Scheme 22): Pressing Outer Bushing From Outside Of Liftgate
7. Detach the liftgate and outer bushing while pressing the outer bushing in the direction of the arrows shown in the figure, pull the outer bushing from the inside of the liftgate in the direction of the arrow (2), and remove it.
8. Install in the reverse order of removal. (Scheme 23): Removing Outer Bushing

REAR WASHER NOZZLE ADJUSTMENT

Scheme 24

Scheme 25

1. Insert a needle or similar thin tool into the injection nozzle of the rear washer nozzle and adjust the area where washer fluid injected from the rear washer nozzle is sprayed as shown in the figure. (Scheme 24): Inserting Needle Into Injection Nozzle Of Rear Washer Nozzle (Scheme 25): Identifying Rear Washer Nozzle Adjusting Ceramic End Line

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Remove the front over fender. (See «FRONT OVER FENDER REMOVAL/INSTALLATION»(ref-615469-S26249008432014051000000) ).
3. Remove the mudguard (RH). (See «MUDGUARD REMOVAL/INSTALLATION»(ref-615433-S03927761162014051000000) ).
4. Disconnect the rear washer hose A from the washer motor.
5. Remove the rear washer hose A from the washer tank hook.
6. Remove the rear washer hose A from clips A and B.
7. Disconnect the rear washer hose A from the joint pipe A and remove it.
8. Disconnect the rear washer hose B from the joint pipe A. (Scheme 26): Disconnecting Rear Washer Hose A From Washer Motor
9. Remove the sunroof seaming welt, (with sunroof) (See «SUNROOF UNIT REMOVAL/INSTALLATION»(ref-615484-S04733214242014051000000) ).
10. Remove the A pillar trim. (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-615455-S18284409542014051000000) ).
11. Disconnect the rear washer hose B from the joint pipe B and remove it.
12. Disconnect the rear washer hose C from the joint pipe B.
13. Remove the following parts: Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-615452-S19821275172014051000000) ). Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-615455-S21135452612014051000000) ). Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-615455-S15598834492014051000000) ). Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-615455-S30956965972014051000000) ). B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-615455-S28493908822014051000000) ). Front seat belt adjusting cover (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-615482-S42598094432014051000000) ). (Scheme 27): Removing Rear Washer Hose B From Joint Pipe B Front seat belt upper anchor installation bolt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-615482-S42598094432014051000000) ). B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-615455-S13404345382014051000000) ). Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-615455-S08116469212014051000000) ). Trunk board (See «TRUNK BOARD REMOVAL/INSTALLATION»(ref-615455-S29131302172014051000000) ). Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-615455-S40973116952014051000000) ). Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-615455-S22359050062014051000000) ). D-pillar trim (See «D-PILLAR TRIM REMOVAL/INSTALLATION»(ref-615455-S20578915672014051000000) ). C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-615455-S09907123002014051000000) ). Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-615455-S27262415202014051000000) ).
14. Remove the tape and clips shown in the figure. Without sunroof (Scheme 28): Identifying Tape Applying Area On Headliner (Without Sunroof) With sunroof (Scheme 29): Identifying Tape Applying Area On Headliner (With Sunroof)
15. Disconnect the rear washer hose C from the joint pipe C and remove it.
16. Disconnect the rear washer hose D from the joint pipe C.
17. Remove the liftgate upper trim. (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-615455-S41758863582014051000000) ). (Scheme 30): Removing Rear Washer Hose C From Joint Pipe C
18. Partially peel the liftgate grommet in the direction of arrow (1) shown in the figure, and remove the liftgate grommet from the liftgate grommet inner. (Scheme 31): Removing Liftgate Grommet From Liftgate Grommet Inner
19. Using a tape-wrapped precision flathead screwdriver, press the liftgate grommet inner tabs in the directions of arrows (2) and (3) shown in the figure and remove each liftgate grommet inner from the liftgate and vehicle side in the direction of arrow (4). (Scheme 32): Removing Liftgate Grommet Inner From Liftgate And Vehicle Side
20. Disconnect the rear washer hose D from the rear washer nozzle and remove it.
21. Install in the reverse order of removal. (Scheme 33): Removing Rear Washer Hose D

