Interior Trim: Removal & Installation Mazda 6 GJ

GLOVE COMPARTMENT REMOVAL/INSTALLATION

Scheme 14

Scheme 15

Scheme 16

1. Pull the stay damper in the direction of the arrow shown in the figure, and detach the connecting part between the glove compartment and the stay damper. (Scheme 14): Stay Damper
2. Push both ends of the inner-side glove compartment in the direction of the arrow shown in the figure. (Scheme 15): Push Both Ends Of Inner-Side Glove Compartment
3. Lower the glove compartment in the direction of the arrow shown in the figure. (Scheme 16): Dashboard Hook
4. Detach the hook from the dashboard in the direction of the arrow shown in the figure and remove the glove compartment.
5. Install in the reverse order of removal.

Scheme 17

1. Disconnect the negative battery cable.
2. Remove the center panel upper. (See «CENTER PANEL UPPER REMOVAL/INSTALLATION»(ref-581614-S25330971132013101400000) )
3. Remove the screw. (Scheme 17): Center Ventilator Grille, Upper Panel And Screws
4. Remove the center ventilator grille from the center panel upper.
5. Install in the reverse order of removal.

Scheme 18

1. Pull out the fin of the side ventilator grill with turning it while disconnecting the tab of the ventilator grill cover. (Scheme 18): Fin Side Ventilator Grill
2. Install in the reverse order of removal.

Scheme 19

1. Disconnect the negative battery cable.
2. Remove the rear console panel. (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-581614-S12913222402013101400000).)
3. Remove the tabs A (Scheme 19): Rear Ventilator Grille And Tabs
4. Remove the rear ventilator grille.
5. Install in the reverse order of removal.

Scheme 20

1. Disconnect the negative battery cable.
2. Remove the following parts: Driver-side front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S36484760642013101400000).) Drive-side front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-581614-S15846352132013101400000).) Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-581614-S15065956352013101400000).) Drive-side decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-581614-S30597239632013101400000).) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-581656-S24929307862013101400000).) Meter hood (See «METER HOOD REMOVAL/INSTALLATION»(ref-581614-S19165313082013101400000).) Drive-side lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-581614-S08723493922013101400000).)
3. Remove the bolts. (Scheme 20): Knee Bolster And Bolts With Torque Specification
4. Remove the knee bolster.
5. Install in the reverse order of removal.

Scheme 21

1. Detach clip A, pin B and guide C by pulling them in the direction of the arrow (1), (2). (Scheme 21): Dashboard Under Cover Clips
2. Remove the dashboard under cover.
3. Install in the reverse order of removal.

UPPER PANEL REMOVAL/INSTALLATION

Scheme 22

Scheme 23

1. Pull the upper panel in the direction of the arrow in the order of (1) and (2), then remove it while detaching the clip A, B and C. (Scheme 22): Upper Panel Clips
2. Move the upper panel in the direction of the arrow in the order of (3), and remove it. (Scheme 23): Moving Upper Panel
3. Install in the reverse order of removal.

Scheme 24

Scheme 25

1. Remove the shift knob. (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-581615-S07668845722013101400000) )
2. Pull the shift panel in the direction of the arrow shown in the figure and remove it while detaching the hooks. ATX (Scheme 24): Pulling Shift Panel Of Hooks (ATX) MTX (Scheme 25): Pulling Shift Panel Of Hooks (MTX)
3. Remove the shift panel.
4. Install in the reverse order of removal.

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

1. Disconnect the negative battery cable.
2. Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-581614-S15065956352013101400000).) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-581615-S07668845722013101400000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-581614-S38776581642013101400000).) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-581614-S30597239632013101400000).)
3. Disconnect the auxiliary jack connector and accessory socket connector.
4. Remove the screws A, B and screw C. (Scheme 26): Rear Console And Screws
5. Open the console lid and remove the storage box and mat. (Scheme 27): Storage Box And Mat
6. Remove the screws D. (Scheme 28): Rear Console And Screws
7. Pull the rear console in the direction of the arrow in the order of (1), then detaching clip E. (Scheme 29): Rear Console Clips
8. Pull up the rear console in the direction of the arrow (2) shown in the figure, move the rear console in the direction of the arrow (3), and remove it avoiding the parking brake lever. (Scheme 30): Moving Rear Console
9. Install in the reverse order of removal.

