Sunroof: Removal & Installation Mazda 6 GJ

Sun Roof/t-Top/convertible Top 5 illustrations ~1525 words

FRONT DRAIN HOSE INSTALLATION

CAUTIONIf the front drain hose is pinched or bent anywhere, the water in the hose may not discharge and enter the inside of the vehicle. During and after installation of the trims and the headliner, always make sure there is no interference with the front drain hose. Fix any problem if found.
  1. Apply soapy water to the front drain hose inserting area.
  2. Insert one end (the wider end) of the front drain hose into the sunroof frame.
  3. Install the front drain hose to the clips, parallel to the pillar and free of slack.
  4. Insert the front drain hose joint into the hinge pillar inner hole.
  5. Connect the auto-dimming mirror connector. (vehicles with auto-dimming mirror)
  6. Install the following parts: Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-581614-S06320006622013101400000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-581614-S34345018172013101400000) .) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-581620-S12558053102013101400000) .) Sunvisors (See «SUNVISOR REMOVAL/INSTALLATION»(ref-581614-S15387534752013101400000) .) C-pillar trims (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S18739322292013101400000) .) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-581617-S04306764902013101400000) .) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-581617-S39478993682013101400000) .) B-pillar upper trims (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-581614-S03709703802013101400000) .) B-pillar lower trims (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-581614-S21790786902013101400000) .) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S02378223002013101400000) .) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-581619-S13872678202013101400000) .) A-pillar trims (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S20559757112013101400000) .) Sunroof seaming welt Audio amplifier (with Bose®) (See «AUDIO AMPLIFIER REMOVAL/INSTALLATION»(ref-581616-S17006069772013101400000) .) Dashboard (See «DASHBOARD REMOVAL/INSTALLATION»(ref-581614-S23273769092013101400000) .) A-pillar trims (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S20559757112013101400000) .) Passenger-side air bag module (See «PASSENGER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-581610-S16434598032013101400000) .) SIRIUS satellite radio unit (See «SIRIUS SATELLITE RADIO UNIT REMOVAL/INSTALLATION»(ref-581616-S38070671012013101400000) .) Side panel (See «SIDE PANEL REMOVAL/INSTALLATION»(ref-581614-S07883015262013101400000) .) Steering shaft (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581622-S34424186902013101400000) .) (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581622-S06798620582013101400000) .) Steering shaft cover (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581622-S34424186902013101400000) .) (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581622-S06798620582013101400000) .) Audio unit (See «AUDIO UNIT REMOVAL/INSTALLATION»(ref-581616-S32219205692013101400000) .) Center panel upper (See «CENTER PANEL UPPER REMOVAL/INSTALLATION»(ref-581614-S25330971132013101400000) .) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-581651-S30763301102013101400000) .) Meter hood (See «METER HOOD REMOVAL/INSTALLATION»(ref-581614-S19165313082013101400000) .) Combination switch (See «COMBINATION SWITCH REMOVAL/INSTALLATION»(ref-581620-S26915536712013101400000) .) aa. Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-581614-S36009183262013101400000) .) ab. Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581622-S34424186902013101400000) .) (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581622-S06798620582013101400000) .) ac. Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-581610-S10735079002013101400000) .) ad. Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-581614-S08723493922013101400000) .) ae. Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-581656-S24929307862013101400000) .) af. Rear console (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-581614-S12913222402013101400000) .) ag. Climate control unit (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]»(ref-581663-S24664239442013101400000) .) (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [MANUAL AIR CONDITIONER]»(ref-581664-S10963812152013101400000) .) ah. Center panel lower (See «CENTER PANEL LOWER REMOVAL/INSTALLATION»(ref-581614-S05740589362013101400000) .) ai. Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-581614-S38776581642013101400000) .) aj. Shift knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM LOCATION INDEX»(ref-581615-S41865543102013101400000) .) ak. Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-581614-S30597239632013101400000) .) al. Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-581614-S15065956352013101400000) .) am. Front side trims (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-581614-S15846352132013101400000) .) an. Front scuff plates (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S36484760642013101400000) .) ao. Dashboard under cover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-581614-S27123962102013101400000) .) ap. Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-581614-S35474389282013101400000) .)
  7. Connect the rain sensor connector. (Vehicles with auto light/wiper system)
  8. Install the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-581618-S16481366742013101400000) .)
  9. Install the seaming welt.
  10. Connect the negative battery cable.

