General Information: Removal & Installation Mazda CX-5 I

Oem General Information 3 illustrations ~361 words

Removal of Parts

  1. While correcting a problem, also try to determine its cause. Begin work only after first learning which parts and subassemblies must be removed and disassembled for replacement or repair. After removing the part, plug all holes and ports to prevent foreign material from entering.

Learning Correcting Problem. Scheme 15

Scheme 15: Learning Correcting Problem

INSTALLATION OF RADIO SYSTEM

The control modules and control unit have been designed with sufficient attention to radio wave disturbances from the outside. However, observe the following precautions when installing the radio set to the vehicle to prevent adverse effects on the control modules and control unit.

Scheme 16

Scheme 16: INSTALLATION OF RADIO SYSTEM
  1. Install the radio set and its antenna as far away as possible from the control modules and control unit.
  2. The antenna feeder and power cable generate radio waves, therefore, keep them 100 mm {3.94 in} or more from the control modules, control unit, and wiring harness. If the antenna feeder and power cable cross over the wiring harness, place them perpendicular to the wiring harness.
  3. Do not install a high output radio set.
  4. Do not use the control modules and control unit power source for the radio set. In addition, do not use the cigar lighter and accessory socket power source.
  5. Do not attach the antenna feeder or wiring harness of the radio set to the wiring harness, fuel pipe, or brake tube of the vehicle.
  6. Do not install any radio set-related devices in the area where the air bag module deploys to prevent a secondary accident if the air bag were to deploy. (Scheme 16): Identifying Curtain Air Bag Module, SAS Control Module And Air Beg Module (Passenger And Driver Side)
  7. After installing the radio set, perform a test transmission with the engine idling to verify that it does not affect engine control.

Replacement

  1. Use the appropriate tools to remove a terminal as shown. When installing a terminal, be sure to insert it until it locks securely.
  2. Insert a thin piece of metal from the terminal side of the connector and with the terminal locking tab pressed down, pull the terminal out from the connector.

Removing Connector Terminal (Type A And B). Scheme 17

Scheme 17: Removing Connector Terminal (Type A And B)