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

1. Disconnect the negative battery cable.
2. Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-581614-S15065956352013101400000).) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-581615-S07668845722013101400000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-581614-S38776581642013101400000).) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-581614-S30597239632013101400000).)
3. Disconnect the auxiliary jack connector and accessory socket connector.
4. Remove the screws A, B and screw C. (Scheme 31): Rear Console And Screws
5. Open the console lid and remove the storage box and mat. (Scheme 32): Storage Box And Mat
6. Remove the screws D. (Scheme 33): Rear Console And Screws
7. Remove the clip F and hook G. (Scheme 34): Rear Console Panel Clip And Hook
8. Remove the rear console panel.
9. Remove the rear fan switch connector.
10. Remove the screw H. (Scheme 35): Rear Console And Screw
11. Pull the rear console in the direction of the arrow in the order of (1), then detaching clip E. (Scheme 36): Pulling Rear Console Of Clip
12. Pull up the rear console in the direction of the arrow (2) shown in the figure, move the rear console in the direction of the arrow (3), and remove it avoiding the parking brake lever. (Scheme 37): Moving Rear Console
13. Install in the reverse order of removal.

Scheme 38

1. Disassemble in the order indicated in the table.
2. Assemble in the reverse order of disassembly. (Scheme 38): Rear Console, Rear Console Cover, Clip, Tab And Screw

Scheme 39

1. Disassemble in the order indicated in the table.
2. Assemble in the reverse order of disassembly. (Scheme 39): Rear Console, Rear Console Cover, Clip And Tab

Scheme 40

1. Remove the upper panel. (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-581614-S15065956352013101400000) )
2. Pull the decoration panel in the direction of the arrow in the order of (1) and (2), then remove it while detaching the hooks A, clips B and pin C. (Scheme 40): Decoration Panel Mounting Components (Driver-Side)
3. Remove the decoration panel.
4. Install in the reverse order of removal.

Scheme 41

1. Remove the upper panel. (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-581614-S15065956352013101400000) )
2. Pull the decoration panel in the direction of the arrow in the order of (1) and (2), then remove it while detaching the hooks A, clips B and pin C. (Scheme 41): Decoration Panel Mounting Components (Passenger-Side)
3. Remove the decoration panel.
4. Install in the reverse order of removal.

Scheme 42

1. Partially peel back the seaming welt.
2. Pull the upper end of the A-pillar trim in the direction of the arrow (1), (2) shown in the figure and remove clip A, B and tab C. (Scheme 42): A-Pillar Trim Upper End Mounting Components CAUTION: When pulling out the A-pillar trim, be careful not to damage the tabs.
3. When installing the A-pillar, Install the new clip A to the A-pillar trim in advance.
4. Install in the reverse order of removal.

Scheme 43

1. Remove the front scuff plate. (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S36484760642013101400000).)
2. Partially peel back the seaming welt.
3. Remove the cap nut. (Scheme 43): Front Side Trim Mounting Components
4. Pull the front side trim in the direction of the arrow shown in the figure and remove it while detaching clip.
5. Remove the front side trim.
6. Install in the reverse order of removal.

Scheme 44

1. Remove the following parts: High-mount brake light (See «HIGH-MOUNT BRAKE LIGHT REMOVAL/INSTALLATION»(ref-581620-S00181689782013101400000).) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-581617-S04306764902013101400000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S18739322292013101400000).)
2. Fold the rear seat back.
3. Remove the fastener A. (Scheme 44): Rear Package Trim Mounting Components
4. Pull up the rear package trim in the direction of the arrow (1) shown in the figure to remove the clips B, pull the rear package trim in the direction of the arrow (2), and remove it while pulling out the guides C.
5. Remove the rear package trim.
6. Install in the reverse order of removal.

