On-Board Diagnostic [Auto Light/wiper Control Module]: Overview Mazda 6 GJ

On-Board Diagnostic Wiring Diagram (Auto Light/Wiper Control Module). Scheme 35

Scheme 36

1. Connect the M-MDS (IDS) to the DLC-2. (Scheme 36): Identifying DLC-2 Location
2. After the vehicle is identified, select the following items from the initialization screen of the IDS. Select "Self Test". Select "Modules". Select "LCM".
3. Verify the DTC according to the directions on the screen. If any DTCs are displayed, perform troubleshooting according to the corresponding DTC inspection.
4. After completion of repairs, clear all DTCs stored in the auto light/wiper control module. (See «CLEARING DTC [AUTO LIGHT/WIPER CONTROL MODULE]»(ref-581704-S04380179062013101400000).)

See also:
• ON-BOARD DIAGNOSTIC TEST [MZR 2.5]
• ON-BOARD DIAGNOSTIC TEST [MZI 3.7 V6]