Scheme 14

Scheme 14: REAR DRAIN HOSE REMOVAL
Scheme 14: REAR DRAIN HOSE REMOVAL
  1. Disconnect the negative battery cable.
  2. Partially peel back the seaming welt.
  3. Remove the following parts: Sunroof seaming welt A-pillar trims (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S20559757112013101400000) .) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-581619-S13872678202013101400000) .) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S36484760642013101400000) .) Rear scuff plate inner (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S02378223002013101400000) .) B-pillar lower trims (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-581614-S21790786902013101400000) .) B-pillar upper trims (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-581614-S03709703802013101400000) .) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-581617-S39478993682013101400000) .) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-581617-S04306764902013101400000) .) C-pillar trims (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S18739322292013101400000) .)
  4. Disconnect the dimming mirror connector. (vehicles with dimming mirror)
  5. Disconnect the rain sensor connector. (vehicles with rain sensor)
  6. Remove the sunvisors. (See «SUNVISOR REMOVAL/INSTALLATION»(ref-581614-S15387534752013101400000) .)
  7. Remove the map light. (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-581620-S12558053102013101400000) .)
  8. Remove the assist handle. (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-581614-S34345018172013101400000) .)
  9. Remove the headliner. (See «HEADLINER REMOVAL/INSTALLATION»(ref-581614-S06320006622013101400000) .)
  10. Remove the trunk end trim. (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-581614-S18023401772013101400000) .)
  11. Remove the trunk side trim. (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-581614-S05382445092013101400000) .)
  12. Disconnect the rear drain hose from the sunroof frame.
  13. Remove the rear drain hose from the clips.
  14. Pull the rear drain hose into the room side.
  15. Remove the rear drain hose.

REAR DRAIN HOSE INSTALLATION

CAUTIONIf the rear drain hose is pinched or bent anywhere, the water in the hose may not discharge and enter the inside of the vehicle. During and after installation of the trims and the headliner, always make sure there is no interference with the rear drain hose. Fix any problem if found.
  1. Apply soapy water to the rear drain hose inserting area.
  2. Insert one end (the wider side) of the rear drain hose into the sunroof frame.
  3. Install the rear drain hose to the clips parallel to the pillar and free of slack.
  4. Insert the rear drain hose joint into the rear pillar inner hole.
  5. Install the trunk side trim. (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-581614-S05382445092013101400000) .)
  6. Install the trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-581614-S18023401772013101400000) .)
  7. Install the headliner. (See «HEADLINER REMOVAL/INSTALLATION»(ref-581614-S06320006622013101400000) .)
  8. Install the map light. (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-581620-S12558053102013101400000) .)
  9. Install the assist handle. (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-581614-S34345018172013101400000) .)
  10. Install the sunvisors. (See «SUNVISOR REMOVAL/INSTALLATION»(ref-581614-S15387534752013101400000) .)
  11. Connect the rain sensor connector. (vehicles with rain sensor)
  12. Connect the dimming mirror connector. (vehicles with dimming mirror)
  13. Install the following parts: C-pillar trims (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S18739322292013101400000) .) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-581617-S04306764902013101400000) .) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-581617-S39478993682013101400000) .) B-pillar upper trims (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-581614-S03709703802013101400000) .) B-pillar lower trims (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-581614-S21790786902013101400000) .) Rear scuff plate inner (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S02378223002013101400000) .) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S36484760642013101400000) .) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-581619-S13872678202013101400000) .) A-pillar trims (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S20559757112013101400000) .) Sunroof seaming welt
  14. Install the seaming welt.
  15. Connect the negative battery cable.