Scheme 45

1. Remove the front scuff plate. (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S36484760642013101400000) )
2. Remove the rear scuff plate. (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S02378223002013101400000) )
3. Partially peel back the seaming welt.
4. Pull the B-pillar lower trim in the direction of the arrow (1), (2), (3) shown in the figure, detach pin A, tab B, clip C, pin D, and clip E then remove the B-pillar lower trim. (Scheme 45): B-Pillar Lower Trim Mounting Components
5. Remove the B-pillar lower trim.
6. Install in the reverse order of removal.

Scheme 46

Scheme 47

1. Remove the following parts: Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S36484760642013101400000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S02378223002013101400000).) Adjuster anchor cover (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-581619-S13872678202013101400000).) Front seat belt upper anchor installation bolts (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-581619-S13872678202013101400000).)
2. Partially peel back the seaming welt.
3. Remove the B-pillar lower trim. (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-581614-S21790786902013101400000) )
4. Grasp the lower end of the B-pillar upper trim, pull it in the direction of the arrow shown in the figure, and remove clip A, pin B, and hook C. (Scheme 46): B-Pillar Upper Trim Mounting Components
5. Remove the B-pillar upper trim in the direction of the arrow shown in the figure. (Scheme 47): Removing B-Pillar Upper Trim CAUTION: When removing the B-pillar upper trim, be careful not to damage the tabs.
6. Install in the reverse order of removal.

Scheme 48

Scheme 49

1. Remove the following parts: Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-581617-S39478993682013101400000).)
2. Partially peel back the seaming welt.
3. Pull the C-pillar trim in the direction of the arrow (1), (2), (3) shown in the figure, then detaching clip A and B. (Scheme 48): C-Pillar Trim Mounting Components
4. Remove the C-pillar trim in the direction of the arrow shown in the figure while remove the tabs C and D. (Scheme 49): C-Pillar Trim Tabs CAUTION: When removing the C-pillar trim, be careful not to damage the tabs C and D.
5. When installing the C-pillar, Install the new clip A to the C-pillar trim in advance.
6. Install in the reverse order of removal.

Scheme 50

1. Detach tabs A while pulling the front scuff plate in the direction of the arrow (1) shown in the figure, then detach tabs B, pins C, clips D, pin E and guides F while pulling in the direction of the arrow (2). (Scheme 50): Front Scuff Plate Mounting Components
2. Remove the front scuff plate.
3. Install in the reverse order of removal.

Scheme 51

1. Remove the rear seat cushion. (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-581617-S39478993682013101400000).)
2. Remove the fastener A.
3. Detach tab B while pulling the rear scuff plate in the direction of the arrow (1) shown in the figure, then detach tab C, pin D, E, clip F and G while pulling in the direction of the arrow (2). (Scheme 51): Rear Scuff Plate Mounting Components
4. Remove the rear scuff plate.
5. Install in the reverse order of removal.

Scheme 52

1. Disconnect the negative battery cable.
2. Pull the inner garnish in the direction of the arrow shown in the figure and remove it while detaching clips and tab. (Scheme 52): Inner Garnish Mounting Components
3. Disconnect the front tweeter connector. (Vehicles with tweeter)
4. Install in the reverse order of removal.

Scheme 53

Scheme 54

1. Remove the screw. (Scheme 53): Fuel-Filler Lid Opener Bezel And Screw
2. Move the fuel-filler lid opener bezel in the direction of the arrow shown in the figure. (Scheme 54): Moving Fuel-Filler Lid Opener Bezel
3. Install in the reverse order of removal.

Scheme 55

1. Disassemble in the order shown in the figure.
2. Assemble in the reverse order of disassemble. (Scheme 55): Rear Door Trim Components

Scheme 56

1. Open the trunk lid.
2. Remove the trunk mat.
3. Remove the trunk board.
4. Remove the fasteners A. (Scheme 56): Trunk End Trim Mounting Components
5. Pull the trunk end trim in the direction of the arrow shown in the figure and remove it while detaching the pins B, D and clips C.
6. Install in the reverse order of removal.

TRUNK SIDE TRIM REMOVAL/INSTALLATION

1. Remove the trunk end trim. (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-581614-S18023401772013101400000) .)
2. Remove the rear seat cushion. (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-581617-S39478993682013101400000) .)
3. Remove the rear side seat back. (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-581617-S04306764902013101400000) .)

