Rain Sensor Installation Note
| CAUTION | If the rate at which the rain sensor reflects or transmits infrared light between the rain sensor and the windshield, or through the protective sheet is changed, the rain sensor will determine that there is a malfunction in the rain detection function and stop auto wiper system control. Be careful of the following when installing the rain sensor: Do not reuse the rain sensor protective sheet Do not touch the rain sensor lens, rain sensor protective sheet, and sensor installation area on windshield with your fingers Verify that there is no air bubble after installing the rain sensor |
Scheme 69
Scheme 70
Scheme 71
Scheme 72
Scheme 73
Scheme 74
- Wipe off any oil or dirt from the rain sensor lens and the windshield using a clean rag. (Scheme 69): Cleaning Oil Or Dirt From Rain Sensor Lens And Windshield Using Clean Rag
- Peel off backing of double-sided adhesive tape A from the rain sensor protective sheet. (Scheme 70): Removing Double-Sided Adhesive Tape A From Rain Sensor Protective Sheet
- Adhere the rain sensor protective sheet to the rain sensor lens. (Scheme 71): Applying Rain Sensor Protective Sheet To Rain Sensor Lens
- Peel off backing of double-sided adhesive tape B from the rain sensor protective sheet.
- Install the rain sensor in the direction of the arrow (1). (Scheme 72): Removing Double-Sided Adhesive Tape B From Rain Sensor Protective Sheet (Scheme 73): Installing Rain Sensor
- Press the rain sensor in the direction (direction of arrow (2)) of the windshield and press out any air bubbles. (Scheme 74): Pressing Rain Sensor
- Verify that there is no air bubble between the rain sensor and the windshield.
