Interior Trim: Overview Mazda 6 GJ

Scheme 1

Scheme 2

1. Disconnect the negative battery cable.
2. Remove the following parts: Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-581614-S35474389282013101400000).) Dashboard under cover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-581614-S27123962102013101400000).) Front scuff plates (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S36484760642013101400000).) Front side trims (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-581614-S15846352132013101400000).) Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-581614-S15065956352013101400000).) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-581614-S30597239632013101400000).) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(/mazda/6/gj-2012-2015/remont/manual-trans/#manual-transaxle-shift-mechanism).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-581614-S38776581642013101400000).) Center panel lower (See «CENTER PANEL LOWER REMOVAL/INSTALLATION»(ref-581614-S05740589362013101400000).) Climate control unit (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]»(ref-581663-S24664239442013101400000).) (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [MANUAL AIR CONDITIONER]»(ref-581664-S10963812152013101400000).) Rear console (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-581614-S12913222402013101400000).) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-581656-S24929307862013101400000).) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-581614-S08723493922013101400000).) Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-581610-S10735079002013101400000).) Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581622-S34424186902013101400000).)(See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581622-S06798620582013101400000).) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-581614-S36009183262013101400000).) Combination switch (See «COMBINATION SWITCH REMOVAL/INSTALLATION»(ref-581620-S26915536712013101400000).) Meter hood (See «METER HOOD REMOVAL/INSTALLATION»(ref-581614-S19165313082013101400000).) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-581651-S30763301102013101400000).) Center panel upper (See «CENTER PANEL UPPER REMOVAL/INSTALLATION»(ref-581614-S25330971132013101400000).) Audio unit (Vehicles with audio system) (See «AUDIO UNIT REMOVAL/INSTALLATION»(ref-581616-S32219205692013101400000).) Car-navigation unit (Vehicles with car-navigation system) (See «CAR-NAVIGATION UNIT REMOVAL/INSTALLATION»(ref-581616-S02637365352013101400000).) Steering shaft cover (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581622-S34424186902013101400000).)(See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581622-S06798620582013101400000).) Steering shaft (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581622-S34424186902013101400000).)(See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581622-S06798620582013101400000).) Side panel (See «SIDE PANEL REMOVAL/INSTALLATION»(ref-581614-S07883015262013101400000).) SIRIUS satellite radio unit (See «SIRIUS SATELLITE RADIO UNIT REMOVAL/INSTALLATION»(ref-581616-S38070671012013101400000).) aa. Passenger-side air bag module (See «PASSENGER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-581610-S16434598032013101400000).) ab. A-pillar trims (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S20559757112013101400000).)
3. Disconnect antenna feeder No.1 clip from the A-pillar inner panel.
4. Disconnect the washer hose. (See «WINDSHIELD WASHER HOSE REMOVAL/INSTALLATION»(ref-581618-S15331574552013101400000).)
5. Disconnect the dashboard wiring harness connectors.
6. Remove the caps.
7. Remove bolts A, B, C, D and E. (Scheme 1): Dashboard Caps And Bolts With Torque Specification
8. Raise the back side of the dashboard rotate it in the direction of the arrow shown in the figure. (Scheme 2): Raising Back Side Of Dashboard
9. Take the dashboard out through the opened driver's door.
10. Install in the reverse order of removal.

Scheme 3

1. Pull the speaker grille while remove the clips. (Scheme 3): Pulling Speaker Grille Clips
2. Remove the speaker grille.
3. Install in the reverse order of removal.

Scheme 4

1. Remove the ventilator grilles (See «VENTILATOR GRILLE REMOVAL/INSTALLATION»(ref-581614-S42522699092013101400000).)
2. Disassemble in the order indicated in the table.
3. Assemble in the reverse order of disassembly. (Scheme 4): View Of Dashboard Components

Scheme 5

Scheme 6

1. Pull down the steering wheel.
2. Remove the blind rubber. (See «METER HOOD REMOVAL/INSTALLATION»(ref-581614-S19165313082013101400000).)
3. Pull the upper column cover in the direction of the arrow in the order of (1) and (2), then remove the upper column cover while detaching the tabs and pin. (Scheme 5): Upper Column Cover Mounting Components
4. Pull up the steering wheel.
5. Remove the screws.
6. Remove the lower column cover in the direction of the arrow (4) while keeping it open in the direction of the arrow (3) shown in the figure. (Scheme 6): Lower Column Cover Mounting Components
7. Install in the reverse order of removal.

Identifying Center Panel Upper And Protective Tape Shaded Area. Scheme 7

Scheme 8

Scheme 9

1. Disconnect the negative battery cable.
2. Insert a tape-wrapped fastener remover into the position indicated by the arrow in the figure, slide it to remove the hook A and clips B, and raise the front side of the center panel upper. (Scheme 8): Front Side Upper Center Panel, Hook And Clips
3. Pull the center panel upper in the direction of the arrow shown in the figure and remove it while detaching clips C. (Scheme 9): Center Panel Upper Clips
4. Disconnect the center speaker connector.
5. Disconnect the hazard warning switch connector.
6. Disconnect the information display connector.
7. Install in the reverse order of removal.

Scheme 10

1. Disconnect the negative battery cable.
2. Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-581614-S15065956352013101400000).) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-581614-S30597239632013101400000).) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(/mazda/6/gj-2012-2015/remont/manual-trans/#manual-transaxle-shift-mechanism).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-581614-S38776581642013101400000).)
3. Pull the center panel lower in the direction of the arrow(1) shown in the figure while detaching clips B. (Scheme 10): Center Panel Lower Clips
4. Pull the center panel lower in the direction of the arrow(2) shown in the figure and remove it while detaching clips B and hooks A.
5. Disconnect the PAD indicator light bulb connector. (Vehicles with PAD indicator light bulb)
6. Disconnect the seat warmer switch connector. (Vehicles with seat warmer)
7. Disconnect the advanced keyless entry and push button start connector. (Vehicles with advanced keyless entry and push button start system)
8. Disconnect the accessory socket (front) connector.
9. Disconnect the cigarette lighter socket connector. (Arab Gulf Cooperation Council)
10. Install in the reverse order of removal.

Scheme 11

1. Disconnect the negative battery cable.
2. Remove the following parts: Driver-side front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S36484760642013101400000).) Driver-side front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-581614-S15846352132013101400000).) Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-581614-S15065956352013101400000).) Driver-side decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-581614-S30597239632013101400000).) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-581656-S24929307862013101400000).) Meter hood (See «METER HOOD REMOVAL/INSTALLATION»(ref-581614-S19165313082013101400000).)
3. Remove the screw A, pull the lower panel in the direction of the arrow in the order of (1) (2), (3) and remove the lower panel while detaching the hooks B, C, clips D and guide pin E. (Scheme 11): Lower Panel Clips And Screw
4. Disconnect the switch connector.
5. Install in the reverse order of removal.

Scheme 12

1. Pull the side panel in the direction of the arrow in the order of (1) and (2), then remove it while detaching the clips A, B, C and guide D. (Scheme 12): Side Panel Clips And Guide
2. Remove the side panel.
3. Install in the reverse order of removal.

Scheme 13

1. Pull the meter hood in the direction of the arrow shown in the figure and remove it while detaching the clips A, tab B and blind rubber. (Scheme 13): Meter Hood Clips And Tab
2. Remove the meter hood.
3. Install in the reverse order of removal.