Scheme 57

1. Remove the fasteners and hook, then remove the trunk side trim. (See «HOOK REMOVAL NOTE»(ref-581614-S30365227292013101400000).) (Scheme 57): Trunk Side Trim, Fasteners And Hook (Left Side)
2. Install in the reverse order of removal.

Scheme 58

1. Remove the fasteners and hook, then remove the trunk side trim. (See «HOOK REMOVAL NOTE»(ref-581614-S30365227292013101400000).) (Scheme 58): Trunk Side Trim, Fasteners And Hook (Right Side)
2. Install in the reverse order of removal.

Scheme 59

1. Remove hook by inserting a small flathead screwdriver into the service hole as shown in the figure. (Scheme 59): Removing Hook

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

1. Disconnect the negative battery cable.
2. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-581614-S33446531912013101400000) )
3. Pull the cover of inner handle and remove it while detaching tabs. (Scheme 60): Front Door Trim, Recess Cover, Tab And Screws
4. Remove the recess cover.
5. Remove the screws.
6. Pull in the direction of the arrow shown in the figure and remove clips from the door inner panel using a fastener remover. (Scheme 61): Inner Door Panel Clips
7. Remove the front door trim in the direction of the arrow shown in the figure. (Scheme 62): Removing Front Door Trim
8. Remove the inner handle and move the front door trim in the direction of the arrow shown in the figure. (Scheme 63): Moving Front Door Trim
9. Turn the inner handle 90° in the direction of the arrow and remove it from the front door trim. (Scheme 64): Turning Inner Handle
10. Disconnect the power outer mirror switch connector and power window main switch connector. (driver-side)
11. Disconnect the power window subswitch connector. (passenger-side)
12. Remove the door courtesy illumination bulb socket. (See «COURTESY LIGHT BULB REMOVAL/INSTALLATION»(ref-581620-S02768668452013101400000).)
13. Install in the reverse order of removal.

Scheme 65

1. Disassemble in the order shown in the figure.
2. Assemble in the reverse order of disassemble. (Scheme 65): Front Door Trim Components (Driver-Side)

Scheme 66

1. Disassemble in the order shown in the figure.
2. Assemble in the reverse order of disassemble. (Scheme 66): Identifying Front Door Trim Components (Passenger-Side)

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

1. Disconnect the negative battery cable.
2. Pull the cover of inner handle and remove it while detaching tabs. (Scheme 67): Rear Door Trim, Recess Cover, Tabs And Screws
3. Remove the recess cover.
4. Remove the screws.
5. Pull in the direction of the arrow shown in the figure and remove clips from the door inner panel using a fastener remover. (Scheme 68): Inner Door Panel Clips
6. Remove the rear door trim in the direction of the arrow shown in the figure. (Scheme 69): Removing Rear Door Trim
7. Remove the inner handle and move the rear door trim in the direction of the arrow shown in the figure. (Scheme 70): Moving Rear Door Trim
8. Turn the inner handle 90° in the direction of the arrow and remove it from the rear door trim. (Scheme 71): Turning Inner Handle
9. Disconnect the power window subswitch connector.
10. Install in the reverse order of removal.

Scheme 72

1. Remove the recess. (See «RECESS REMOVAL/INSTALLATION»(ref-581614-S17369187092013101400000) )
2. Remove the fasteners, then remove the trunk lid trim. (Scheme 72): Trunk Lid Trim And Fasteners
3. Install in the reverse order of removal.

Scheme 73

Scheme 74

1. Insert a fastener remover in the position indicated by the arrow in the figure and detach tabs A. (Scheme 73): Recess Tabs
2. Remove the recess in the direction of the arrow shown in the figure avoiding tabs B. (Scheme 74): Removing Recess Tabs
3. Install in the reverse order of removal.

Scheme 75

Scheme 76

1. Insert a fastener remover into the assist handle service hole and remove the assist handle cover. (Scheme 75): Inserting Fastener Remover Into Assist Handle Service Hole
2. Insert the fastener remover in the position indicated by the arrow in the figure, push down the clip by moving the fastener remover in the direction of the arrow, and remove the assist handle from the assist handle bracket while shaking the assist handle up and down. (Scheme 76): Removing Assist Handle From Assist Handle Bracket CAUTION: When inserting a fastener remover, be careful not to damage the tabs.