Scheme 34

Scheme 35

Scheme 36

Scheme 37

1. Switch the ignition ON (engine off or on).
2. Open the driver's door.
3. Switch the ignition OFF.
4. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-615412-S41218039042014051000000) ).
5. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-615455-S35240345352014051000000) ).
6. Rotate the steering wheel in the direction of the arrow shown in the figure to the angle where the service hole is visible. (Scheme 34): Rotating Steering Wheel
7. Insert a tape-wrapped flathead screwdriver into the service hole in the position shown in the figure.
8. While pressing the wiper and washer switch tab in the direction of the arrow (1) shown in the figure using a flathead screwdriver, pull out the wiper and washer switch in the direction of the arrow (2) shown in the figure to detach the wiper and washer switch tab and the start stop unit. (Scheme 35): Inserting Flathead Screwdriver Into Service Hole (Scheme 36): Removing Wiper And Washer Switch Using Screwdriver
9. Remove the wiper and washer switch from the start stop unit.
10. Install in the reverse order of removal. (Scheme 37): Identifying Wiper And Washer Switch And Start Stop Unit

Scheme 38

Scheme 39

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Remove the following parts: Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-615455-S35240345352014051000000) ). Wiper and washer switch (See «WIPER AND WASHER SWITCH REMOVAL/INSTALLATION»(ref-615468-S27501597382014051000000) ).
3. Use a tester to measure and verify that the continuity between the windshield wiper and washer switch terminals is as indicated in the table. If the continuity is not as indicated in the table, replace the windshield wiper and washer switch. (See «WIPER AND WASHER SWITCH REMOVAL/INSTALLATION»(ref-615468-S27501597382014051000000) ). (Scheme 38): Wiper And Washer Switch Terminals Continuity Reference Chart (Scheme 39): Windshield Washer Switch - Circuit Diagram

Scheme 40

Scheme 41

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Remove the following parts: Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-615455-S35240345352014051000000) ). Wiper and washer switch (See «WIPER AND WASHER SWITCH REMOVAL/INSTALLATION»(ref-615468-S27501597382014051000000) ).
3. Use a tester to measure and verify that the continuity between the rear wiper and washer switch terminals is as indicated in the table. If the continuity is not as indicated in the table, replace the wiper and washer switch. (See «WIPER AND WASHER SWITCH REMOVAL/INSTALLATION»(ref-615468-S27501597382014051000000) ). (Scheme 40): Rear Wiper And Washer Switch Terminals Continuity Reference Chart (Scheme 41): Rear Washer Switch - Circuit Diagram

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

1. Disconnect the negative battery cable. (See «NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION [SKYACTIV-G 2.0]»(ref-615412-S04991947062014051000000) ).
2. Spread open the rain sensor cover in the direction of the arrows (1) and disengage tabs A to remove it. (Scheme 42): Removing Rain Sensor Cover
3. Disconnect the rain sensor connector in the direction of the arrow (2). (Scheme 43): Removing Rain Sensor Connector
4. Slide rain sensor tabs B in the direction of the arrow (3) shown in the figure, detach the engagement, and pull tab B in the direction of the arrow (4). (Scheme 44): Sliding Rain Sensor Tabs B
5. Remove the rain sensor in the direction of the arrow (5) shown in the figure. (Scheme 45): Removing Rain Sensor
6. Peel off the rain sensor protective sheet from the rain sensor.
7. Install in the reverse order of removal. (See «RAIN SENSOR INSTALLATION NOTE»(ref-615468-S34285420522014051000000) ).
8. Perform headlight auto light setting. (See «LIGHTING SYSTEM PERSONALIZATION FEATURES SETTING PROCEDURE»(ref-615452-S21497963772014051000000) ). (Scheme 46): Identifying Rain Sensor Protective Sheet
