AUTO LIGHT/WIPER CONTROL MODULE REMOVAL/INSTALLATION
Note. Auto wiper system are integrated with the auto light/wiper control module.
- Disconnect the negative battery cable.
- Remove the dashboard under cover (driver-side). (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-581614-S27123962102013101400000) .)
- Remove the auto light/wiper control module. (See «AUTO LIGHT-OFF CONTROL MODULE REMOVAL/INSTALLATION»(ref-581620-S41670473562013101400000) .)
- Install in the reverse order of removal.
Rain Sensor Installation Note
| CAUTION | If the rate at which the rain sensor reflects or transmits infrared light between the rain sensor and the windshield, or through the protective sheet is changed, the rain sensor will determine that there is a malfunction in the rain detection function and stop auto wiper system control. Be careful of the following when installing the rain sensor: Do not reuse rain sensor protective sheet Do not touch rain sensor lens, rain sensor protective sheet, and sensor installation area on windshield with your finger Verify that there is no air bubble after installing rain sensor |
Scheme 29
Scheme 30
Scheme 31
Scheme 32
Scheme 33
Scheme 34
- Wipe off any oil or dirt from the rain sensor lens and the windshield using a clean rag. (Scheme 29): Cleaning Rain Sensor Lens
- Peel off double-sided adhesive tape A from the rain sensor protective sheet. (Scheme 30): Peeling Off Double-Sided Adhesive Tape A From Rain Sensor Protective Sheet
- Adhere the rain sensor protective sheet to the rain sensor lens. (Scheme 31): Installing Rain Sensor Protective Sheet To Rain Sensor Lens
- Peel off double-sided adhesive tape B from the rain sensor protective sheet. (Scheme 32): Peeling Off Double-Sided Adhesive Tape B From Rain Sensor Protective Sheet
- Install the rain sensor. (Scheme 33): Rain Sensor
- Press the rain sensor in the direction of the windshield and press out any air bubbles. (Scheme 34): Pressing Rain Sensor
- Verify that there is no air bubble between the windshield and the rain sensor.