Scheme 77

1. Insert the assist handle in the assist handle bracket.
2. Push the assist handle cover in the direction of the arrow shown in the figure to install the assist handle. (Scheme 77): Pushing Assist Handle Cover

Scheme 78

Scheme 79

1. Disconnect the negative battery cable.
2. Remove the screw. (Scheme 78): Rotating Sunvisor And Screw
3. Rotate the sunvisor in the direction of the arrow.
4. Unhook and remove the sunvisor.
5. Disconnect the vanity mirror illumination connector.
6. Press the center adaptor tabs as shown in the figure using two tape-wrapped flathead screwdrivers, and remove the center adaptor. (Scheme 79): Pressing Center Adaptor Tabs
7. Install in the reverse order of removal.

Scheme 80

Scheme 81

1. Disconnect the negative battery cable.
2. Partially peel back the seaming welt.
3. Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-581618-S16481366742013101400000) )
4. Disconnect the rain sensor connector. (Vehicles auto light/wiper system)
5. Remove the following parts: Sunroof seaming welt (vehicles with sunroof system) A-pillar trims (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S20559757112013101400000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S36484760642013101400000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S02378223002013101400000).) B-pillar lower trims (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-581614-S21790786902013101400000).) Front seat belt upper anchor installation bolts (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-581619-S13872678202013101400000).) B-pillar upper trims (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-581614-S03709703802013101400000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-581617-S39478993682013101400000).) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-581617-S04306764902013101400000).) C-pillar trims (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S18739322292013101400000).)
6. Disconnect the auto-dimming mirror connector. (vehicles with auto-dimming mirror)
7. Remove the sunvisors. (See «SUNVISOR REMOVAL/INSTALLATION»(ref-581614-S15387534752013101400000) )
8. Remove the map light. (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-581620-S12558053102013101400000) )
9. Remove the assist handle. (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-581614-S34345018172013101400000) )
10. Disconnect the roof harness connector, remove the clip, and remove the connector.
11. Remove the fasteners. (Scheme 80): Roof Harness Connector And Fasteners
12. Remove the retainer holding the roof panel and remove the headliner.
13. Take the headliner off from the passenger-side door opening. (Scheme 81): Removing Retainer Holding Roof Panel
14. Install in the reverse order of removal.

Scheme 82

Scheme 83

1. Disconnect the negative battery cable.
2. Remove the following parts: Front seats (See «FRONT SEAT REMOVAL/INSTALLATION»(ref-581617-S37007315702013101400000).) Audio amplifier (Vehicles with Bose® system) (See «AUDIO AMPLIFIER REMOVAL/INSTALLATION»(ref-581616-S17006069772013101400000).) Front scuff plates (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S36484760642013101400000).) Rear scuff plates (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S02378223002013101400000).) Front side trims (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-581614-S15846352132013101400000).) Steering shaft cover (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581622-S34424186902013101400000).)(See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581622-S06798620582013101400000).) Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-581614-S15065956352013101400000).) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-581614-S30597239632013101400000).) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM LOCATION INDEX»(ref-581615-S41865543102013101400000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-581614-S38776581642013101400000).) Center panel lower (See «CENTER PANEL LOWER REMOVAL/INSTALLATION»(ref-581614-S05740589362013101400000).) Rear console (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-581614-S12913222402013101400000).) B-pillar lower trims (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-581614-S21790786902013101400000).) Fuel-filler lid opener bezel (See «FUEL-FILLER LID OPENER BEZEL REMOVAL/INSTALLATION»(ref-581614-S33838077642013101400000).) Front seat belt lower anchor installation bolts (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-581619-S13872678202013101400000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-581617-S39478993682013101400000).)
3. Remove the fasteners A and B. (Scheme 82): Floor Covering And Fasteners
4. Remove the flange cap nuts C and harness clips D. (Scheme 83): Flange Cap Nuts And Harness Clips
5. Take the floor covering off from the front passenger-side door opening.
6. Install in the reverse order of removal.