Scheme 15

Scheme 15: SUNROOF MOTOR REMOVAL/INSTALLATION
Scheme 15: SUNROOF MOTOR REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Partially peel back the seaming welt.
  3. Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-581618-S16481366742013101400000) .)
  4. Disconnect the rain sensor connector. (Vehicles auto light/wiper system)
  5. Remove the following parts: Sunroof seaming welt A-pillar trims (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S20559757112013101400000) .) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S36484760642013101400000) .) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S02378223002013101400000) .) B-pillar lower trims (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-581614-S21790786902013101400000) .) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-581619-S13872678202013101400000) .) B-pillar upper trims (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-581614-S03709703802013101400000) .) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-581617-S39478993682013101400000) .) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-581617-S04306764902013101400000) .) C-pillar trims (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S18739322292013101400000) .)
  6. Disconnect the auto-dimming mirror connector. (vehicles with auto-dimming mirror)
  7. Remove the sunvisors. (See «SUNVISOR REMOVAL/INSTALLATION»(ref-581614-S15387534752013101400000) .)
  8. Remove the map light. (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-581620-S12558053102013101400000) .)
  9. Remove the assist handle. (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-581614-S34345018172013101400000) .)
  10. Remove the headliner. (See «HEADLINER REMOVAL/INSTALLATION»(ref-581614-S06320006622013101400000) .)
  11. Disconnect the sunroof motor connector.
  12. Remove the screws, and then remove the sunroof motor.
  13. Install in the reverse order of removal. NOTE: If the glass panel or the sunroof motor is moved with the sunroof motor removed, initial position setting of the sunroof motor will be required. Perform initial position setting referring to the Sunroof Motor Assembly Note. (See «SUNROOF UNIT DISASSEMBLY/ASSEMBLY»(ref-581735-S26567063692013101400000) .)
  1. Disconnect the negative battery cable.
  2. Partially peel back the seaming welt.
  3. Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-581618-S16481366742013101400000) .)
  4. Disconnect the rain sensor connector. (Vehicles auto light/wiper system)
  5. Disconnect the auto-dimming mirror connector. (vehicles with auto-dimming mirror)
  6. Remove the following parts: Sunroof seaming welt A-pillar trims (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S20559757112013101400000) .) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S36484760642013101400000) .) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S02378223002013101400000) .) B-pillar lower trims (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-581614-S21790786902013101400000) .) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-581619-S13872678202013101400000) .) B-pillar upper trims (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-581614-S03709703802013101400000) .) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-581617-S39478993682013101400000) .) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-581617-S04306764902013101400000) .) C-pillar trims (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S18739322292013101400000) .) Sunvisors (See «SUNVISOR REMOVAL/INSTALLATION»(ref-581614-S15387534752013101400000) .) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-581620-S12558053102013101400000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-581614-S34345018172013101400000) .) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-581614-S06320006622013101400000) .)
  7. Measure the voltage at each terminal. If not as specified, inspect the parts listed under "Inspection item" and the related wiring harnesses. If the parts and wiring harnesses are normal but the system still does not work properly, replace the sunroof motor. (See «SUNROOF MOTOR REMOVAL/INSTALLATION»(ref-581735-S04777688962013101400000) .)

Scheme 16

Scheme 16: Terminal Voltage Table (Reference)
Scheme 16: Terminal Voltage Table (Reference)
TerminalSignalConnected toTest conditionVoltage (V)Inspection item
ASlide openSunroof switchSunroof is fully opening.B+Sunroof switch
Other1.0 or less
BSlide close/tilt downSunroof switchSunroof is closing/tilting down.B+Sunroof switch
Other1.0 or less
CTilt upSunroof switchSunroof is tilting up.B+Sunroof switch
Other1.0 or less
EIG2A/C 10 A fuseSwitch the ignition ON.B+A/C 10 A fuse
Other1.0 or less
FVehicle speedInstrument clusterPulse signalInstrument cluster Related wiring harnesses
GGNDGNDUnder any condition1.0 or lessGND
HCommunicationBCMBecause this terminal is for communication, good/no good judgment by terminal voltage is not possible.BCM Related wiring harnesses
JPower supplySUN ROOF 15 A fuseUnder any conditionB+SUN ROOF 15 A fuse

Note. The sunroof switch is together with the front map light.

  1. Disconnect the negative battery cable.
  2. Open the overhead console.
  3. Remove the map light from the headliner. (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-581620-S12558053102013101400000) .)
  4. Install in the reverse order of removal.

Scheme 17

Scheme 17: SUNROOF SWITCH INSPECTION
Scheme 17: SUNROOF SWITCH INSPECTION

Scheme 18

Scheme 18
Scheme 18
  1. Disconnect the negative battery cable.
  2. Open the overhead console.
  3. Remove the map light from the headliner. (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-581620-S12558053102013101400000) .)
  4. Remove the sunroof switch. (See «SUNROOF SWITCH REMOVAL/INSTALLATION»(ref-581735-S06748777692013101400000) .)
  5. Inspect for continuity between the sunroof switch terminals using an ohmmeter. If not as specified, replace the sunroof switch. (See «SUNROOF SWITCH REMOVAL/INSTALLATION»(ref-581735-S06748777692013101400000) .)
